InJet
®
388 CD
TECHNICAL DATA SHEET
4
www.dct.cleaning
Dimensions (w x l x h) 1050 x 1360 x 2400 mm 41.3 x 53.5 x 94,4 in
Weight 420 kg 926 lbs
Ø energy consumption per cycle 1,5 kWh 1.5 kWh
Cleaning  uid consumption per cycle 0,05 – 0,2 l 0.01 – 0.08 gal
Compressed air consumption per cycle 900 l / cycle 237 gal/cycle
Max. dimensions of the cleaned parts 190 x 800 x 760 mm 7.48 x 31,5 x 29,92 in
Max. dimensions of the cleaned part
with used air knife
100 x 800 x 760 mm* 3,94 x 31,5 x 29,92 in
Exchangeable mechanical  lter of cleaning  uid 5 – 200 μm 5–200 μm
Operating pressures 1,5 – 2,8 Bar 21.75 – 40.6 PSI
Cleaning  uid  ow rate 200 l / min 52.8 gal / min
Temperature range setting of the cleaning  uid From ambient temperature to 60°C From ambient temperature to 140°F
Conductivity range settings of the rinsing  uid
in the tanks.
0 – 2000 μS/cm * optional 0 – 2000 μS/cm * optional
Temperature range setting of the drying From ambient temperature to 80°C From ambient temperature to 176°F
Noise level < 70 dB < 70 dB
Device control PLC + 4,3“ touchscreen PLC + 4.3“ touchscreen
Volume of the storage tank 75 l 19,8 gal
* Air knife is optional accessory
TECHNICAL PARAMETERS
DIMENSIONS MINIMUM SERVICE SPACE
AROUND THE MACHINE
600 mm
23.6 in
600 mm
23.6 in
600 mm
23.6 in
600 mm
23.6 in
open door
450 mm
17.7 in
1050 mm
41.3 in
1840 mm
72.4 in
1360 mm
53.5 in
metric units imperial units
2400 mm
94.4 in
InJet
®
388 CD
TECHNICAL DATA SHEET
5
www.dct.cleaning
Power supply 400V, 32A, 50Hz (3+N+PE) UL 400V, 32A, 60Hz* (3+N+PE)
Pmax 7,5 kW 7.5 kW
Connection to central air pressure Pipe Ø 6 mm Pipe ID 0.24 in
Recommended working pressure 4,5 – 6 Bar 65.25 – 87 PSI
Compressed air quality 3. Class ** 3. Class **
Exhaust pipe diameter Ø 100 mm ID 3.94 in
Exhaust pipe capacity 380 m
3
/h 13400 ft
3
/h
Minimum liquid for  rst run 1 x 50 l 2 x 19.8 gal
Service space required around the device 600 mm 23.6 in
* When using frequency convertor
** According to the norm ISO 8573-1
INSTALLATION REQUIREMENTS
BACK
VIEW
RIGHT
VIEW
RIGHT
VIEW
input air pressure Ø 6 mm
input air pressure ID 0.24 in
1050 mm
41.3 in
1360 mm
53.5 in
545 mm
21.5 in
245 mm
9.65 in
Ø 100 mm
ID 3.94 in
input el. power 230/400 V
discharge of fl uids G1“
1840 mm
72.4 in
230 mm
9.06 in
metric units imperial units
InJet
®
388 CD
TECHNICAL DATA SHEET
6
www.dct.cleaning
1 process chamber – fully automatted solution
100% closed loop uid system
2 arm rotation – uid powered
Cleaning uid heating
Mechanical ltration
Hot air drying
Chimney ap – electronically controlled
Pneumatic door lock
Emergency stop button
Manipulation wheels – lockable
PLC controller + 4,3“ touchscreen display
Spare parts (base kit)
STANDARD HARDWARE EQUIPMENT
Electronic monitoring of uid level
Electronic monitoring of uid pressure
Electronic process cycle counter
3 levels of logging – operator, maintenance, engineer
Spraying uid pressure – continuous measurement
Standard software language mutation – CZ, ENG
Liquid and lter replacement notication – cycle counting
Possibility of 5 programs – setting option
Smart warning – low or high pressure level
Smart warning – low uid level
STANDARD SOFTWARE EQUIPMENT
