SpecificationsDQ12 Series Sensor
06-May-25page8of13 © Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
•
•
•
•
•
•
Polarized Retroreflective Retroreflective
Excess Gain Beam Pattern Excess Gain Beam Pattern
1
10
100
0.1 m
0.33'
0.01 m
0.03'
1 m
3.3'
10 m
33'
1000
DISTANCE
DQ12 LP..
EXCESS GAIN
2.5 m
2.0 m 1.5 m 1.0 m 0.5 m 0
0
10 mm
20 mm
30 mm
40 mm
10 mm
20 mm
30 mm
40 mm
0
0.4"
0.8"
1.2"
0.4"
0.8"
1.2"
1.6"
1.6"
DISTANCE
1.64' 3.28' 4.92' 6.56'
8.20'
DQ12 LP..
1
10
100
0.1 m
0.33'
0.01 m
0.03'
1 m
3.3'
10 m
33'
1000
DISTANCE
DQ12 LV..
EXCESS GAIN
2.5 m 3.0 m 3.5 m 2.0 m 1.5 m 1.0 m 0.5 m 0
0
20 mm
40 mm
60 mm
20 mm
40 mm
60 mm
0
0.8"
1.6"
2.4"
0.8"
1.6"
2.4"
DISTANCE
DQ12 LV..
1.64' 3.28' 4.92' 6.56' 8.20' 9.84' 11.48'
Fixed-field focus and spot sizes are typical. Performances are based on the use of a 90% reflectance white test card.*
Fixed Field -- 15 mm Fixed Field -- 30 mm Fixed Field -- 50 mm
1
10
100
10 mm
0.4"
100 mm
4.0"
1000 mm
40.0"
1 mm
0.04"
1000
DISTANCE
Q12..FF15DQ12..FF15
EXCESS GAIN
1
10
100
10 mm
0.4"
100 mm
4.0"
1000 mm
40.0"
1 mm
0.04"
1000
DISTANCE
DQ12..FF30
EXCESS GAIN
1
10
100
10 mm
0.4"
100 mm
4.0"
1000 mm
40.0"
1 mm
0.04"
1000
DISTANCE
DQ12..FF50
EXCESS GAIN
Standard Models:
Ø 0.5 mm spot size at 7 mm focus
Ø 1.5 mm spot size at 15 mm cutoff
* Using 18% gray test card: cutoff distance will be
95% of value shown. Using 6% black test card:
cutoff distance will be 90% of value shown.
Standard Models:
Ø 1 mm spot size at 15 mm focus
Ø 2.5 mm spot size at 30 mm cutoff
* Using 18% gray test card: cutoff distance will be
90% of value shown. Using 6% black test card:
cutoff distance will be 80% of value shown.
Standard Models:
Ø 1 mm spot size at 15 mm focus
Ø 4 mm spot size at 50 mm cutoff
* Using 18% gray test card: cutoff distance will be
80% of value shown. Using 6% black test card:
cutoff distance will be 60% of value shown.
06-May-25 page9of13
DQ12 Series Sensor
© Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
Chapter Contents
Cordsets ............................................................................................................................................................................................................... 9
Brackets ............................................................................................................................................................................................................. 10
Apertures............................................................................................................................................................................................................ 10
Cordsets
3-pin Single-Ended Threaded M8 Female Cordsets
Model Length Style Dimensions Pinout(Female)
PKG3M-2 2m(6.56ft)
Straight
ø 9.5
35 Typ.
M8 x 1
7 mm
58 mm
4.3 mm Dia
4
3
1
1=Brown
3=Blue
4=Black
PKG3M-4 4 m (13.12 ft)
PKG3M-5 5 m (16.4 ft)
PKG3M-7 7m(22.96ft)
PKG3M-9 9m(29.52ft)
PKG3M-10 10m(32.81ft)
PKW3M-2 2m(6.56ft)
Right-Angle
ø 9.5
28 Typ.
20 Typ.
M8 x 1
7 mm
58 mm
4.3 mm Dia
PKW3M-5 5m(16.40ft)
PKW3M-9 9m(29.53ft)
4-PinThreadedM8Cordsets—SingleEnded
Model Length Style Dimensions Pinout (Female)
PKG4M-2
2.04 m (6.68
ft)
Straight
ø 9.5
35 Typ.
M8 x 1
4
3
1
2
1 = Brown
2 = White
3 = Blue
4 = Black
PKG4M-5 5 m (16.4 ft)
PKG4M-9
9.04 m (29.6
ft)
PKW4M-2 2 m (6.56 ft)
Right Angle
ø 9.5
28 Typ.
20 Typ.
M8 x 1
1
2
3
4
PKW4M-5 5 m (16.4 ft)
PKW4M-9 9 m (29.5 ft)
Accessories
Chapter 4
AccessoriesDQ12 Series Sensor
06-May-25page10of13 © Banner Engineering Corp. All rights reserved.
www.bannerengineering.com
•
•
•
•
4-PinThreadedM12Cordsets—SingleEnded
Model Length Style Dimensions Pinout (Female)
MQDC-406 2 m (6.56 ft)
Straight
44 Typ.
ø 14.5
M12 x 1
2
3
4
1
5
1 = Brown
2 = White
3 = Blue
4 = Black
5 = Unused
MQDC-415 5 m (16.4 ft)
MQDC-430 9 m (29.5 ft)
MQDC-450 15 m (49.2 ft)
MQDC-406RA 2 m (6.56 ft)
Right-Angle
32 Typ.
[1.26"]
30 Typ.
[1.18"]
ø 14.5 [0.57"]
M12 x 1
1
2
3
4
MQDC-415RA 5 m (16.4 ft)
MQDC-430RA 9 m (29.5 ft)
MQDC-450RA 15 m (49.2 ft)
Brackets
SMBQ12T
Right-anglebracket
20-ga.300seriesstainlesssteel
Hole center spacing:AtoB=7.6
Hole size:A=3.5x8.1,B=ø3.2
11
34
34
Ø3.3
4 X
SMBQ12A
Adjustableright-anglebracket
20-ga.300seriesstainlesssteel
Hole center spacing:AtoB=7.6
Hole size:A=3.5x8.1,B=ø3.2
11
34
34
Ø3.3
Ø3.2
Apertures
Opposed-modesensors(standardmodelsonly)maybefittedwithaperturestonarroworshapethesensor’seffectivebeam
tomorecloselymatchthesizeorprofileoftheobjectsbeingsensed.Acommonexampleisusing“line”(or“slot”)type
apertures to sense thread.
NOTE: The use of apertures will reduce the sensing range (see table below).
