10 6 6 1 9 3 6 2 7 10 9 4 9 8 8 5 8 9 9 10 6 6 1 9 3 6 2 7 10 9 4 9 8 8 5 8 9 9 Controller Controller Section KL V-1504 8-1 NO Parts_No. Parts_Name Q_ty Remarks Compati Revision_No._date 1 KLF-M4209-91 SYSTEM UNIT ASSY 1…

100%1 / 67
2
3
18
15
17
12
9
14
16
23
21
1
12
4
10
20
11
9
8
11
9
13
19
7
24
12
22
5
6
12
2
3
18
15
17
12
9
14
16
23
21
1
12
4
10
20
11
9
8
11
9
13
19
7
24
12
22
5
6
12
Duct & Exit Devices
Conveyor Section
KLV-1410
7-9
NO
Parts_No.
Parts_Name
Q'ty
Remarks
Compati
Revision_No._date
1
KLV-M91E0-00
W CABLE DUCT ASSY.
1
2
KLV-M91F0-00
EXIT STOPPER ASSY.
1
3
KLV-M91G0-00
EXIT ST. SENS. ASSY.
1
4
KLV-M91E1-00
BRKT.,W CABLE DUCT 1
1
5
KLV-M91E2-00
BRKT.,W CABLE DUCT 2
1
6
KLV-M91E3-00
DUCT,CABLE
1
7
KLV-M91E4-00
TAPE,W DUCT 1
1
8
KLV-M91E5-00
TAPE,W DUCT 2
1
9
$US4
JOINT
8
10
$UT4
JOINT
2
11
$US6
JOINT
2
12
91312-04010
BOLT HEX,SOCKET HEAD
8
13
98702-03006
SCREW,FLAT HEAD
8
14
KLV-M91F1-00
BRKT.,CYLINDER
1
15
KLV-M91F2-A0
CYLINDER ASSY
1
incl. SQ081 & SQ082
16
KLV-M91F3-00
STOPPER
1
17
$TS4-M5
JOINT
2
18
91312-05055
BOLT HEX,SOCKET HEAD
2
19
KLV-M9165-00
BRKT.,SENSOR ST. 1
1
20
KLV-M9166-01
BRKT.,SENSOR ST. 2
1
21
KLV-M654C-00
SENS.EXT.ST ON ASSY
1
SQ073 : EXIT POS
22
91312-04006
BOLT HEX,SOCKET HEAD
2
23
97602-03310
SCREW PAN HEAD W/WASHER
2
24
92902-04200
WASHER,PLAIN
2
10
6
6
1
9
3
6
2
7
10
9
4
9
8
8
5
8
9
9
10
6
6
1
9
3
6
2
7
10
9
4
9
8
8
5
8
9
9
Controller
Controller Section
KLV-1504
8-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLF-M4209-91
SYSTEM UNIT ASSY
1
2
KLA-M441H-20
VISION BOARD ASSY
1
3
KLA-M4530-20
REMOTE IF BOARD ASSY
1
4
KLA-M5840-23
SERVO BOARD ASSY
1
5
KLW-M5880-10
CONVERTER BOARD ASSY
1
6
KLR-M4111-00
PANEL,DUMMY
3
7
KKE-M4141-00
DUMMY PANEL SYS
1
8
90166-12JA10
SCREW, PAN HEAD
4
9
97602-04308
SCREW PAN HEAD W/WASHER
12
10
91312-04006
BOLT HEX,SOCKET HEAD
4
14,15,16,17,18
2,3,4,5,6,7,
8,9,10,11,12,13
1
19,20,21,22,23,
24,25,
26,27,28,29,30,
31,32
33
14,15,16,17,18
2,3,4,5,6,7,
8,9,10,11,12,13
1
19,20,21,22,23,
24,25,
26,27,28,29,30,
31,32
33
Exterior
Exterior & Etc. Section
KLV-1504
9-1
NO
Parts_No.
Parts_Name
Q'ty
Remarks
Compati
Revision_No._date
1
KLF-M5150-11
KEYBOARD/BALL E
1
2
KHT-M4899-00
LIGHT 1 ASSY
1
for H1,850 : L484mm : R.Y.G.
3
KLV-M4899-10
LIGHT 1 ASSY
1
for H1,900 : L534mm : R.Y.G.
4
KLV-M4899-20
LIGHT 1 ASSY
1
for H2,000 : L634mm : R.Y.G.
5
KLV-M4899-30
LIGHT 1 ASSY
1
for H2,100 : L734mm : R.Y.G.
6
KLV-M4899-40
LIGHT 1 ASSY
1
for H2,200 : L834mm : R.Y.G.
7
KLV-M4899-50
LIGHT 1 ASSY
1
for H2,300 : L934mm : R.Y.G.
8
KLV-M4899-60
LIGHT 1 ASSY
1
for H1,850 : L484mm : C.B.G. : CE-marking
9
KLV-M4899-70
LIGHT 1 ASSY
1
for H1,900 : L534mm : C.B.G. : CE-marking
10
KLV-M4899-80
LIGHT 1 ASSY
1
for H2,000 : L634mm : C.B.G. : CE-marking
11
KLV-M4899-90
LIGHT 1 ASSY
1
for H2,100 : L734mm : C.B.G. : CE-marking
12
KLV-M4899-A0
LIGHT 1 ASSY
1
for H2,200 : L834mm : C.B.G. : CE-marking
13
KLV-M4899-B0
LIGHT 1 ASSY
1
for H2,300 : L934mm : C.B.G. : CE-marking
14
KV7-M4887-00
LED UNIT SPARE
1
Red
15
KV7-M4887-10
LED UNIT SPARE
1
Yellow
16
KV7-M4887-20
LED UNIT SPARE
1
Green
17
KV7-M4887-30
LED UNIT SPARE
1
Blue : CE-marking
18
KV7-M4887-40
LED UNIT SPARE
1
Clear : CE-marking
19
KLW-M669V-10
HNS,OP.PANEL
1
White : READY
20
KLW-M669V-20
HNS,OP.PANEL
1
Green : START
21
KLW-M669V-30
HNS,OP.PANEL
1
Red : STOP
22
KLW-M669V-40
HNS,OP.PANEL
1
Yellow : ERR. CLEAR
23
KLW-M669V-50
HNS,OP.PANEL
1
White : RESET
24
KLW-M669V-60
HNS,OP.PANEL
1
White : STOP : CE-marking
25
KLW-M669V-70
HNS,OP.PANEL
1
Blue : ERR. CLR. : CE-marking
26
KLW-M669V-90
HNS,OP.PANEL
1
White : READY : Chinese
27
KLW-M669V-A0
HNS,OP.PANEL
1
Green : START : Chinese
28
KLW-M669V-B0
HNS,OP.PANEL
1
Red : STOP : Chinese
29
KLW-M669V-C0
HNS,OP.PANEL
1
Yellow : ERR. CLR. : Chinese
30
KLW-M669V-D0
HNS,OP.PANEL
1
White : RESET : Chinese
31
KLW-M669V-E0
HNS,OP.PANEL
1
White : STOP : Chinese : CE-marking
32
KLW-M669V-F0
HNS,OP.PANEL
1
Blue : ERR. CLR. : Chinese : CE-marking
33
LC1-M13H2-00
SWITCH,EMG ASSY
1
34
KLF-M4268-10
USB MEMORY ASSY
1
