– 40 – 8mm WD 1 Joint Detection Unit 1710-006 WD Joint Detection Unit DS-28080 18 15 13 1 1 17 16 12 14 19 3 4 5
– 39 –
Tape Feeder GT-28080,28082
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi
GT-28080 GT-28082
445 KYD-MCN3J-00 211DD071 PLATE 1 1
446 90990-06J004 221A0231 BOLT,HEX-SCT 2 2 BUTTAN M3L4
454 KYD-MCN3G-00 211AD802 COVER(MOTOR) 1 1
473 90990-01J120 221A0298 BOLT,HEX-SCT 4 4 M2L5
4A5 KYD-MCN42-00 222M1492 SPRING_COMP 2 2
4B2 KYM-M861H-00 022Q0004 ASSY,SPRING,FLAT 2 2
4B3 90990-08J035 221DB001 MACHINE SCREW 2 2 PAN M2L4 SW+FWS
4C1 KYM-M860R-00 212B2303 CHUTE(R) 1 1
4C2 KYM-M8601-00 016S1047 ASSY,LEVER 1
4C2
KYH-M862E-00
0926B32S ASSY_LEVER 1
4C3 KYD-MCN1U-00 0926B300 BLOCK 1 1
4C4 KYD-MCN3U-00 216F0880 PIN_GUIDE 1 1
4C5 KYD-MCN3V-00 216F0881 PIN_GUIDE 1 1
4C6 KYD-MCN43-00 222P0200 SPRING_TORSION 1 1
4C7 90990-02J037 221C0100 SET SCREW(SET SCREW) 2 2 SET M2L3
4C8 KYD-MC108-00 0804000K NAME PLATE 1
4D1 KYM-M864S-00 212B2304 CHUTE(L) 1 1
4D2 KYH-M862C-00 0926B32R ASSY_LEVER 1
4D2 KYH-M861Y-00 0926B302 ASSY_LEVER 1
4D3 KYD-MCN1U-00 0926B300 BLOCK 1 1
4D4 KYD-MCN3U-00 216F0880 PIN_GUIDE 1 1
4D5 KYD-MCN3V-00 216F0881 PIN_GUIDE 1 1
4D6 KYD-MCN43-00 222P0200 SPRING_TORSION 1 1
4D7 90990-02J037 221C0100 SET SCREW(SET SCREW) 2 2 SET M2L3
4D8 KYD-MC108-00 0804000K NAME PLATE 1
1710-006
– 41 –
Joint Detection Unit DS-28080
1710-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
3 KYD-MC605-00 0804000N PLATE_INDEX 1
4 KYD-MC606-00 0804000P PLATE_INDEX 1
5
90990-01J150
221AA98 BOLT_HEX-SCT 2 M4L20 SW+FW
11 KYH-M8613-00 0926J000 FRAME 1
12 KYD-MC10U-00 016S0729 ASSY_LEVER 1
13 KYM-M863P-00 211A8923 COVER 1
14 KYD-MC13U-00 222P0183 SPRING_TORSION 1
15 90440-01J025 221KB002 RING_E_025W 1
16 KYD-MC140-00 23G10090 SENSOR_PHOTO 2
17 90166-12J206 221DA065 MACHINE_SCREW 4 PAN M2L6 SW+FWS
18 90167-02JA06 221DA103 MACHINE SCREW 2 FLT M2.5L6
19 KYM-M863Y-00 212A2269 GUIDE 1
