Station Software Version 713.0 (R19-2) / Installation Manual 11/2019 Edition
50
The Language Pack is now ready to be installed. The following dialog box is displayed.
Figure 5-39: Ready for installation
Before installing, you can check the available, required and recommended disk space (per drive) to
perform the installation.
► Click the Disk Space button.
The Disk Space Requirements dialog box is displayed.
Figure 5-40: Disk Space Requirements
► Click the OK button.
The Ready to install dialog box is displayed again.
► Click the Install button to start the installation.
Station Software Version 713.0 (R19-2) / Installation Manual 11/2019 Edition
51
The setup status is displayed during installation.
Figure 5-41: Setup status
After successful installation, the following dialog is displayed.
Figure 5-42: Installation completed
► Click the OK button to exit the setup wizard.
Station Software Version 713.0 (R19-2) / Installation Manual 11/2019 Edition
52
When the installation has been completed, the language(s) you selected will be available on the
station software GUI and SIPLACE Vision GUI respectively.
NOTICE
Uninstalling the Language Pack
Please note that if you uninstall the Language Pack, all installed languages will be
uninstalled (Chinese included!). Single languages cannot be selected or deselected.
If Chinese shall be installed again, the standard Station Software installation must be
modified.
► Follow the instructions in section 8.1
► In the Features and Packages dialog, enable the Chinese language, too.
5.6.3.1 Error Handling
If an error occurs during installation, the setup is interrupted and the following dialog box displayed.
Figure 5-43: Error during installation
► Ensure that the Create Error Report on end option is selected (default).
► Click OK to exit the setup wizard.
The setup wizard will prompt you to store the Error Report (as zip file).
► After the problem has been solved, start the BundleInstaller.exe file to run the installation
again.
