SIPLACE OIS V11.2 / Software Version Description Ausgabe 05/2014 Edition

3.4 Platform for 70x station software

Supported machines: Data interface for capturing the station

software operating data:

SIPLACE X4i Version 701.xx and higher

SIPLACE X2, X3, X4 Version 702.xx and higher

SIPLACE SX1, SX2 Version 703.xx and higher

SIPLACE SX4 Version 704.xx and higher

SIPLACE DX1, DX2, DX4 Version 705.xx and higher

SIPLACE SX1/SX2 V2 Version 706.0 and higher

SIPLACE X3 S, X4 S, X4i S Version 706.1 and higher

SIPLACE X2 S, X4 S micron,

X4i S micron, CA4, CA4 eWLP

Version 707.x and higher

3.5 Compact Line machines

Supported machines: SIPLACE CS, CF

Data interface for capturing the station software operating data:

● Version 101.xx and 408.xx

SIPLACE OIS V11.2 / Software Version Description Ausgabe 05/2014 Edition

4 Prerequisites

NOTICE

System requirements

The Support Media DVD included in the installation package checks the necessary

system requirements of your system and installs these. Amongst others e.g. Microsoft

.NET Framework, the License Manager and the Error Reporting tool.

The use of the Support Media V1.16 is obligatory.

The system requirements (supported operating systems and database variants) and an

overview of the interoperable products can be found in the SIPLACE Support Media

Installation Manual, item no. [00197214-xx].

4.1 OIS/SIS functionality

● The hard disk must have at least 200 MB of free memory.

4.2 OIS Client

● The hard disk must have at least 20 MB of free memory.

● When the system is used on a SIPLACE machine, the station computer must have at least

128 MB of main memory.

● Monitoring Service must be installed.

● You must know the TCP/IP address or the UNC name (e.g. \\server-name) of the Monitoring

Service.

● A compatible version of the station software must be installed (see chapter 3, Interfaces for OIS

client).

● A network connection to the Monitoring Service is available.

4.3 Monitoring functionality

● The hard disk must have at least 200 MB of free memory.

SIPLACE OIS V11.2 / Software Version Description Ausgabe 05/2014 Edition

5 New Features

The SIPLACE OIS 11.2 version does not contain any new features.

If not differently described, the features of previous SIPLACE OIS versions are contained in the

SIPLACE OIS 11.2 version.
