KLV_YCP10_PartsList.pdf - 第57页
5 8 1 6 4 2 7 3 9 5 8 1 6 4 2 7 3 9 Overview Conveyor Section KL V-1409 7-1 NO Parts_No. Parts_Name Q'ty Remarks Compati Revision_No._date 1 KL V -M91A0-00 CONV . ST AND L ASSY . 1 2 KL V -M91B0-00 CONV . ST AND R A…
30
22
11
1
8
25
18
29
33
9
26
33
6
15
5
3
3
7
4
21
17
16
20
10
7
14
14
13
28
31
12
12
10
24
23
1
32
16
7
15
19
27
31
2
7
MX-Drive
Camera Section
30
22
11
1
8
25
18
29
33
9
26
33
6
15
5
3
3
7
4
21
17
16
20
10
7
14
14
13
28
31
12
12
10
24
23
1
32
16
7
15
19
27
31
2
7
KLV-1406
6-5
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-41J156
COLLAR
2
2
90KC1-012518
AC SERVO MOTOR
1
3
90K71-2L0616
LM RAIL,15
2
4
90K80-S15LV0
LM BLOCK
2
5
90K80-S15RV0
LM BLOCK
2
6
91312-04012
BOLT HEX,SOCKET HEAD
11
7
91312-04014
BOLT HEX,SOCKET HEAD
20
8
91312-04016
BOLT HEX,SOCKET HEAD
22
9
91312-05014
BOLT HEX,SOCKET HEAD
6
10
91312-05016
BOLT HEX,SOCKET HEAD
2
11
91312-05020
BOLT HEX,SOCKET HEAD
4
12
91312-05025
BOLT HEX,SOCKET HEAD
6
13
91312-05040
BOLT HEX,SOCKET HEAD
2
14
91312-05065
BOLT HEX,SOCKET HEAD
6
15
KG2-M2604-00
SUPPORT UNIT
1
16
KGY-M9115-00
DAMPER 2,W
2
17
KLV-M7506-00
HOLDER,BRG. CX 2
1
18
KLV-M7601-00
FRAME,MX
1
19
KLV-M7603-00
BRKT.,MOTOR MX
1
20
KLV-M7604-00
HOLDER,BRG. MX
1
21
KLV-M7605-00
PLATE,MX
1
22
KLV-M7606-00
HOLDER,NUT MX
1
23
KLV-M7607-00
BRKT.,CAMERA
1
24
KLV-M760C-00
COVER,TOP
1
25
KLV-M760D-00
STAY,MX
1
26
KLV-M760E-00
PLATE,BACK
1
27
KLV-M760G-00
COUPLING 8X10
1
28
KLV-M7610-00
BALL SCREW,MX
1
29
91312-06030
BOLT HEX,SOCKET HEAD
5
30
92902-06200
WASHER,PLAIN
5
31
98902-04008
SCREW BINDING HEAD
4
32
99480-04008
PIN,PARALLEL
2
33
99480-06012
PIN,PARALLEL
3
5
8
1
6
4
2
7
3
9
5
8
1
6
4
2
7
3
9
Overview
Conveyor Section
KLV-1409
7-1
NO
Parts_No.
Parts_Name
Q'ty
Remarks
Compati
Revision_No._date
1
KLV-M91A0-00
CONV. STAND L ASSY.
1
2
KLV-M91B0-00
CONV. STAND R ASSY.
1
3
KLV-M91C0-00
CONV. F ASSY.
1
4
KLV-M91D0-00
CONV. R ASSY.
1
5
KLV-M91E0-00
W CABLE DUCT ASSY.
1
6
KLV-M91F0-00
EXIT STOPPER ASSY.
1
<NORMAL> in case of "Right to Left"
7
KLV-M91G0-00
EXIT ST. SENS. ASSY.
1
<NORMAL> in case of "Right to Left"
8
KLV-M91F0-00
EXIT STOPPER ASSY.
1
<OPTION> in case of "Left to Right"
9
KLV-M91G0-00
EXIT ST. SENS. ASSY.
1
<OPTION> in case of "Left to Right"
1
32
40
25
45
15
14
46
16
46
26
38
19
20
5
27
35
34
39
42
43
11
6
33
3
21
12
24
41
13
18
37
33
45
35
42
22
49
8
17
50
38
28
9
47
2
4
38
36
23
10
25
48
7
33
35
31
52
51
44
53
30
54
42
29
1
32
40
25
45
15
14
46
16
46
26
38
19
20
5
27
35
34
39
42
43
11
6
33
3
21
12
24
41
13
18
37
33
45
35
42
22
49
8
17
50
38
28
9
47
2
4
38
36
23
10
25
48
7
33
35
31
52
51
44
53
30
54
42
29
Belt Drive
Conveyor Section
KLV-1408
7-2
NO
Parts_No.
Parts_Name
Q'ty
Remarks
Compati
Revision_No._date
1
KLV-M91A0-00
CONV. STAND L ASSY.
1
see page "7-1".
2
KLV-M9101-00
LEG,FL
1
3
KLV-M9102-00
LEG,R
1
4
KLV-M9103-00
STAY,GUIDE
1
5
KLV-M9104-00
BRKT.,BEARING L
1
6
KLV-M9105-00
PLATE,NUT HOLDER L
1
7
KLV-M9106-00
BRKT.,SENSOR L
1
8
KLV-M9107-00
BRKT.,W MOTOR
1
9
KLV-M9108-00
PLATE,NUT
1
10
KLV-M9109-00
BLOCK
1
11
KLV-M911D-00
HOLDER,BRG.
1
12
KLV-M9A00-00
BALL SCREW,W
1
13
KHT-M9104-00
GUIDE,WM
1
Left side of "R & L" pair : see page "7-3".
14
KG7-M9113-01
PULLEY 3
1
15
KGT-M912D-00
PULLEY
1
16
KHW-M9137-00
COLLAR,BRG.
1
17
KHW-M9139-00
PLATE,BRG.
1
18
KHY-M9152-00
SPACER
1
19
KHY-M9153-00
DAMPER B
1
20
KHY-M9154-00
SPACER
1
21
KJX-M9112-00
BELT,W
1
22
KLD-M9119-00
DAMPER A
1
23
90K2E-2E4527
AC SERVO MOTOR
1
24
90990-25J024
BEARING
2
25
90990-28J018
WASHER,PLAIN
2
26
90990-28J093
WASHER,PLAIN
1
27
90933-01J000
BEARING
1
28
90933-01J200
BEARING
1
29
90112-02J010
BOLT HEX,SOCKET HEAD
2
30
91312-03008
BOLT HEX,SOCKET HEAD
2
31
91312-03010
BOLT HEX,SOCKET HEAD
4
32
91312-04008
BOLT HEX,SOCKET HEAD
1
33
91312-04010
BOLT HEX,SOCKET HEAD
7
34
91312-04012
BOLT HEX,SOCKET HEAD
3
35
91312-04016
BOLT HEX,SOCKET HEAD
13
36
91312-04025
BOLT HEX,SOCKET HEAD
1
37
91312-05010
BOLT HEX,SOCKET HEAD
1
38
91312-05014
BOLT HEX,SOCKET HEAD
6
39
91312-05016
BOLT HEX,SOCKET HEAD
2
40
91312-05025
BOLT HEX,SOCKET HEAD
1
41
91312-05040
BOLT HEX,SOCKET HEAD
1
42
91312-06030
BOLT HEX,SOCKET HEAD
6
43
91312-06035
BOLT HEX,SOCKET HEAD
2
44
92902-03200
WASHER,PLAIN
2
45
92902-05200
WASHER,PLAIN
2
46
92A08-04306
SCREW SET
4
47
95302-04600
NUT HEXAGON
1
48
99480-05012
PIN,PARALLEL
1
49
99480-06014
PIN,PARALLEL
1
50
90K81-200004
CAP C4
8
51
90990-11J003
SCREW, PAN HEAD W/W
1
52
$NK-3N
NYLON CLIP
1
53
KLV-M654H-00
SENS.BACKUPPIN ASSY
1
SQ080-B : Receiver side : JCN6 BACKUP
54
KLS-M1917-00
SLIT
1
Pair : see page "7-3".
