01.08.2014 Page 3

JTF-S and JTF-M on SX1/2

Sales Numbers:

00166670-xx JTF-S with Adapter

00166671-xx JTF-M with Adapter

00166673-xx Magazine 14 Trays JTF-M

00166672-xx Magazine 18 Trays JTF-M

00166662-xx Barcodesticker JTF Cassette 14

00166663-xx Barcodesticker JTF Cassette 18

00166664-xx Barcode ruler sticker for JTF

Retrofit kit for SX1/2:

00166650-01 Table for Jedec Tray Feeder SX1/SX2

include this no.03106350-xx Installation kit JTF3 for SX1/2

Additional Parts:

03067206-xx COT insert 30

03073312-xx Waste chute SX1/2 COT30

03092444-xx COT SX1/2, 30 Slots

Optionally: 00519902-xx Stationary camera Typ33 SX1/2

00519918-xx Stationary camera Typ25 SX1/2

Note: The option JTF-M include 5 pieces 03110222-xx

Tray carrier for JTF-M.

SIPLACE

01.08.2014 Page 4

Example Configuration on SX1 and SX2

1. Option:, nozzle changer or SPS magazine

2. Option: stationary camera or SPS magazine

3. Place for non tape feeder (Linear feeder, LDU, Glue feeder)

FCU

Sensor

FC/3D

SST33

JTF-S or JTF-M

Gantry 1

CPP/TH

SX1 with CPP_H or Twin head

SX2 with CPP_H or Twin head

SST33

FCU

Sensor

ST33

FCU

Sensor

FC/3D

Gantry 2

CPP/TH

Gantry 1

CPP/TH

JTF-S or JTF-M

SIPLACE

01.08.2014 Page 5

JTF-S or JTF-M on X-Serie S machine

General:

- The JTF-S or JTF-M can be install on location 2 or 3 or on both locations.

- Setup of the JTF-S and JTF-M only in PA 2.

- For better access to PA 2 a distance of 500 mm between X-Series S and next machine is

recommended.

- The retrofit kit of the Jedec feeder include the retrofit kit of the Service window (00519975)

- Machine with CPP_H or Twin Head support the Jedec feeder.

Position adapter for JTF-S or JTF-M

X4i S Location 2 adapter on track 27

X4i S Location 3 adapter on track 1

X4,3,2 S Location 2 adapter on track 26

X4 S Location 3 adapter on track 1

Note:

For the SIPLACE X3 S / X2 S the JTF-S or JTF-M can be install on Location 2 only!
