KW1-M134S-000 KW1-M1340-010 KW1-M1 14A-000 No. Part No. Part Name Q'ty Remarks KW1-M1340-010 T APE GUIDE UNIT 1 KW1-M134S-000 T APE GUIDE ASSY 1 KW1-M1 14A-000 HAND LEVER ASSY 1 1 KW1-M1 177-000 MAIN ARM 1 2 3 KW1-M…
KW1-M1110-011
Continued on
Page 3-4,3-5
KW1-M112A-000
K87-M112L-100
KW1-M1320-000
No. Part No. Part Name Q'ty Remarks Change Compati.
KW1-M1110-011
Body Assy
1
K87-M112L-100
Sprocket Axis Assy
1
KW1-M112A-000 Racking Lever Assy
1
KW1-M1320-000 Sprocket Assy
1
1
2
KW1-M1112-000 Knock Pin (Front)
1
*Attention
3
KW1-M1113-000 Knock Pin (Rear)
1
*Attention
4
5
6
7
8
KW1-M131E-000 Spring
1
9
10
11
K87-M111H-200 Back Stopper
1
12
KW1-M111A-000 Spring
1
13
K87-M111B-000 Back Stopper Axis
1
14
K87-M111C-000 Plane Washer
1
15
16
17
18
19
K87-M112D-100 Coil Spring
1
20
21
22
K87-M111D-000 Push Pin
1
23
K87-M111F-100 Stopper Pin
1
24
K87-M111G-100 Push Pin
1
25
K87-M111P-000 Screw, Flat Head+
1
26
K87-M111X-000 Screw, Set
1
27
K87-M111R-000 Screw, Set
5
28
K87-M1115-000 Circular Rivet
2
*Attention
KW1-1107
3
1
BODY & RACHET Unit
CLA-825
CL-825(D type) 8mm-2P(1005)
*Attention: This parts need press t and training.
*Attention:
圧入部品のため修理依頼を推奨します。
KW1-M134S-000
KW1-M1340-010
KW1-M114A-000
No. Part No. Part Name Q'ty Remarks
KW1-M1340-010 TAPE GUIDE UNIT 1
KW1-M134S-000 TAPE GUIDE ASSY 1
KW1-M114A-000 HAND LEVER ASSY 1
1 KW1-M1177-000 MAIN ARM 1
2
3 KW1-M1343-010 SHUTTER PLATE 1
4
KW1-M1144-010 SHUTTER GUIDE PIN
2
*Attention
5
KW1-M114N-000
GUIDE AXIS 1
6 KW1-M1345-010
LEAF SPRING
1 *Attention
7 KW1-M134T-001 LEAF SPRING 1
8 KW1-M116K-000 LEVER AXIS 1
9
10
11
12
13
K87-M111C-000 PLANE WASHER 2
14 K87-M1181-000 ROD CONNECT 1
15
16
17 K87-M1184-000
CONNECT PIN
1
18 KW1-M1185-001 MULTI CYLINDER 1
19 KW1-M111L-001 BARB CONNECTOR STRAIGHT 2
20 K87-M111M-000 GASKET 2
21 KW1-M11B1-000 AIR HOSE (70mm) 1
22 K87-M111P-000 SCREW,FLAT HEAD+ 2 *Attention
23 K87-M11BF-000 SCREW,FLAT HEAD+ 2
24 K87-M53BS-000 Screw,Pan Head+ 1
25 KW1-M11B6-000 S.W.
付
SCREW,CAPBOLT HEAD 2
26 K87-M11B9-000 CIRCLIP E 1
KW1-1107
3
2
TAPE GUIDE & AIR CYLINDER Assy
CLA-825
CL-825(D type) / CLI-825(A type) 8mm-1005
*Attention: This parts need thread locker and training.
*Attention:
接着部品のため修理依頼を推奨します。
KW1-M1131-102
KW1-M1132-001
KW1-M113A-000
No. Part No. Part Name Q'ty Remarks
KW1-M1131-102 CLAMP LEVER UNIT 1
KW1-M1132-001 CLAMP LEVER ASSY 1
KW1-M113A-000 CLANK ARM ASSY 1
1
2
3
4 K87-M113D-001 ARM 2
5
6 K87-M113M-000 AXIS PIN 1
7 K87-M113L-100 CLAMP LEVER AXIS 1
8
9 K87-M113E-000 HINGE PIN 2 1
10 K87-M113H-000 PUSH PIN (L=10) 1
11 K87-M111V-000 SCREW,SET 1
12 K87-M111R-000 SCREW,SET 1
13 K87-M11D7-000 CIRCLIP E 2
KW1-0911
3
3
TOGGLE CLAMP Assy CLA-825
CL-84 ~ 82E (D type) / CLI-84 ~ 82E(A type) 8mm
