Windows XP Embedded / Installation Manual Ausgabe 10/2014 Edition
7
Overview Machine and Vision Computer types
X2 X3 X4 X4I SX1/SX2 SX4 D-series
SIMATIC BoxPC 627,
two-computer operation
X
X
X
X
SIMATIC BoxPC
627B/627C,
two-computer operation
X
X
X
X
SIMATIC BoxPC
627B/627C,
one-computer operation
X X
SIMATIC BoxPC
827B/827C,
one-computer operation
X
X
X
X
X
IBase PC
ABP102-A/ABP402-A,
one-computer operation
X
Table 2-1: Overview Machine and Vision Computer types
The Windows XP Embedded operation system is supported in the following combinations:
– Windows XP Embedded SP2: BoxPC 627/627B/827B
– Windows Embedded Standard (XPe SP3): BoxPC 627C/827C
– Windows XP Embedded SP3: IBase ABP 102-A/ABP 402-A
Windows XP Embedded / Installation Manual Ausgabe 10/2014 Edition
8
3 Prerequisites for Installation
3.1 Software Components
Standard package Software SIPLACE Station as of version 605.03 SP1:
SR 605.03 SP1, item no. [00140001-06] or
Standard package Software SIPLACE Station as of version 704.01:
SR 704.01, item no. [00388544-01]
3.2 Hardware Components of the Computer System for the
Machine/Vision Computer
3.2.1 SIPLACE X-Serie, SX-Series and D-Series Hardware Components
3.2.1.1 Machine/Vision Computer (in Two-Computer Operation)
Name SIMATIC BoxPC 627
CPU / clock frequency Pentium M 760 / 2 GHz
RAM 1 GB
Hard disk Yes
External DVD drive Yes (1 per machine)
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 3-1: Machine/Vision computer hardware SIPLACE X-series
Name SIMATIC BoxPC 627B
CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz
RAM 1 GB
Harddisk Yes
External DVD drive Yes (1 per machine)
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 3-2: Machine/Vision computer hardware SIPLACE X-series
Windows XP Embedded / Installation Manual Ausgabe 10/2014 Edition
9
Name SIMATIC BoxPC 627C
CPU / clock frequency Intel® Celeron® P4505 / 1,87 GHz
RAM 1 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 3-3: Machine/Vision computer hardware SIPLACE X-series
3.2.1.2 Machine/Vision Computer (in One-Computer Operation)
Name SIMATIC BoxPC 627B
CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz
RAM 1 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and
external USB hub
Yes
Network 2x 100 MBit
Table 3-4: Machine/Vision computer hardware SIPLACE SX1/2 and D-series
Name SIMATIC BoxPC 627C
CPU / clock frequency Intel® Celeron® P4505 / 1.87 GHz
RAM 1 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 3-5: Machine/Vision computer hardware SIPLACE SX1/2 and D-series
