KLC-100_YSi-X_HD_pl.pdf - 第6页
3 1 Base Frame Base KLC-1304 5 20 26 26 26 26 26 26 13 26 21 21 4 3 16 24 28 1 1 34 1 1 34 28 28 12 12 28 28 14 14 2 14 14 26 26 13 27 30 30 7 7 25 25 32 31 31 19 18 35 35 35 26 26 26 17 26 29 29 22 23 23 32 35 33 33 9 9…
2
1
Base Shield / UPS Stay
Base
KLC-1208
35
35
35
35
20
20
22
20
22
35
22
35
35
35
35
17
35
35
35
35
35
35
35
35
35
35
27
35
35
3
34
34
34
34
34
34
34
14
14
45
45
33
32
25
24
23
34
29
30
30
35
35
35
35
35
35
35
35
19
19
18
35
35
2
5
7
6
8
8
4
16
9
9
1
34
34
34
34
21
13
13
34
34
28
28
12
15
31
35
35
35
35
35
35
35
35
10
10
19
26
35
35
35
40
43
43
41
37
39
43
46
42
46
42
44
36
38
11
13
13
22
22
35
35
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLC-M11E1-00 PLATE,SHIELD B1 1
2 KLC-M11E2-00 PLATE,SHIELD B2 1
3 KLC-M11E3-00 PLATE,SHIELD B3 1
4 KLC-M11E4-00 PLATE,SHIELD B4 1
5 KLC-M11E5-00 PLATE,SHIELD B5 1
6 KLC-M11E6-00 PLATE,SHIELD B6 1
7
KLC-M11E7-00
PLATE,SHIELD B7 1
8
KLC-M11E8-00 PLATE,SHIELD B8 2
9 KLC-M11E9-00 PLATE,SHIELD B9 2
10 KLC-M11EA-00 PLATE,SHIELD BA 2
11 KLC-M11EB-00 PLATE,SHIELD BB 1
12 KLC-M11EC-00 PLATE,SHIELD BC 1
13 KLC-M11ED-00 PLATE,SHIELD BD 4
14 KLC-M11EE-00 PLATE,SHIELD BE 2
15 KLC-M11EF-00 PLATE,SHIELD BF 1
16 KLC-M11EG-00 PLATE,SHIELD BG 1
17 KLC-M11EH-00 PLATE,SHIELD BH 1
18 KLC-M11EJ-00 PLATE,SHIELD BJ 1
19 KLC-M11EK-00 PLATE,SHIELD BK 3
20 KLC-M11EL-00 PLATE,SHIELD BL 3
21 KLC-M11EM-00 PLATE,SHIELD BM 1
22 KLC-M11EN-00 PLATE,SHIELD BN 5
23 KLC-M11EP-00 PLATE,SHIELD BP 1
24 KLC-M11ER-00 PLATE,SHIELD BR 1
25 KLC-M11ES-00 PLATE,SHIELD BS 1
26 KLC-M11ET-00 PLATE,SHIELD BT 1
27 KLC-M11EV-00 PLATE,SHIELD BV 1
28 KLC-M11EW-00 PLATE,SHIELD BW 2
29 KLC-M11EX-00 PLATE,SHIELD BX 1
30 KLC-M11EY-00 PLATE,SHIELD BY 2
31 KLC-M11F1-00 BRKT.,SHIRLD BM 1
32 KLC-M11F2-00 BRKT.,HNS. 1 1
33 KLC-M11F3-00 BRKT.,HNS. 2 1
34 KLC-M11FA-00 BOLT,BUTTON HEAD 41
35 KLC-M11FB-30 BOLT,BUTTON HEAD 147
36 KLC-M1151-00 BRACKET1,UPS 1
37 KLC-M1152-00 BRACKET2,UPS 1
38 KLC-M1153-00 BRACKET3,UPS 1
39 KLC-M1154-00 BRACKET4,UPS 1
40 KKH-M658E-01 LABEL UPS CAUTION 1
41 KGA-M658E-11 SEAL,UPS 2 1
42 KKE-M111M-00 PLATE,CLAMP 3
43 97602-04306 SCREW,BIN.HEAD W/W. 8
44 97602-05310 SCREW,PAN HEAD W/W 5
45 90990-01J065 BOLT,HEX.SOCKET HEAD 10
46 91312-05010 BOLT HEX.SOCKET HEAD 6 M5X10
3
1
Base Frame
Base
KLC-1304
5
20
26
26
26
26
26
26
13
26
21
21
4
3
16
24
28
11
34
11
34
28
28
12
12
28
28
14
14
2
14
14
26
26
13
27
30
30
7
7
25
25
32
31
31
19
18
35
35
35
26
26
26
17
26
29
29
22
23
23
32
35
33
33
9
9
8
8
10
10
6
20
1
15
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLC-M11G1-00 FRAME L 1
2 KLC-M11G2-00 FRAME R 1
3 KLC-M11G3-00 SIDE BOX L 1
4 KLC-M11G4-00 SIDE BOX R 1
5 KLC-M11G5-A0 FRAME,CENTER ASSY 1
6 KLC-M11G5-01 FRAME,CENTER 1
7 KLC-M11GG-00 PLATE G 2
8 KLC-M11GH-00 PLATE1,NUT 4
9 KLC-M11GJ-00 PLATE2,NUT 4
10 KLC-M11GK-00 PLATE3,NUT 4
11 KLC-M1158-00 NYLOCK BOLT (M12X30) 16
12 90990-21J001 PIN 8
13
KLC-M11M1-01 BRKT.M1 2 OK MJ70213-2012/7/31
KLC-M11M1-00 BRKT.M1 2
14 KLC-M11M2-00 BRKT.M2 4
15
delete MJ70213-2012/7/31
KLC-M11M3-01 BRKT.M3 1
16 KLC-M11M4-00 BRKT.M4 1
17
KLC-M11M5-01 BRKT.M5 1 OK MJ60072-2012/7/17
KLC-M11M5-00 BRKT.M5 1
18 KLC-M11M6-00 BRKT.M6 1
19 KLC-M11M7-00 BRKT.M7 1
20 KLC-M11M8-00 BRKT.M8 2
21 KLC-M11M9-00 BRKT.M9 2
22
KLC-M11MA-01 BRKT.MA 1 OK MJ60072-2012/7/17
KLC-M11MA-00 BRKT.MA 1
23 KLC-M11MB-00 BRKT.MB 2
24 KLC-M11MC-00 BRKT.MC 1
25 99480-06020 PIN,PARALLEL 4
26 91312-04006 BOLT HEX.SOCKET HEAD 36 M4X6
27 91312-04012 BOLT,HEX.SOCKET HEAD 8 M4X12
28 91312-05008 BOLT HEX.SOCKET HEAD 18 M5X8
29 91312-06010 BOLT HEX.SOCKET HEAD 8 M6X10
30 91312-06020 BOLT HEX.SOCKET HEAD 16 M6X20
31 91312-08025 BOLT HEX.SOCKET HEAD 12 M8X25
32 91312-08030 BOLT HEX.SOCKET HEAD 12 M8X30
33 90990-01J038 BOLT,HEX.SOCKET HEAD 8
34 90201-124G9 WASHER,PLAIN 16
35 92902-08200 WASHER,PLAIN 24
1
2
Upper Cover
Cover
KLC-1304
40
40
39
39
39
39
40
3
14
4
39
39
40
40
40
40
40
40
40
40
40
40
40
40
40
27
15
42
20
26
28
21
39
39
39
39
39
39
7
5
9
2
17
39
44
44
23
43
24
25
22
1
8
6
10
41
19
16
18
40
13
12
11
39
39
37
37
36
36
35
35
34
38
38
38
38
38
38
30
32
33
29
31
37
37
35
35
36
36
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLC-M13N1-00 COVER 1 ASSY. 1
2 KLC-M13N2-00 COVER 2 ASSY. 1
3 KLC-M13K3-00 COVER,3 1
4 KLC-M13N4-00 COVER 4 ASSY. 1
5 KLC-M13N5-00 COVER,CTR. L ASSY. 1
6 KLC-M13N6-00 COVER,CTR. R ASSY. 1
7 KLC-M13N7-00 COVER 7 L ASSY. 1
8 KLC-M13N8-00 COVER 7 R ASSY. 1
9 KLC-M13NA-00 COVER,8 L ASSY. 1
10 KLC-M13NB-00 COVER,8 R ASSY. 1
11 KLC-M13KC-00 COVER,ROOF RH. 1
12 KLC-M13KD-00 COVER,ROOF CTR. 1
13 KLC-M13NC-00 COVER,ROOF L ASSY. 1
14 KLC-M13KG-00 COVER,G 1
15 KLC-M13KH-00 COVER,H 1
16 KLC-M13KL-00 COVER,L 1
17 KLC-M13KM-00 COVER,DOOR FR. 1
18 KLC-M13KN-00 COVER,DOOR FR. UPR. 1
19 KLC-M13KP-00 COVER,DOOR RR. 1
20 KLC-M13K9-00 BRKT.,KB 1
21 KLC-M13KA-00 COVER,SW 1
22 KLC-M13KT-00 COVER,MONITOR 1
23 KLC-M13KV-00 HANDLE 1
24 KLC-M13M2-00 DAMPER,DOOR 1
25 KLC-M13M3-00 PLATE,STRIKE 1
26 KLC-M13D6-00 SEAL 1(YSi-X) 1
27 KLC-M13D7-00 SEAL 2(YAMAHA) 1
28 KLC-M13KX-00 SEAL, X-RAY KEY 1
29 KLC-M13J7-00 STAY,COVER ROOF 1 1
30 KLC-M13J8-00 STAY,COVER ROOF 2 1
31 KLC-M13J9-00 STAY,COVER ROOF 3 1
32 KLC-M13JB-00 STAY,COVER ROOF 4 1
33 KLC-M13JC-00 STAY,COVER ROOF R 1
34 KLC-M13JD-00 STAY,COVER ROOF L 1
35 KLC-M13JG-00 BRKT.,COVER SIDE 4
36 90990-23J027 GROMMET 14
37 91312-04006 BOLT HEX.SOCKET HEAD 8 M4X6
38 91312-04010 BOLT HEX.SOCKET HEAD 34 M4X10
39 90990-01J065 BOLT,HEX.SOCKET HEAD 53
40 90990-12J001 SCREW BIN.HEAD W/W 73
41 90990-12J007 SCREW BIN.HEAD W/W 2
42 90990-46J010 BOLT,THIN HEAD 2
43 91312-04014 BOLT,HEX.SOCKET HEAD 2 M4X14
44 98702-04006 SCREW FLAT HEAD 6
