CP-642E PARTS LIST ver08
1 - 1 - 1
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
Ref.19-4
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
A
x2
38
39
37
B022-050
□22
φ5.0
41
42
S022-070
40
□22
φ7.0
B022-070
45
44
43
□22
φ7.0
47
48
46
R012-004
φ12
φ0.41
34
35
36
S022-050
□22
φ5.0
31
S020-050
33
32
□20
φ5.0
R020-037
29
30
28
φ20
φ3.75
M020-025
26
27
25
φ20
φ2.5
14
15
13
R012-018
φ12
φ1.81
R016-025
17
18
16
φ16
φ2.5
R016-037
20
21
19
φ16
φ3.75
R020-025
23
24
22
φ20
φ2.5
11
10
12
M012-013
φ12
φ1.3
7
9
8
R012-013
φ12
φ1.3
5
R012-010
4
6
φ12
φ1.0
R012-007
2
3
1
φ12
φ0.71
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 AWPH9514 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-007 OT
2 AWPH9011 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-007 OT
3 WPH8291 20 SEAL ｼｰﾙ R012-007 PL
4 AWPH9524 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-010 OT
5 AWPH9021 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-010 OT
6 WPH8301 20 SEAL ｼｰﾙ R012-010 PL
7 AWPH9534 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-013 OT
8 AWPH9031 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-013 OT
9 WPH8311 20 SEAL ｼｰﾙ R012-013 PL
10 AWPH9545 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY M012-013 OT
11 AWPH9088 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 M012-013 OT
12 WPH8311 20 SEAL ｼｰﾙ M012-013 PL
13 AWPH9554 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-018 OT
14 AWPH9077 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-018 OT
15 WPH8320 20 SEAL ｼｰﾙ R012-018 PL
16 AWPH9563 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R016-025 OT
17 AWPH9125 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R016-025 OT
18 WPH8201 20 SEAL ｼｰﾙ R016-025 PL
19 AWPH9572 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R016-037 OT
20 AWPH9135 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R016-037 OT
21 WPH8211 20 SEAL ｼｰﾙ R016-037 PL
22 AWPH9583 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R020-025 OT
23 AWPH9041 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R020-025 OT
24 WPH8081 20 SEAL ｼｰﾙ R020-025 PL
25 AWPH9593 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY M020-025 OT
26 AWPH9098 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 M020-025 OT
27 WPH8081 20 SEAL ｼｰﾙ M020-025 PL
28 AWPH9602 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R020-037 OT
29 AWPH9051 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R020-037 OT
30 WPH8121 20 SEAL ｼｰﾙ R020-037 PL
31 AWPH9612 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S020-050 OT
32 AWPH9060 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 S020-050 OT
33 WPH8101 20 SEAL ｼｰﾙ S020-050 PL
34 AWPH9662 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S022-050 OT
35 AWPH9154 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 S022-050 OT
36 WPH8231 20 SEAL ｼｰﾙ S022-050 PL
37 AWPH9672 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B022-050 OT
38 AWPH9154 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 B022-050 OT
39 WPH8221 20 SEAL ｼｰﾙ B022-050 PL
CP-642E PARTS LIST ver08
1 - 1 - 2
1.1.ノズル一覧(WPH)
1.1.Nozzles (WPH)
1.1.ノズル一覧(WPH)
1.1.Nozzles(WPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
40 AWPH9682 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S022-070 OT
41 AWPH9164 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 S022-070 OT
42 WPH8181 20 SEAL ｼｰﾙ S022-070 PL
43 AWPH9694 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B022-070 OT
44 AWPH9176 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 B022-070 OT
45 WPH8171 20 SEAL ｼｰﾙ B022-070 PL
46 AWPH9702 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-004 Option(For 0603 support) OT
47 AWPH9181 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無 R012-004 Option(For 0603 support) OT
48 WPH8331 20 SEAL ｼｰﾙ R012-004 Option(For 0603 support) PL
CP-642E PARTS LIST ver08
1 - 1 - 3
1.1.ノズル一覧(WPH)
1.1.Nozzles (WPH)
