DIGIT AL INSPECTION 01 2 SCIENSCOPE INTERNA TIONAL DIGIT AL INSPECTION SCIENSCOPE INTERNA TIONAL 01 3 Our industry-st andar d Macro vide o/ digital inspection sy stems now f eatur e the powerful Ver sa-C am. The Ver - sa…
DIGITAL INSPECTION
010
SCIENSCOPE INTERNATIONAL
DIGITAL INSPECTION
SCIENSCOPE INTERNATIONAL
011
• Features NEW 1080p HDMI/USB All-One camera with inrgrated optics
(50x Max)
• Integrated diffused LED ring light
• Mounting adapter
• SD or USB card capture
• Includes 23" HD LCD monitor
• Capture software
MAC-PK1-A1
• Features NEW 1080p HDMI/USB All-One camera with integrated optics (50x
Max)
• Integrated diffused LED ring light
• Mounting adapter
• SD or USB card capture
• Includes 23" HD LCD monitor
• Capture software
• Heavy duty articulating arm stand
MAC-PK3-A1
ALL-ONE DIGITAL INSPECTION SYSTEMS
• Features NEW 1080p HDMI/USB All-One camera with integrated optics
(50x Max)
• Integrated diffused LED ring light
• Mounting adapter
• SD or USB card capture
• Includes 23" HD LCD monitor
• Capture software
MAC-PK5S-A1
• Features NEW 1080p HDMI/USB All-One camera with integrated optics
(50x Max)
• Integrated diffused LED ring light
• Mounting adapter
• SD or USB card capture
• Includes 23" HD LCD monitor
• Capture software
• Dual arm boom stand
MAC-PK5D-A1
Sensor & Size (mm)
Pixel (µm)
G Sensivity Dark Signal
FPS/Resoluon
Binning
Exposure
Working Distance (mm)
Zoom Range
MTF (lp/mm)
Distoron
FOV@1.0X (mm)
FOV@20X (mm)
LED
Color
Power
Inner Dia (mm)
Out Dia (mm)
ALL-ONE INSPECTION SYSTEM SPECIFICATIONS
DIGITAL INSPECTION
012
SCIENSCOPE INTERNATIONAL
DIGITAL INSPECTION
SCIENSCOPE INTERNATIONAL
013
Our industry-standard Macro video/digital inspection
systems now feature the powerful Versa-Cam. The Ver-
sa-Cam can be used as a “live image” HD (1080p) cam-
era connected to a monitor using an HDMI cable or as a
USB 2.0 camera with a USB cable connected to any com-
puter or Windows Tablet. Now the choice between live
HD monitor inspection and high-resolution USB camera
capture and annotation is made at the camera…not be-
tween cameras.
• 1080p (1920 x 1080) HD images @ 60fps
• Onscreen control bar and setting menu
• Image and video capture to SD card
• Split-screen live image | Capture image
comparison (picture-to-picture)
• Image and video gallery/ Image and video review
• Vertical and horizontal line generator
• Save line generator configurations
• Wireless mouse support and control
VERSA CAM
Integrated Software with Convieniently Located Control Bar
HD/ HDMI MODE FEATURES
CC-HDMI-CD2
USB 2.0 MODE FEATURES
• 2 Mega-pixel resolution
• Image and Video capture w/Windows 10 camera app
• Email, Save, or Print software
• Image and video capture with the included software
• Annotation and drawing tools on live or captured images
• Send images directly to the local file location or network
• Time and date stamp images
• Includes DirectShow drivers
• Upgrade software with FOV measurements tools
Image Sensor
1/2.86 Inch Panasonic
FULL HD 2.0 Megapixel
Freeze Image Yes
Effective Pixels 1920 X 1080 HDR Yes
Frame Rate 60fps Edge Enhancements/ Sharpening Yes
Definition More than 1200 lines SD card slot Up to 32GB SD Card
Housing Aluminum/ Plastic Crosshair Multi-Color, small or large
White Balance Automatic/Manual/Continous Horizontal/ Vertical lines
Multi-Color, two lines for each
(Position can be adjusted)
Brightness Control Automatic/Manual/Continous Noise Reduction Support
Color R/G/B adjustable HDMI 1080p
Edge Enhancement Yes USB USB 2.0
OSD: Yes, In HDMI mode
Digital Zoom / Increase Magnification
Digital Zoom / Decrease Magnification
Flip Image Horizontal
Mirror Image Vertical
Freeze Image / Unfreeze Image Toggle
Color to Black and White Toggle
High Dynamic Range Toggle
Side-by-Side Live/Captured Image Comparison
Still Image Capture
Video Capture
Gallery / Image Preview / SD Card Management
Clear SD Card and SD Format
Settings Menu
Integrated Video Caliper and Crosshair
VERSA-CAM (CC-HDMI-CD2) | SPECIFICATIONS
DIGITAL INSPECTION
014
SCIENSCOPE INTERNATIONAL
DIGITAL INSPECTION
SCIENSCOPE INTERNATIONAL
015
VersaCamVersaCam MACRO DIGITAL INSPECTRION SYSTEMS MACRO DIGITAL INSPECTRION SYSTEMS
• MACRO video zoom optics (up to 65x magnification with 8" working
distance)
• Extended post stand
• NEW high-intensity LED ring light with polarizer (IL-LED-R3)
• NEW 1080p HDMI/USB camera (Includes SD card, HDMI cable, USB
cable, and mouse)
• 23" HD LCD monitor
MAC-PK1-R3
• MACRO video zoom optics (up to 65x magnification with 8" working
distance)
• Extended post stand
• Diffused compact LED ring light (IL-LED-E2D)
• Features NEW 1080p HDMI/USB camera (Includes SD card, HDMI ca-
ble, USB cable, and mouse)
• 23" HD LCD monitor
• Capture software
MAC-PK1-E2D
• MACRO video zoom optics (up to 65x magnification with 8" working
distance)
• HEAVY DUTY articulating arm with 15" vertical post
• NEW high-intensity LED ring light with polarizer (IL-LED-R3)
• Features NEW 1080p HDMI/USB camera (Includes SD card, HDMI ca-
ble, USB cable, and mouse)
• 23" HD LCD monitor
MAC-PK3-R3
MAC-PK3-E2D
• MACRO video zoom optics (up to 65x magnification with 8" working
distance)
• Dual arm boom stand
• NEW high-intensity LED ring light with polarizer (IL-LED-R3)
• Features NEW 1080p HDMI/USB camera (Includes SD card, HDMI cable,
USB cable, and mouse)
• 23" HD LCD monitor
MAC-PK5D-R3
• MACRO video zoom optics (up to 65x magnification with 8" working dis-
tance)
• Dual arm boom stand
• Diffused compact LED ring light (IL-LED-E2D)
• Features NEW 1080p HDMI/USB camera
(Includes SD card, HDMI cable, USB
cable, and mouse)
• 23" HD LCD monitor
• Capture software.
MAC-PK5D-E2D
• MACRO video zoom optics (up to 90x magnification with 8" working
distance)
• Extended post stand
• Quadrant-controlled LED ring light
• Features NEW 1080p HDMI/USB camera (Includes SD card, HDMI cable,
USB cable, and mouse)
• 23" HD LCD monitor
MAC-PK1-E1Q
• MACRO video zoom optics (up to 90x magnification with 8" working
distance)
• HEAVY DUTY articulating arm with 15" vertical post
• Quadrant-controlled LED ring light
• Features NEW 1080p HDMI/USB camera (Includes SD card, HDMI cable,
USB cable, and mouse)
• 23" HD LCD monitor
MAC-PK3-E1Q
• MACRO video zoom optics (up to 90x magnification with 8" working dis-
tance)
• Dual arm boom stand
• Quadrant-controlled LED ring light
• Features NEW 1080p HDMI/USB camera (Includes SD card, HDMI cable,
USB cable, and mouse)
• 23" HD LCD monitor
MAC-PK5D-E1Q
• MACRO video zoom optics (up to 65x magnification with 8" working dis-
tance)
• HEAVY DUTY articulating arm with 15" vertical post
• Diffused compact LED ring light (IL-LED-E2D)
• Features NEW 1080p HDMI/USB camera
(Includes SD card, HDMI cable,
USB cable, and mouse)
• 23" HD LCD monitor
VersaCamVersaCam MACRO DIGITAL INSPECTRION SYSTEMS MACRO DIGITAL INSPECTRION SYSTEMS
