16.カバー(DEAK)

16.Cover(DEAK)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考

材質

No. Drg.No. & Code No. QTY Description Rating Remarks

Materials

1 DEAK1220 1 BKT, SW BKT SW FE

2 DEAK1080 1 DUCT, WIRING ﾀﾞｸﾄ配線 FE

3 DETR3450 1 NUT ﾅｯﾄ FE

4 WWM0210 3 SEAL ｼｰﾙ PL

5 DEAK3013 1 COVER, OVERALL ｶﾊﾞｰ全体 FE

7 DEAK3030 2 DUCT, WIRING ﾀﾞｸﾄ配線 FE

9 DEAK3380 1 DOOR 扉 PL

10 DEAK3060 1 ﾄﾘｹﾂﾀﾞｲ AL

11 DEAK1201 1 BKT BKT FE

12 DEAK1211 1 BKT BKT FE

13 DEAK3090 2 BKT BKT FE

14 DEAK3280 1 COVER ｶﾊﾞｰ FE

15 DEAK3120 1 BKT, PIVOT BKT 支点 FE

16 DEAK3130 1 BKT, PIVOT BKT 支点 FE

17 DEAK3140 1 BKT BKT FE

20 DEAK3170 1 BKT BKT FE

21 DEAK3180 1 HINGE 蝶番 OT

22 DEAK3190 1 PLATE ﾌﾟﾚｰﾄ FE

23 H3051B 1 COVER 蓋 MG-5 OT

24 M1010M 2 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-76S OT

25 S31975 1 SW, LIMIT SW ﾘﾐｯﾄ XCS-Z13 OT

26 S31992 3 SW, LIMIT SW ﾘﾐｯﾄ XCS-PA791 OT

28 H5120C 4 BOLT ﾎﾞﾙﾄ TM-171-B1 OT

29 T5012M 1 HANDLE 取手 THA-407 OT

30 T1065Z 2 DAMPER ﾀﾞﾝﾊﾟ KMF80-20 OT

31 S2010K 1 LAMP ﾗﾝﾌﾟ FT11001-GL16(60Hz) 仕様選択部品 Specified parts selection OT

32 S2010F 1 LAMP ﾗﾝﾌﾟ FT11001-GL15(50Hz) 仕様選択部品 Specified parts selection OT

33 DEPZ3010 1 NAMEPLATE 銘板 PL

34 KPA0890 1 SEAL ｼｰﾙ PL

35 KPA0900 1 NAMEPLATE, CAUTION 銘板注意 PL

36 IPK5480 2 SEAL ｼｰﾙ Japanese PL

37 IPK5490 2 SEAL ｼｰﾙ English PL

38 IPK5500 2 SEAL ｼｰﾙ French PL

39 K5203A

SCREW, TRUSS

小ﾈｼﾞﾄﾗｽ M3X6L FE

40 K5170A SCREW, C/R COUNTERSUNK 小ﾈｼﾞ十穴皿 M3X12L FE

41 K5208A

SCREW, TRUSS

小ﾈｼﾞﾄﾗｽ M4X6L FE

42 K5211A

SCREW, TRUSS

小ﾈｼﾞﾄﾗｽ M4X12L FE

43 K5212A

SCREW, TRUSS

小ﾈｼﾞﾄﾗｽ M4X15L FE

44 H5296C 6

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X45 FE

XP-241E PARTS LIST ver03

16 - 2

16.カバー(DEAK)

16.Cover(DEAK)

16.カバー(DEAK)

16.Cover(DEAK)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考

材質

No. Drg.No. & Code No. QTY Description Rating Remarks

Materials

45 K5215A

SCREW, TRUSS

小ﾈｼﾞﾄﾗｽ M5X10L FE

46 K5172A

SCREW, TRUSS

小ﾈｼﾞﾄﾗｽ M5X15L FE

47 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X15L FE

48 H5295A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X35L FE

49 K5216C

SCREW, TRUSS

小ﾈｼﾞﾄﾗｽ M6X15L FE

50 K5262A

SCREW, HEX SOCKET BUTTON

小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M6X10L FE

51 H5321A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X12L FE

52 H5340A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X15L FE

53 W1022A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 4M/M FE

54 W1023A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

55 W1024A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 6M/M FE

56 W1025A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 8M/M FE

57 W1043A WASHER, FLAT ﾜｯｼｬ平 4W-4 FE

58 W1044A WASHER, FLAT ﾜｯｼｬ平 4W-5 FE

59 W1051A WASHER, FLAT ﾜｯｼｬ平 6M/MX1.6X125(1W-6) FE

60 W1052A WASHER, FLAT ﾜｯｼｬ平 8M/MX1.6X17(1W-8) FE

61 N1076A

NUT, HEX

ﾅｯﾄ六角

M3 P=0.5 FE

62 N1082A

NUT, HEX

ﾅｯﾄ六角

M5 P=0.8 FE

63 N1089A

NUT, HEX

ﾅｯﾄ六角

M8 P=1.25 FE

64 DEAK3390 1 BKT BKT AL

65 DEAK3270 1 COVER ｶﾊﾞｰ FE

66 DEAK1191 1 BKT BKT FE

67 ADCPA8010 1 COVER ACRYLIC ｶﾊﾞｰｱｸﾘﾙ PL

68 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M4X8L FE

69 K5209A SCREW, TRUSS 小ﾈｼﾞﾄﾗｽ M4X8L FE

70 K5209A SCREW, TRUSS 小ﾈｼﾞﾄﾗｽ M4X8L FE

71 K5214A SCREW, TRUSS 小ﾈｼﾞﾄﾗｽ M5X8L FE

72 W1050A WASHER, FLAT ﾜｯｼｬ平 1W-5 FE

73 K5212A 8 SCREW, TRUSS 小ﾈｼﾞﾄﾗｽ M4X15L FE

74 DEAK3370 1 BKT BKT FE

75 H5287A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M4X8L FE

76 W1022A 2 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 4M/M FE

77 W1043A 2 WASHER, FLAT ﾜｯｼｬ平 4W-4 FE

78 DEAK1150 1 BKT, SENSOR BKT ｾﾝｻ FE

79 H5273A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M3X5L FE

80 W1021A 2 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 3M/M FE

81 W1042A 2 WASHER, FLAT ﾜｯｼｬ平 4W-3 FE

82 DEAK3360 1 BKT BKT FE

83 H5287A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M4X8L FE

XP-241E PARTS LIST ver03

16 - 3

16.カバー(DEAK)

16.Cover(DEAK)

16.カバー(DEAK)

16.Cover(DEAK)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考

材質

No. Drg.No. & Code No. QTY Description Rating Remarks

Materials

84 W1022A 2 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 4M/M FE

85 W1043A 2 WASHER, FLAT ﾜｯｼｬ平 4W-4 FE

86 DEAK1160 1 BKT, SENSOR BKT ｾﾝｻ FE

87 H5273A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M3X5L FE

88 W1021A 2 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 3M/M FE

89 W1042A 2 WASHER, FLAT ﾜｯｼｬ平 4W-3 FE

90 S3148Z 1 SW, PHOTOELECTRIC SW 光電 HPJ-T23 OT

91 K5173A 4 SCREW, C/R PAN 小ﾈｼﾞ十穴鍋 M3X10L FE

92 W1021A 4 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 3M/M FE

93 W1040A 4 WASHER, FLAT ﾜｯｼｬ平 3M/MX0.5X7 FE

94 DEAK3200 1 DOOR 扉 PL

95 H1187H 1

PACKING

ﾊﾟｯｷﾝ

AF5(50m) OT

96 T4053H 1 TEAP ﾃｰﾌﾟ T0.18XW19X10M OT

97 K5210A 2

SCREW, C/R TRUSS

小ﾈｼﾞ十穴ﾄﾗｽ

M4X10L FE

98 DEAK3210 1 DOOR 扉 PL

99 T4053H 1 TEAP ﾃｰﾌﾟ OT

100 K5210A 2

SCREW, C/R TRUSS

小ﾈｼﾞ十穴ﾄﾗｽ

M4X10L FE

101 DEAK3220 2 RAIL ﾚｰﾙ AL

102 N1082A 14

NUT, HEX

ﾅｯﾄ六角

M5 P=0.8 FE

103 W1023A 14 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

104 W1044A 14 WASHER, FLAT ﾜｯｼｬ平 4W-5 FE

105 DEAK3230 2

NUT

ﾅｯﾄ FE

106 DEAK3240 3

NUT

ﾅｯﾄ FE

107 DEAK3260 1 HANDLE 取手 FE

108 H5300A 2

BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X15L

FE

109 W1023A 2 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

110 W1004C 4 WASHER ﾜｯｼｬ THA-272-3 FE

111 DEAK3290 1 HANDLE 取手 FE

112 H5300A 2

BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X15L

FE

113 W1023A 2 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

114 W1004C 4 WASHER ﾜｯｼｬ THA-272-3 OT

115 DEAK3300 1 BKT BKT FE

116 N1082A 2

NUT, HEX

ﾅｯﾄ六角

M5 P=0.8 FE

117 W1023A 2 WASHER, LOCK ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

118 W1044A 2 WASHER, FLAT ﾜｯｼｬ平 4W-5 FE

119 DEAK3310 1 SPACER ｽﾍﾟｰｻ AL

120 H5280A 2

BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴

M3X20L FE

121 W1010A 2

WASHER, CONICAL ﾜｯｼｬ皿

M-3-L FE

122 DEAK3320 1 SPACER ｽﾍﾟｰｻ AL

XP-241E PARTS LIST ver03

16 - 4

16.カバー(DEAK)

16.Cover(DEAK)
