- - REF.NO NOTE PARTNO DESCRIPTION Qty 1 400-49016 BREAKERCOVER 1 2 400-48785 RDRIVERBR 1 3 400-45704 RESISTANCE 1 4 400-49509 FANMOTORASM 1 5 #01 HM-0003300-30 FANGUA RD 1 6 400-50012 CARRIERRA…

- -

3. ELECTRICAPPARATUSCOMPONENTS(2)

6 7

1 0

1 1

1 2

1 3

1 5

1 6

1 7

1 4

2 4

1 8

2 3

2 8

2 1 2 2

1 9

2 7

2 5 2 6

1 8

2 9

2 0

1 1

3 3

3 2

3 4 3 6

3 5

3 0

3 1

- -

REF.NO NOTE PARTNO DESCRIPTION Qty

1 400-49016 BREAKERCOVER 1

2 400-48785 RDRIVERBR 1

3 400-45704 RESISTANCE 1

4 400-49509 FANMOTORASM 1

#01

HM-0003300-30 FANGUARD 1

6 400-50012 CARRIERRAIL 1

7 HK-0498500-10 TERMINALBOARD 27

8 400-45701 TRANSFORMER 1

9 400-45714 NOISEFILTER 1

10 400-49276 DRIVERCOVER 1

11 E9567-319-000 EARTHMARK 6

12 400-49274 DRIVERBR 1

13 400-49275 DRIVERBR 1

14 HA-0052400-00 CIRCUITPROTECTOR 1

15 400-48784 PCBBR5D 1

16 HA-0052400-0A CIRCUITPROTECTOR 1

17 HA-0052400-0C CIRCUITPROTECTOR 1

18 400-49165 BREAKERCOVER 2

19 PV-0100060-00 HANDVALVE 1

#01

E2411-723-000 BREAKERCOVERB 1

21 400-48783 MAINSWBR5D 1

#02

400-94907 MAIN_SW_BR_5D 1

23 HA-0058500-00 CIRCUITPROTECTOR 1

24 400-49504 POWERLAMPCABLEASM 1

25 400-45200 I/FCABLEASM 1

#02

400-96122 5DI/FCABLEASM 1

27 400-49489 ACPOWERINPUTCABLEASM 1

#01

E2410-723-000 BREAKERCOVERA 1

29 E2106-716-000 POWERSUPPLYSEAL 1

30 SM-6032502-TN SCREW 2

31 SL-4034091-SC SCREWM3X40 2

32 SL-4030891-SC SCREWM3X8 2

33 SM-0040801-SC SCREW 2

34 SL-4030881-SC SCREWM3L=8 2

35 SL-4030881-SC SCREWM3L=8 4

#02

SM-4860501-SB SCREWM2.6L=5 2

- -

4. COVERCOMPONENTS

2 4 2 734

5 6

8 1 2

1 3 1 4

1 5 1 6

1 8 1 9

5 4

1 7

2 0 2 3

2 8

2 9 3 0

4 8 4 9

4 6 4 7

5 2 5 3

4 4 4 5

4 0 4 2

3 8 3 9

3 6 3 7

5 0 5 1

3 1 3 5

4 3
