USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 69

Power Modules

GoTo Focused Delivery Program: I/O

IndraControl S20 (IP20) - Power Modules

This IndraControl S20 module is used to feed the local bus supply within

an IndraControl S20 station. The module is connected locally to the

IndraControl XM controller or remotely using an IndraControl S20 eldbus

coupler.

For complete engineering and design information: GoTo www.boschrexroth-us.com/GoToIO

Features

• IP20 rating

• Diagnostic and status indicators

• Logic voltage 24 VDC

• Logic power supply 4 A

Part Number Description Max. Quantity Shipment (Business Days)

R911173345 S20-PWR 3 5 day(s)

70 Bosch Rexroth Corporation Electric Drives and Controls GoTo | USC00017/10.2021

Inline - Cabinet Mount (IP20)

Power Modules

GoTo Focused Delivery Program: I/O

Inline - Cabinet Mount (IP20) - Power Modules

Compact modules utilizing spring-cage I/O connectors. Provide either 24

V DC to all PLC busses (Logic, Input, Output, Analog). Segment modules

create separate "zone" of I/O to which power can be selectively cut-off.

For complete engineering and design information: GoTo www.boschrexroth-us.com/GoToIO

Features

• 2 available DC power modules to add only the power needed

• Wiring terminals easily removed, to allow module replacement without rewiring

• Single power module can provide up to 8A of 24 V DC power to PLC busses

Part Number Description Max. Quantity Shipment (Business Days)

R911170789 R-IB IL 24 PWR IN-PAC 5 3 day(s)

R911170710 R-IB IL 24 SEG/F-D-PAC 5 3 day(s)

R911170790 R-IB IL 24 SEG/F-PAC 5 3 day(s)

USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 71

Bus Couplers

GoTo Focused Delivery Program: I/O

Inline - Cabinet Mount (IP20) - Bus Couplers

Sercos III, Probus and Modbus TCP available. Bus couplers provide

network drops that are expandable with using the same Inline I/O that is

used locally with a PLC.

For complete engineering and design information: GoTo www.boschrexroth-us.com/GoToIO

Features

• Wiring terminals easily removed to allow module replacement without rewiring

• Sercos III bus coupler for an entire Sercos III eld bus architecture

• Congurable network speeds

Part Number Description Max. Quantity Shipment (Business Days)

R911172194 R-IL PB BK DI8 DO4/CN-PAC 5 3 day(s)

R911170971 R-IL PB BK DP/V1-PAC 5 3 day(s)

R911170875 R-IL S3 BK DI8 DO4-PAC 5 3 day(s)
