DIGIT AL INSPECTION 022 SCIENSCOPE INTERNA TIONAL DIGIT AL INSPECTION SCIENSCOPE INTERNA TIONAL 023 Smar tCam-Ul tra Aut oF ocu s Macr o Inp se ction S y s tem s • MACRO vide o zoom optics (up to 6 5x magnific ation with…
DIGITAL INSPECTION
020
SCIENSCOPE INTERNATIONAL
DIGITAL INSPECTION
SCIENSCOPE INTERNATIONAL
021
The SmartCam-Ultra AF from Scienscope is our most ad-
vanced 4k resolution camera. It features a vivid 4K image
to a live monitor (HDMI) or 8.2 Megapixel image via USB
3.0 and WiFi to a computer. Includes a host of onboard im-
age processing and measurement tools accessible using a
mouse connected to the camera via its onboard software.
Capture images to SD card, USB Flash drive, USB 3.0, and
WiFi. Measure anything using the onboard field-of-view
measuring tools, DXF overlay, or multi-line generator.
Export your measurement data and images with measured
objects!
• Auto-Focus
• Live measurement and annotation tools
• Image and video capture to SD card or USB Flash drive
• Split-screen live image/captured image comparison
• Image and video gallery / Image and video review
• Export measurement data to an SD card or USB Flash
• Wireless mouse control
SC U
Integrated Software with Convieniently Located Control Bar
HDMI MODE FEATURES
CC-SMART-4K-AF
USB 3.0/WIFI MODE FEATURES
• Image and video capture using Windows 10 camera
app
• Measure and annotate using included WiFi and USB
2.0 software
• Image and video capture using the included software
• Directly email or print images
• Export measurement data
Image Sensor Sony IMX334© 1/1.8”(7.68x4.32) Freeze Image Yes
Effective Pixels
30@3840*2160(HDMI)
20@3840*2160(USB)
HDR Yes
Frame Rate 30fps Edge Enhancements/ Sharpening Yes
Definition 4200 lines SD card slot Up to 32GB SD Card
Housing Aluminum Crosshair Multi-Color, small or large
White Balance Automatic/Manual/Continous Horizontal/ Vertical lines
Multi-Color, two lines for each
(Position can be adjusted)
Brightness Control Automatic/Manual/Continous Noise Reduction Support
Color R/G/B adjustable HDMI 1080p
Edge Enhancement Yes USB USB 3.0
OSD Yes, In HDMI mode
Digital Zoom / Increase Magnification
Digital Zoom / Decrease Magnification
Flip Image Horizontal
Mirror Image Vertical
Color to Black and White Toggle
Freeze Image/ Unfreeze Image Toggle
Digital Line Generator
Side-by-Side Live/Captured Image Comparison
Still Image Capture
Auto Focus / Optical Zoom
Gallery / Image Preview / SD Card Management
Side-by-Side Live/Captured Image Comparison
File Explorer
Settings
Software Info
SC-U AF (CC-SMART-4K-AF) | SPECIFICATIONS
DIGITAL INSPECTION
022
SCIENSCOPE INTERNATIONAL
DIGITAL INSPECTION
SCIENSCOPE INTERNATIONAL
023
SmartCam-Ultra AutoFocus Macro Inpsection Systems
• MACRO video zoom optics (up to 65x magnification with 8" working
distance)
• Extended post stand
• NEW high-intensity LED ring light with polarizer (IL-LED-R3)
• Features NEW 4K HDMI SMARTCAM w/ Autofocus (Includes SD card and
mouse)
• 26" 4k/UHD LED monitor
MAC-PK1-4KSC-R3-AF
• MACRO video zoom optics (up to 65x magnification with 8" working
distance)
• Extended post stand
• Diffused compact LED ring light (IL-LED-E2D)
• Features NEW 4K HDMI SMARTCAM (Includes SD card and mouse)
• 26" 4k/UHD LED monitor
• Calibration target included
MAC-PK1-4KSC-E2D-AF
• MACRO video zoom optics (up to 65x magnification with 8" working
distance)
• Dual arm boom stand
• NEW high-intensity LED ring light with polarizer (IL-LED-R3)
• Features NEW 4K HDMI SMARTCAM w/ Autofocus (Includes SD card and
mouse)
• 26" 4k/UHD LED monitor
MAC-PK5D-4KSC-R3-AF
MAC-PK5D-4KSC-E2D-AF
• MACRO video zoom optics (up to 65x magnification with 8" working
distance)
• Dual arm boom stand with diffused compact LED ring light (IL-LED-
E2D)
• Features NEW 4K HDMI SMARTCAM w/ Autofocus (Includes SD card and
mouse)
• 26" 4k/UHD LED monitor
• MZ7A Micro-Zoom video zoom optics (0.5x video coupler, zoom
body)
• Dual illuminated LED track stand with course and fine focus
• Features NEW 4K HDMI SMARTCAM w/ Autofocus (Includes SD
card and mouse)
• 26" 4k/UHD LED monitor
• Calibration target included
MZ7A-PK2-4KSC-AF
• MZ7A Micro-Zoom video zoom optics (0.5x video coupler, zoom
body)
• Dual arm boom stand
• NEW high-intensity LED ring light with polarizer (IL-LED-R3)
• Features NEW 4K HDMI SMARTCAM w/ Autofocus (Includes SD card
and mouse)
• 26" 4k/UHD LED monitor
• Calibration target included
MZ7A-PK5D-4KSC-R3-AF
• MZ7A Micro-Zoom video zoom optics (0.5x video coupler, zoom
body)
• Dual arm boom stand
• Diffused compact LED ring light (IL-LED-E2D)
• Features NEW 4K HDMI SMARTCAM w/ Autofocus (Includes SD card
and mouse)
• 26" 4k/UHD LED monitor
MZ7A-PK5D-4KSC-E2D-AF
SmartCam-Ultra AutoFocus Micro Inpsection Systems
DIGITAL INSPECTION
024
SCIENSCOPE INTERNATIONAL
DIGITAL INSPECTION
SCIENSCOPE INTERNATIONAL
025
Experience the future of imaging with Scienscope’s Smart-
Cam-4K, the pinnacle of 4K resolution cameras. Unleash
stunning 4K visuals on your HDMI monitor or grab crisp
8.2 Megapixel shots via USB 3.0. Dive into a world of im-
age mastery with onboard processing and mouse-driven
measurement tools. Save your creations on SD cards, USB
Flash drives, and USB 2.0. Precision measurement awaits
with field-of-view tools, DXF overlay, and multi-line gen-
eration. Export your data and images, showcasing your
measured wonders!
• Live measurement and annotation tools
• Image and video capture to SD card or USB Flash
drive
• Split-screen live image/captured image comparison
• Image and video gallery / Image and video review
• Export measurement data to an SD card or USB
Flash
• Wireless mouse control
SC 4K
Integrated Software with Convieniently Located Control Bar
HDMI MODE FEATURES
CC-SMART-4K
USB 2.0 MODE FEATURES
• Image and video capture using Windows 10 camera app
• Measure and annotate using included WiFi and USB 2.0
software
• Image and video capture using the included software
• Directly email or print images
• Export measurement data
Image Sensor Sony IMX334© 1/1.8”(7.68x4.32) Freeze Image Yes
Effective Pixels
30@3840*2160(HDMI)
20@3840*2160(USB)
HDR Yes
Frame Rate 30fps Edge Enhancements/ Sharpening Yes
Definition 4200 lines SD card slot Up to 32GB SD Card
Housing Aluminum Crosshair Multi-Color, small or large
White Balance Automatic/Manual/Continous Horizontal/ Vertical lines
Multi-Color, two lines for each
(Position can be adjusted)
Brightness Control Automatic/Manual/Continous Noise Reduction Support
Color R/G/B adjustable HDMI 1080p
Edge Enhancement Yes USB USB 2.0
OSD Yes, In HDMI mode
Digital Zoom / Increase Magnification
Digital Zoom / Decrease Magnification
Flip Image Horizontal
Mirror Image Vertical
Color to Black and White Toggle
Freeze Image/ Unfreeze Image Toggle
Digital Line Generator
Side-by-Side Live/Captured Image Comparison
Still Image Capture
Auto Focus/ Optical Zoom Menu
Gallery / Image Preview / SD Card Management
Side-by-Side Live/ Captured Image Comparison
File Explorer
Settings
SC-U (CC-SMART-4K) | SPECIFICATIONS
Software Info
