s So ft w a r e O pe r a t i o n R eduction of err o rs caused by manual edit and achievement of intelligent pr o gramming
Control Computer
industrial control computer with Intel high-performance processor
Adjusting Method of Tracks
electric
Range of Nozzle Buffer
4.5mm
Maximum Step Length of Z Axis
20mm
Range of Angle for Components
±180°
Motor
AC Servo Motor
Driver
high-speed DSP driver
Air Supply Requirements
oil water filter,≥ 50L,dust filter and air pressure stabilizer etc.
Vacuum Supply of Nozzle
Japanese CKD vacuum generator integrating the high-speed vacuum burst function
Range of Air Supply Pressure
0.5-0.6mp
OS
Independent research and development SMT intelligent OS based on Windows
Vision Display
17-inch industrial control display
Cable
German Igus durable flexible cable（10 million times）
Power Supply
220V 50/60Hz
Average Power
600W
Machine Dimensions
desk machine 1140*900*900mm
vertical machine 900*1140*1340mm
Weight
(desk machine)210kg (vertical machine)280kg
Price
s
Software Operation
Reduction of errors caused by manual edit and achievement of intelligent programming
1
2
3
4
Create production project and set mark points
Import the .CSV file exported from PCB files, generate project coordinates through four corner coordinate positioning, and automatic-
ally generate mark points. Through the packaging library, the layout of material station and nozzle can be generated intelligently, and
the picking parameters and mounting parameters can be generated at the same time, greatly improving programming speed.
Install feeder / nozzle
Install the corresponding feeders of electronic components and nozzles according to the assigned station of the system.
Calibrate feeder picking coordinates intelligently
One-click operation without manual work. It can automatically calibrate installed feeder picking coordinates.Originally, it took an hour,
but through the function of automatic scanning, it could be completed in a few minutes.
Start mounting
After a short manual adjustment and efficient automatic programming, the process quickly enters the first board trial, then you can
start mass production if it runs smoothly.
