Number of Placement Heads 4(high-accuracy) Number of IC Trays 48 Number of Feeders 50/44(subject to 8mm feeder) Positioning Accuracy 0.01mm Repeated Mounting Accuracy 0.02mm Range of Mounting Speed 7000-8000Pcs/h Applica…
Product Specification
Software part
Number of Placement Heads
4(high-accuracy)
Number of IC Trays
48
Number of Feeders
50/44(subject to 8mm feeder)
Positioning Accuracy
0.01mm
Repeated Mounting Accuracy
0.02mm
Range of Mounting Speed
7000-8000Pcs/h
Applicable Components
resistor,capacitor,chip,lamp bead etc.
Supported Maximum Area of PCB
(50F)350*190mm /(44FX)350*280mm
Feeders
electric feeder, pneumatic feeder,vibrating feeder, IC tray etc.
Recognition Devices
mark camera x1,fast recognition camera x4, high-precision camera x1
Maximum Height of Applicable Components
≤7mm
PCB Convey Mode
three-stage entry,automatic connection from left to right, automatic PCB positioning
Mark Positioning
manual / automatic
Programming Method
automatic programming after manually importing files of PCB coordinates
Control System
HuaweiGuochuang control system
Maximum Step Length of XY Axis
629mm*679mm
Tracks of XY Axis
double linear motion guide + double ground ball screw
Motion Mode of XY Axis
intelligent linkage of acceleration and deceleration of curve and line, integrated linear interpolation algorithm.
Model
HW-T4-50F / HW-T4-44FX
Control Computer
industrial control computer with Intel high-performance processor
Adjusting Method of Tracks
electric
Range of Nozzle Buffer
4.5mm
Maximum Step Length of Z Axis
20mm
Range of Angle for Components
±180°
Motor
AC Servo Motor
Driver
high-speed DSP driver
Air Supply Requirements
oil water filter,≥ 50L,dust filter and air pressure stabilizer etc.
Vacuum Supply of Nozzle
Japanese CKD vacuum generator integrating the high-speed vacuum burst function
Range of Air Supply Pressure
0.5-0.6mp
OS
Independent research and development SMT intelligent OS based on Windows
Vision Display
17-inch industrial control display
Cable
German Igus durable flexible cable（10 million times）
Power Supply
220V 50/60Hz
Average Power
600W
Machine Dimensions
desk machine 1140*900*900mm
vertical machine 900*1140*1340mm
Weight
(desk machine)210kg (vertical machine)280kg
