KLV_YCP10_PartsList.pdf - 第52页
35 7 9 26 2 32 3 1 28 29 22 30 9 12 12 29 21 7 30 8 19 9 23 27 25 14 24 11 2 5 17 5 31 34 6 18 13 1 15 6 33 3 16 20 4 10 CX-Peripheral Camera Section 35 7 9 26 2 32 3 1 28 29 22 30 9 12 12 29 21 7 30 8 19 9 23 27 25 14 2…
Wiping Fabric Roll
Cleaner Section
KLV-1504
7
3
2
6
5
6
5
1
4
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KHT-M3661-00 PIPE,PAPER 530 1 L=530
KGY-M3661-A0 PIPE,PAPER 440 1 L=440
KGY-M3661-B0 PIPE,PAPER 360 1 L=360
KGY-M3661-C0 PIPE,PAPER 260 1 L=260
2
KHT-M36C0-00 ROLL UNIT 530 1 L=530
KHT-M36C0-A2 ROLL UNIT 440 1 L=440
KHT-M36C0-B2 ROLL UNIT 360 1 L=360
KHT-M36C0-C2 ROLL UNIT 260 1 L=260
3
KHT-M3622-00 NOZZLE,VACUUM 530 1 L=530
KHT-M3622-A0 NOZZLE,VACUUM 440 1 L=440
KHT-M3622-B0 NOZZLE,VACUUM 360 1 L=360
KHT-M3622-C0 NOZZLE,VACUUM 260 1 L=260
4
KHT-M3660-00 BENCOT,ROLL 530 1 L=530
KGY-M3660-A0 BENCOT,ROLL 440 1 L=440
KGY-M3660-B0 BENCOT,ROLL 360 1 L=360
KGY-M3660-C0 BENCOT,ROLL 260 1 L=260
KHT-M366S-00 ROLL SET, 530 1 L=530 10SET of parts numbers
KGY-M366S-A0 ROLL SET, 440 1 L=440 10SET of parts numbers
KGY-M366S-B0 ROLL SET, 360 1 L=360 10SET of parts numbers
KGY-M366S-C0 ROLL SET, 260 1 L=260 10SET of parts numbers
5
KHT-M3690-00 ADAPTER,530,R 2 L=530
KHT-M3690-A0 ADAPTER,440,R 2 L=440
KHT-M3690-B0 ADAPTER,360,R 2 L=360
KHT-M3690-C0 ADAPTER,260,R 2 L=260
6
KHT-M3662-A2 ADAPTER,440,L 2 L=440
KHT-M3662-B2 ADAPTER,360,L 2 L=360
KHT-M3662-C2 ADAPTER,260,L 2 L=260
7 91312-03008 BOLT HEX.SOCKET HEAD 22 M3*8
5-5
35
7
9
26
2
32
3
1
28
29
22
30
9
12
12
29
21
7
30
8
19
9
23
27
25
14
24
11
2
5
17
5
31
34
6
18
13
1
15
6
33
3
16
20
4
10
CX-Peripheral
Camera Section
35
7
9
26
2
32
3
1
28
29
22
30
9
12
12
29
21
7
30
8
19
9
23
27
25
14
24
11
2
5
17
5
31
34
6
18
13
1
15
6
33
3
16
20
4
10
KLV-1406
6-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
21
2
90990-01J032
BOLT HEX,SOCKET HEAD
4
3
90990-11J003
SCREW, PAN HEAD W/W
21
4
90KC2-012317
AC SERVO MOTOR
1
5
91312-04005
BOLT HEX,SOCKET HEAD
4
6
91312-04010
BOLT HEX,SOCKET HEAD
4
7
91312-04012
BOLT HEX,SOCKET HEAD
26
8
91312-05006
BOLT HEX,SOCKET HEAD
4
9
91312-05012
BOLT HEX,SOCKET HEAD
8
10
91312-05018
BOLT HEX,SOCKET HEAD
4
11
91312-05035
BOLT HEX,SOCKET HEAD
3
12
KLC-M2818-00
TAPE,LX AXIS 1
2
13
KLV-M653M-00
SENSOR CX ORG ASSY
1
CX ORG
14
KLV-M7508-00
STAY,CAMERA
1
15
KLV-M7509-00
BRKT.,DUCT CX
1
16
KLV-M750A-00
COUPLING 10X14
1
17
KLV-M750B-00
DOG,SENSOR CX
1
18
KLV-M750D-00
BRKT.,SENSOR CX
1
19
KLV-M750E-00
COVER,UNDER
1
20
KLV-M750F-00
COVER,STROKE
1
21
KLV-M750J-00
STAY,CX 2
1
22
KLV-M750K-00
STAY,CX 3
1
23
KLV-M750L-00
PLATE,L
1
24
KLV-M750P-00
STOPPER,CX
1
temporary stopper under shipment
25
KLV-M7511-00
CABLE DUCT,CX
1
26
KLV-M7512-00
TAPE,DUCT CX 1
1
27
KLV-M7513-00
TAPE,DUCT CX 2
1
28
KLV-M7515-00
BRKT.,DUCT CX 2
1
29
91312-06018
BOLT HEX,SOCKET HEAD
8
30
91312-06025
BOLT HEX,SOCKET HEAD
8
31
92902-04200
WASHER,PLAIN
2
32
92902-05200
WASHER,PLAIN
2
33
97602-03308
SCREW PAN HEAD W/WASHER
2
34
98902-04006
SCREW BINDING HEAD
4
35
99480-06012
PIN,PARALLEL
2
2
4
13
13
5
21
25
23
8
18
17
22
1
10
21
7
14
12
3
3
25
4
24
23
7
2
11
19
15
6
12
9
1
9
20
16
22
CX-Drive
Camera Section
2
4
13
13
5
21
25
23
8
18
17
22
1
10
21
7
14
12
3
3
25
4
24
23
7
2
11
19
15
6
12
9
1
9
20
16
22
KLV-1406
6-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-41J156
COLLAR
2
2
90K71-0L0760
LM RAIL,15
2
3
90K80-S15LV0
LM BLOCK
2
4
90K80-S15RV0
LM BLOCK
2
5
91312-04010
BOLT HEX,SOCKET HEAD
8
6
91312-04014
BOLT HEX,SOCKET HEAD
4
7
91312-04016
BOLT HEX,SOCKET HEAD
26
8
91312-04018
BOLT HEX,SOCKET HEAD
4
9
91312-05012
BOLT HEX,SOCKET HEAD
3
10
91312-05016
BOLT HEX,SOCKET HEAD
1
11
91312-05020
BOLT HEX,SOCKET HEAD
4
12
KG2-M2604-00
SUPPORT UNIT
1
13
KGY-M9115-00
DAMPER 2,W
2
14
KLV-M7501-00
FRAME,CX
1
15
KLV-M7503-00
BALL SCREW,CX
1
16
KLV-M7504-00
HOLDER,MOTOR CX
1
17
KLV-M7505-00
HOLDER,BRG. CX
1
18
KLV-M7506-00
HOLDER,BRG. CX 2
1
19
KLV-M7507-00
TABLE,SLIDE
1
20
KLV-M750C-00
BRKT.,DAMPER CX
1
21
KLV-M750G-00
STAY,CX 1
2
22
91312-06020
BOLT HEX,SOCKET HEAD
6
23
91312-06022
BOLT HEX,SOCKET HEAD
8
24
95302-05700
NUT HEXAGON
4
25
99480-06012
PIN,PARALLEL
2
