1-B 本体部 Mai n B od y パーツレイアウト Kit No. キット品 番 Kit N am e キット名称 N610040204AA ｾｸｼｮﾝN o. PARTS LAYOUT Section No. - - M3 ( KN610040204AA-37-2 )
Ref
No.
Remarks
R
1
Q'ty
1-A
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610040204AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
FRAME
1
1 N210059345AJ
BLOCK
4
2 N210019284AA
LEVELPAD UNIT
4
3 N610066240AA
LEVELPAD UNIT
2
4 N610066241AA
COVER
1
7 N210018282AA
COVER
1
8 N210018289AA
BRACKET
1
9 KXFB02NSA00
COVER
2
10 N210018280AA
FILTER
1
11 KXF0DKLAA00
A
PS/300(DA 0DKLA)
LOCK
2
12 KXF09H6AA00 C-555-50
NUT
8
13 N510017897AA
Hexagon nut Type-3 Best class M12-6H-4T A2J (Trivalent)
SCREW
8
14 XXF12C45FT
Hexagon socket set screw Flat point M12X45-45H SOB
URETHANE
8
15 KXF0CX7AA00 AN25-30
JOINT
6
16 N510066456AA KQ2U06-00A
JOINT
2
17 KXF0DUBAA00 KK3S-08E
JOINT
2
18 N510066700AA KQ2H08-00A
WASHER
8
20 KXF0CPDAA00 WSSB25-12-2
SADDLE
2
21 N510032250AA FCD13
COVER
2
24 N210047778AA
COVER
2
25 N210058809AA
COVER
2
26 N210063272AA
PLUG
4
27 N510016508AA CP-30-HP-18
JOINT
2
28 N510066638AA KQ2UD06-08A
JOINT
6
29 KXF0E1XLA00 KCE06-00
JOINT
2
30 N510066658AA KQ2R06-08A
SILICONE
1
31 N510030216AA KE347B(100gTube)
M2
--
( KN610040204AA-37-1 )
1-B
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610040204AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M3
( KN610040204AA-37-2 )
Ref
No.
Remarks
R
1
Q'ty
1-B
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610040204AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
SHAFT
4
1 KXFB02GCB01
TARGET
8
2 KXFB03KAA01
PLATE
8
3 KXFB02GLA00
PLATE
4
4 KXFB02GMA01
BLOCK
4
5 KXFB02GNA00
PLATE
4
6 KXFB02GPA01
SHAFT
4
7 N210029143AB
BRACKET
4
8 N210047758AA
BRACKET
1
9 N210123132AA
BRACKET
4
10 N210043947AA
COVER
4
11 N210033593AB
TRAY
4
12 MTNK001742AA 195409DB-17
SHEET
4
13 KXF0DKNAA00 Hanenite sponge sheet(DA 0DKNA)
FRAME
4
14 N510001361AA SFF-244 L=77
PIN
4
15 KXF0CXMAA00 1017003-80020
WASHER
12
16 KXF0CP7AA00 URWH20-10-5
COLLAR
8
17 KXF0CP3AA00 NCLB6-10-18.5
WASHER
12
18 KXF0CPBAA00 WSSB20-6-3
WASHER
12
19 KXF0CXCAA00 WSSB20-10-2
COLLAR
4
20 KXF0CXDAA00 NCLB6-10-31.5
BOLT
8
21 N510017461AA
Hexagon socket head cap screw M6X95-10.9 A2J (Trivalent)
VALVE
4
22 KXF0A3RAA00 VQZ1220-5MO-C4
SILENCER
8
23 KXF00WCAA00 AN120-M5
JOINT
4
24 N510066875AA KQ2W06-M5A
PLATE
1
25 N210118844AA
SPACER
4
26 KXF0B5HAA00 SW-302
M4
--
( KN610040204AA-37-2 )
