System Requirements and Software Components
System Requirements for SIPLACE Traceability
SIPLACE Traceability 3.5 29
4 System Requirements and Software Components
4.1 System Requirements for SIPLACE Traceability
4.2 System Requirements for the SIPLACE Explorers Traceability
Option
4.3 Configuration
In order to establish the connection to the station computer, you need to install SIPLACE Trace Server
in the SIPLACE LAN. The installation options vary according to your network configuration and are as
follows:
1. SIPLACE Trace Service on one computer
This option requires that all SIPLACE Pro computers are available in the same LAN segment.
2. SIPLACE Trace Service on each line server
This option needs to be selected if the SIPLACE Pro computers are in different line-specific LAN seg-
ments.
The SIPLACE Trace Monitor setup is used to configure and generate the monitor web application on the
Apache Tomcat web server.
The Apache web server and the database server can be installed on any host. The following require-
ments need to be fulfilled:
1. Each Trace Service configured at the factory with the export option Database must be able to access
the central SQL server, on which the traceability database is installed.
2. The Apache web server and the SQL server are installed on computers in the same LAN segment.
The following components are required for the web and database server:
▪ Web server for managing Java Servlets
▪ Database server
NOTICE
System requirements
The system requirements (supported operating system and database variants) and an over-
view of mutually compatible products can be found in the Assembly Instructions SIPLACE Sup-
port Media, item no [00197214-xx].
NOTICE
Station based traceability
For machine-based traceability, the SIPLACE placement machines must be equipped with the
options "Setup verification" and "Traceability".
NOTICE
System requirements
The system requirements (supported operating system and database variants) and an over-
view of mutually compatible products can be found in the Assembly Instructions SIPLACE Sup-
port Media, item no [00197214-xx].
System Requirements and Software Components
Configuration
30 SIPLACE Traceability 3.5
NOTICE
System requirements
The system requirements (supported operating system and database variants) and an over-
view of mutually compatible products can be found in the Assembly Instructions SIPLACE
Support Media, item no [00197214-xx].
NOTICE
SQL server
For a detailed description of how to install the SQL servers, refer to the Assembly Instructions
(item no. 00196824-xx (English)), on Support Media DVD 1. The SQL server itself is not part of
the Support Media DVDs.
Traceability System Components and Features
Trace Service Server System Components
SIPLACE Traceability 3.5 31
5 Traceability System Components and Features
5.1 System Components
SIPLACE Trace Service processes traceability data. This data is imported from station and line software
and then stored in the traceability database, before being exported as XML files or made available via
the OIB interface. The traceability database can be visualized via the Trace Monitor.
SIPLACE Traceability consists of three components:
▪ Trace Service server:
for generation and export of data
▪ Trace Service Manager:
for configuration of the Trace Service server
▪ Trace Monitor:
For displaying and searching for recorded traceability data
All SIPLACE Trace Service components are automatically installed on the same computer during instal-
lation. The Trace Monitor web application is generated with the help of the Trace Monitor configuration
tool, which can be separately installed on any computer.
In addition to Trace Monitor, you can also install the traceability option for SIPLACE Explorer. Before this
installation, make sure that SIPLACE Explorer has been installed and activated. This is required for dis-
playing and searching for recorded traceability data.
5.1.1 Trace Service Server
When using machine-based traceability, the Trace Service server imports the traceability data from the
stations. The traceability data are exported:
▪ into the Trace database (which is configured in the Trace Service Manager)
▪ to the OIB interface (see the OIB SDK for details)
▪ into the file system (as XML files)
All settings or configurations are performed via the SIPLACE Trace Service Manager.
5.1.2 Trace Service Manager
The line-specific configuration and other options are set via the user interface of the Trace Service Man-
ager.
▪ Configuring the database connection to SIS and Setup Center
▪ Export method for configuring traceability data
▪ Configuring traceability database (create, update, backup and restore)
▪ Configuring lines and their traceability operating modes
5.1.3 Trace Monitor
The Trace Monitor is used to display the recorded and invoked data.
The user can search for specific data using the Trace Monitor. In doing so, it is possible to filter the
search according to various criteria, e.g. according to produced boards, placed components etc. The
data displayed can be saved as a CSV file for further processing in MS Excel.
