Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE MODEL TPM-1 10F/R-C 0509-002 136 271 41 1 141 6705 W ASHER SPR 5 20 748R--310-271 272 41 1 141 4008 W ASHER V 4X9X0.8 6 748R--310-272 273 41 1 141 2905 W ASHER SPR 4 6 748…
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
MODEL TPM-110F/R-C
0509-002
135
201 630 094 5225 HINGE 2 748R--310-201
202 630 092 8112 HINGE 2 748R--310-202
203 630 089 2703 HANDLE 1 748R--310-203
204 630 064 6528 SWITCH,BUTTON 2 SPB010,011 748R--310-204
205 630 125 5071 PILOT LAMP 1 748R--310-205
206 630 088 5347 SWITCH,LIMIT(DOOR SWITCH) 1 SQ003,D4DS-1AFS 748R--310-206
207 630 096 8101 SWITCH,LIMIT 1 748R--310-207
208 630 096 8118 MECH PARTS 2 748R--310-208
209 630 092 8129 MECH PARTS 1 748R--310-209
210 630 103 0883 COVER 1 748R--310-210
211 630 103 0890 COVER 1 748R--310-211
212 630 102 5308 COVER 1 748R--310-212
213 630 103 0951 COVER 1 748R--310-213
214 630 103 0968 COVER 1 748R--310-214
215 630 103 1118 PLATE 1 748R--310-215
216 630 103 1125 PLATE 1 748R--310-216
217 630 103 1019 COVER 1 748R--310-217
218 630 103 1026 COVER 1 748R--310-218
219 630 103 1033 COVER 1 748R--310-219
220 630 103 1040 COVER 1 748R--310-220
221 630 136 4001 COVER 1 748R--310-221
222 630 136 5473 BRACKET 1 748R--310-222
223 630 136 6005 BRACKET 1 748R--310-223
224 630 103 1385 BRACKET 1 748R--310-224
225 630 103 1392 BRACKET 1 748R--310-225
226 630 103 1200 COVER 1 748R--310-226
227 630 131 8479 COVER 1 748R--310-227
228 630 091 1862 NAME PLATE,INDEX 1 748R--310-228
229 630 121 8588 NAME PLATE 1 748R--310-229
230 630 114 5167 NAME PLATE,NOTICE 2 748R--310-230
231 630 100 0640 NAME PLATE,NOTICE 1 748R--310-231
232 630 100 0633 NAME PLATE,NOTICE 10 748R--310-232
234 630 100 1159 NAME PLATE,NOTICE 2 748R--310-234
235 630 133 7975 ACCESSORY,LAMP 1 748R--310-235
236 630 136 3998 BRACKET 1 748R--310-236
237 630 136 5466 BOX 1 748R--310-237
238 630 135 6792 MOTOR,DC 1 S-FAN,MDS1225-24M 748R--310-238
239 630 049 1074 ACCESSORY,MOT-M 1 748R--310-239
240 630 061 6538 ACCESSORY,MOT-M 1 748R--310-240
241 630 136 4469 CORD 1 748R--310-241
261 630 000 7886 BOLT,HEX-SCT 7 748R--310-261
262 630 000 7787 BOLT,HEX-SCT 4 748R--310-262
263 630 000 7756 BOLT,HEX-SCT 4 748R--310-263
264 630 000 7749 BOLT,HEX-SCT 12 748R--310-264
265 630 000 7619 BOLT,HEX-SCT 6 748R--310-265
266 630 000 7503 BOLT,HEX-SCT 6 748R--310-266
267 411 141 4305 WASHER V 6X12.5X1.6 7 748R--310-267
268 411 141 3001 WASHER SPR 6 7 748R--310-268
269 411 141 4107 WASHER V 5X10X1 16 748R--310-269
270 630 001 0220 WASHER 4 748R--310-270
R-3
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
MODEL TPM-110F/R-C
0509-002
136
271 411 141 6705 WASHER SPR 5 20 748R--310-271
272 411 141 4008 WASHER V 4X9X0.8 6 748R--310-272
273 411 141 2905 WASHER SPR 4 6 748R--310-273
274 411 141 3902 WASHER V 3X7X0.5 6 748R--310-274
275 411 141 2806 WASHER SPR 3 6 748R--310-275
276 411 140 8007 SCR TRS 5X6 34 748R--310-276
277 411 051 1708 SCR TRS 4X6 4 748R--310-277
278 411 035 2707 SCR FLT 4X8 8 748R--310-278
279 411 002 2600 SCR FLT 3X6 2 748R--310-279
280 411 113 2407 SCR PAN 4X30 2 748R--310-280
281 411 119 2005 WASHER F 4X8X0.8 2 748R--310-281
282 411 008 1706 WASHER SPR 4 6 748R--310-282
283 411 050 5004 SCR TRS 3X6 8 748R--310-283
284 411 113 2506 SCR PAN 4X40 4 748R--310-284
285 411 119 2104 WASHER V 4X9X0.8 4 748R--310-285
286 411 054 8506 NUT HEX 4 4 748R--310-286
R-3
