Existing Restrictions

Technical Restrictions

36 SIPLACE Traceability 3.5

▪ The length of the setup name is limited to 20-50 characters, i.e. only the first 20 to 50 characters will

be taken into account during setup changeovers.

▪ If you change the configuration of the Traceability system the SIPLACE line has to be empty. Other-

wise Traceability data may be incomplete.

▪ Station based and line based traceability cannot run simultaneously in the same line.

▪ If a station is part of several lines (SIPLACE Pro configuration), there are the following restrictions

for line based traceability:

– Only one of the lines may be active at the same time.

– If an external PCB barcode reader is allocated to more than one line then the PCB barcodes are

assigned to the line which is active in Trace Service. If there are multiple lines active with the

same external barcode reader, Trace Service will issue an error message. Traceability data can

not be reliably generated in this case.

▪ In case of line based traceability the sequence of the boards may only be changed (e.g. by a pro-

ductivity lift) if there are external PCB barcode readers in front of AND at the end of the line.

▪ The option "Remove unused charges" in the TraceService Monitor requires that you perform forced

setup verification for all the lines for which traceability data are to be generated in "line-based" mode.

For 407

▪ When using a synchronous dual conveyor, traceability data can only be generated to a limited de-

gree. The restriction is based on the fact that both boards are seen as one panel and that the trace-

ability data is therefore stored in one data package. The board barcode used is always the barcode

read at conveyor 1.

7.2 Technical Restrictions

▪ Network connection

To enable SIPLACE Trace Service to import the traceability data from stations with station software

<70x, you need to configure the relevant network connections (e.g. if files need to be imported from

another host). The non-availability of configured import paths and network connections is recorded

in the log file.

▪ We recommend that you limit the size of the Trace database to 20 GB. If the database has reached

this size, it should be archived in a backup and the production should be continued with a newly cre-

ated Trace database.

Station software Max. length of setup names

407 20 characters exc. path

505 50 characters exc. path

605 256 characters inc. path

70x 256 including the path designation (limitation in the

Trace Host database)

NOTICE

Station and line name

The station name must be unique in the line. The line name must be unique throughout the

traceability system.

Annex

Supported Hardware

SIPLACE Traceability 3.5 37

8 Annex

8.1 Supported Hardware

Standards

SIPLACE recommends the observance of the following standards for all line computers (SIPLACE Pro

Server, SIPLACE Pro Client, SIPLACE stand-alone computer configuration).

Obervance of standards

Product safety

Global IEC 60950

Europe EN 60950

USA UL 60950 3rd. Ed.

Canada CAN/CSA-C22.2 No. 60950 3rd ed.

Electromagnetic compatibility

Europe EN 55 022 class B, EN 55024,

EN61000-3-2 /-3

USA / Canada FCC class A

Declaration of conformity

Europe (CE) 89/336/EWG (EMW)

72/213 EEC (LVD)

North America FCC class A

Applicability

Europe EN ISO 9241-11
