01 1 1-002 ࡃ࡞ࠢࡈࠖ࠳ BULK FEEDER Fig. 3-2 ៝ㅍࠪࡘ࠻ㇱ Transfer Chute Section 14 13 53 23 12 33 52 39 15 11 29 27 28 31 32 26 46 66 67 65 48 47 62-2 59 58 57 56 45 43 51 50 41 41 42 36 40 40 22 16 See Fig.3-1 Key No.1 Fig.3-2 C…
0002-001
3-1
⇟ภ ㇱຠ⇟ภ ㇱ ຠ ฬ ᢙ㊂
⠨
Key No. PART No. PART NAME Q'ty REMARKS
CB-4195
CB-4197
CB-4195T
CB-4197T
1 630 085 0338 FRAME(CASSETTE BODY) 1 1 1 1 685DL-01B-001
1 -1 630 037 0294 PIN,LOCATE 1 1 1 1 685DL-01H-002
2 630 084 9127 PLATE 1 1 1 1 685DL-01B-144
3 411 034 7208 SCR FLT 3X8 2 2 2 2 M3X8 FLT
4 630 039 3002 PLATE 2 2 2 2 685DL-01B-004
5 630 039 3200 PIN,LOCATE 1 1 1 1 685DL-01B-005
6 630 039 3187 PIN,LOCATE 1 1 1 1 685DL-01B-006
7 411 141 4008 WASHER V 4X9X0.8 2 2 2 2 FW4
8 411 141 2905 WASHER SPR 4 2 2 2 2 SW4
9 411 141 0307 NUT HEX 4 2 2 2 2 M4
11 630 054 4817 PIN,LOCATE 1 1 1 1 685DL-01B-002
12 411 140 7208 SCR FLT 4X6 2 2 2 2 M4X6 FLT
13 630 010 5957 SPRING,COMP 1 1 1 1 685DL-01B-008
14 630 044 3493 LEVER 1 1 1 1 685DL-01B-003
15 630 000 9859 NUT,HEX 1 1 1 1 685DL-01H-001
21 630 054 4800 BRACKET 1 1 685DL-01B-010
22 630 070 7601 BRACKET(GRIP) 1 1 685DL-01B-009
23 411 054 8506 NUT HEX 4 1 1 M4 F
24 411 113 4708 SCR FLT 4X10 1 1 M4X10 FLT
25 630 039 7086 TUBE,WIRING 1 685DL-01H-010
25 630 039 7062 TUBE,WIRING 1 685BL-01H-010
26 411 140 7208 SCR FLT 4X6 2 2 M4X6 FLT
30 630 071 0786 ASSY,BRACKET 1
30 630 073 0388 ASSY,BRACKET 1
31 630 054 4800 BRACKET 1 1 685TD-01B-001
32 630 070 7601 BRACKET(GRIP) 1 1 685TD-01B-002
32 -1 630 085 1526 UNIT,I/O 1 1 685TD-01H-001
33 411 054 8506 NUT HEX 4 1 1 M4 F
34 411 113 4708 SCR FLT 4X10 1 1 M4X10 FLT
35
630 039 7086 TUBE,WIRING 1 685TD-01H-002
35
630 039 7062 TUBE,WIRING 1 685TB-01H-002
36
411 140 7208 SCR FLT 4X6 2 2 M4X6 FLT
ᵈᗧ
NOTE
0111-002
ࡃ࡞ࠢࡈࠖ࠳ BULK FEEDER
Fig. 3-2 ៝ㅍࠪࡘ࠻ㇱ Transfer Chute Section
14
13
53
23
12
33
52
39
15
11
29
27
28
31
32
26
46
66
67
65
48
47
62-2
59
58
57
56
45
43
51
50
41
41
42
36
40
40
22
16
See Fig.3-1
Key No.1
Fig.3-2
CB-4195(P-143-001)
CB-4195(P-142-001)
62-1
61
See Fig.2-5
Key No.1
0111-002
3-2
⇟ภ ㇱຠ⇟ภ ㇱ ຠ ฬ ᢙ㊂
⠨
Key No. PART No. PART NAME Q'ty REMARKS
CB-4195
CB-4197
CB-4195T
CB-4197T
11 630 065 9818 BLOCK 2 2 2 2 685DL-01B-025
12 411 043 5004 SCR PAN 4X8 1 1 1 1 M4X8 PAN
13 411 141 2905 WASHER SPR 4 1 1 1 1 SW4
14 630 000 7619 BOLT,HEX-SCT 1 1 1 1 M4X8
15 630 000 7497 BOLT,HEX-SCT 1 1 1 1 M3X4
16 630 101 0878 LEVER(ASSY LEVER) 1 1 1 1
22 630 065 9825 PIN,GUIDE 1 1 1 1 685DL-01B-026
23 411 002 2600 SCR FLT 3X6 1 1 1 1 M3X6 FLT
26 630 072 5698 ASSY,PLATE 1 1 1 1
27 630 066 5079 PLATE 1 1 685DL-01B-023
27 630 083 8701 PLATE 1 1 685BL-01B-023
28 630 065 9665 PIN,HINGE 1 1 1 1 685DL-01B-022
29 630 065 9795 BOLT 1 1 1 1 685DL-01B-024
31 630 065 9863 PIN,GUIDE 1 1 1 1 685DL-01B-030
32 630 066 6090 SPRING,COMP 1 1 1 1 685DL-01B-029
33 411 035 2707 SCR FLT 4X8 1 1 1 1 M4X8 FLT
36 630 091 2777 HOLDER 1 1 1 1 685DL-01B-047
39
630 085 0420 SPACER 1 1 1 1
T0.05
685UD-11R-001
39
630 085 0437 SPACER 1 1 1 1
T0.07
685UD-12R-001
39
630 085 0413 SPACER 1 1 1 1
T0.1
685UD-13R-001
ᵈᗧ
NOTE
