YSM20R_KMK_pl.pdf.pdf - 第127页
1 17 12 35 16 23 21 15 21 20 19 26 28 29 9 3 4 31 27 24 22 30 5 34 13 11 10 6 25 28 28 7 32 8 18 33 14 2 Pin Stand (SL) Matrix 1 17 12 35 16 23 21 15 21 20 19 26 28 29 9 3 4 31 27 24 22 30 5 34 13 11 10 6 25 28 28 7 32 8…
25
19
20
22
21
4
30
18
5
32
3
30
17
28
5
32
30
23
32
32
31
6
36
35
27
14
15
12
27
1
7
26
30
11
29
10
2
13
16
30
8
33
9
24
34
Pin Stand (DS)
Matrix
25
19
20
22
21
4
30
18
5
32
3
30
17
28
5
32
30
23
32
32
31
6
36
35
27
14
15
12
27
1
7
26
30
11
29
10
2
13
16
30
8
33
9
24
34
KMK-1803
13-4
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLW-M91V1-E0
F1 PIN ST.VALVE ASSY
1
2
KLW-M91V1-F0
F2 PIN ST.VALVE ASSY
1
3
KLW-M91V1-G0
R1 PIN ST.VALVE ASSY
1
4
KLW-M91V1-H0
R2 PIN ST.VALVE ASSY
1
5
KLW-M9841-00
PLATE,BASE
2
6
KLW-M9842-00
PLATE
4
7
KLW-M9843-00
PLATE,BUSH
4
8
KLW-M9844-00
PLATE,PIN
4
9
KLW-M9845-00
PLATE
4
10
KLW-M9847-00
JOINT
4
11
KLW-M984A-00
LINEAR BUSH
8
12
KLW-M984B-00
LINEAR SHAFT
8
13
KLW-M984C-00
STOPPER
8
14
KLW-M984D-00
STOPPER
8
15
KMK-M654A-00
CYL.F1 PIN ST.ASSY
1
16
KMK-M654A-10
CYL.F2 PIN ST.ASSY
1
17
KMK-M654A-20
CYL.R1 PIN ST.ASSY
1
18
KMK-M654A-30
CYL.R2 PIN ST.ASSY
1
19
KMK-M9840-A0
PIN ST.F1 ASSY.
1
20
KMK-M9840-B0
PIN ST.F2 ASSY.
1
21
KMK-M9840-C0
PIN ST.R1 ASSY.
1
22
KMK-M9840-D0
PIN ST.R2 ASSY.
1
23
KMK-M9841-00
PLATE,BASE
2
24
KMK-M9846-00
PLATE
4
25
KMK-M9848-00
JOINT,CYL.
4
26
KMK-M984E-00
STAY
4
27
KMK-M984F-A0
SPEED CONTROLLER
8
28
91312-03008
BOLT HEX,SOCKET HEAD
16
29
91312-03010
BOLT HEX,SOCKET HEAD
8
30
91312-04012
BOLT HEX,SOCKET HEAD
32
31
91312-05014
BOLT HEX,SOCKET HEAD
8
32
91312-05020
BOLT HEX,SOCKET HEAD
12
33
91317-03008
BOLT HEX,SOCKET HEAD
8
34
91317-04014
BOLT HEX,SOCKET HEAD
8
35
92902-05200
WASHER,PLAIN
8
36
95302-04600
NUT HEXAGON
16
1
17
12
35
16
23
21
15
21
20
19
26
28
29
9
3
4
31
27
24
22
30
5
34
13
11
10
6
25
28
28
7
32
8
18
33
14
2
Pin Stand (SL)
Matrix
1
17
12
35
16
23
21
15
21
20
19
26
28
29
9
3
4
31
27
24
22
30
5
34
13
11
10
6
25
28
28
7
32
8
18
33
14
2
KMK-1803
13-5
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLW-M911U-00
PLATE,VALVE
1
2
KLW-M91V1-G0
R1 PIN ST.VALVE ASSY
1
3
KLW-M91V1-J0
R2 PIN ST.VALVE ASSY
1
4
KLW-M9841-00
PLATE,BASE
2
5
KLW-M9842-00
PLATE
2
6
KLW-M9843-00
PLATE,BUSH
2
7
KLW-M9844-00
PLATE,PIN
2
8
KLW-M9845-00
PLATE
2
9
KLW-M9847-00
JOINT
2
10
KLW-M984A-00
LINEAR BUSH
4
11
KLW-M984B-00
LINEAR SHAFT
4
12
KLW-M984C-00
STOPPER
4
13
KLW-M984D-00
STOPPER
4
14
KMK-M654A-20
CYL.R1 PIN ST.ASSY
1
15
KMK-M654A-30
CYL.R2 PIN ST.ASSY
1
16
KMK-M9840-C0
PIN ST.R1 ASSY.
1
17
KMK-M9840-E0
PIN ST.R2 ASSY.
1
18
KMK-M9846-00
PLATE
2
19
KMK-M9848-00
JOINT,CYL.
2
20
KMK-M984E-00
STAY
2
21
KMK-M984F-A0
SPEED CONTROLLER
4
22
$KM-05
MUFFLER
1
23
$TSH4-M5M
JOINT
2
24
$TSH6-M5M
JOINT
1
25
91312-03008
BOLT HEX,SOCKET HEAD
8
26
91312-03010
BOLT HEX,SOCKET HEAD
4
27
91312-03014
BOLT HEX,SOCKET HEAD
2
28
91312-04012
BOLT HEX,SOCKET HEAD
16
29
91312-05008
BOLT HEX,SOCKET HEAD
2
30
91312-05014
BOLT HEX,SOCKET HEAD
4
31
91312-05020
BOLT HEX,SOCKET HEAD
4
32
91317-03008
BOLT HEX,SOCKET HEAD
4
33
91317-04014
BOLT HEX,SOCKET HEAD
4
34
92902-05200
WASHER,PLAIN
4
35
95302-04600
NUT HEXAGON
8
11
16
5
17
34
30
10
13
9
32
7
30
4
18
34
30
31
23
8
3
20
4
34
34
19
6
30
26
30
33
21
27
1
2
28
18
30
35
31
28
23
2
22
19
31
35
15
22
12
31
14
24
25
29
30
24
25
29
PU Assy A / B (DS)
Matrix
11
16
5
17
34
30
10
13
9
32
7
30
4
18
34
30
31
23
8
3
20
4
34
34
19
6
30
26
30
33
21
27
1
2
28
18
30
35
31
28
23
2
22
19
31
35
15
22
12
31
14
24
25
29
30
24
25
29
KMK-1803
13-6
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KHY-M921G-01
BRKT.,DOG
1
2
KHY-M921N-01
JOINT A
2
3
KKE-M921D-00
BELT 291-3GT-15
1
4
KLW-M9201-A0
DRIVE UNIT ASSY.
2
5
KLW-M9203-G0
STAY ASSY.
1
6
KLW-M9204-A0
TENTIONER ASSY.
1
7
KLW-M9205-A0
PULLEY ASSY.
1
8
KLW-M9206-A0
MOTOR ASSY.
1
9
KLW-M9207-A0
SENSOR SUB ASSY.
1
10
KLW-M9208-A0
MOTOR ASSY.
1
11
KLW-M9209-A0
SENSOR SUB ASSY.
1
12
KLW-M920B-00
STAY
1
13
KLW-M920C-00
PLATE,PU BASE
1
14
KLW-M920N-00
MATRIX PLATE
1
15
KLW-M920P-00
MATRIX PLATE
1
16
KLW-M9210-C0
MATRIX PU ASSY.A
1
17
KLW-M9210-D0
MATRIX PU ASSY.B
1
18
KLW-M9217-00
BALL BUSH
2
19
KLW-M9218-00
SHAFT
2
20
KLW-M921E-00
BELT 852-3GT-15
1
21
KLW-M921H-02
PLATE,DOG
1
22
KLW-M921T-00
BOLT
8
23
KLW-M9221-01
DAMPER
2
24
KLW-M92U0-A0
MATRIX PIN ASSY.
2
25
90990-28J113
WASHER,PLAIN
8
26
91312-04006
BOLT HEX,SOCKET HEAD
2
27
91312-04008
BOLT HEX,SOCKET HEAD
2
28
91312-04010
BOLT HEX,SOCKET HEAD
4
29
91312-05010
BOLT HEX,SOCKET HEAD
8
30
91312-05012
BOLT HEX,SOCKET HEAD
24
31
91312-05016
BOLT HEX,SOCKET HEAD
16
32
91312-06020
BOLT HEX,SOCKET HEAD
6
33
92902-04200
WASHER,PLAIN
2
34
92902-05200
WASHER,PLAIN
16
35
95602-10100
NUT,S/L
8
