8 Bosch Rexroth Corporation Electric Drives and Controls GoTo | USC00017/10.2021
Drive Systems
IndraDrive Cs - Drives
GoTo Focused Delivery Program: Drive Systems
IndraDrive Cs - Drives
The IndraDrive Cs is a servo drive that features a compact space-saving
design. Selectable Multi-Protocol Ethernet command interface provides the
exibility of choosing any open Ethernet controller for the system, SERCOS
III for example. A Multi-encoder interface allows use of the platform
with virtually any motor technology, for instance torque or linear motor
technologies.
For complete engineering and design information: GoTo www.boschrexroth-us.com/GoTodrivesystems
Features
• Extremely compact design
• Ethernet-based communications, multi-protocol support: SERCOS III, Pro Net IO, EtherNet/IP and EtherCat
• Innovative multi-encoder interface: Hiperface, EnDat 2.1, 1Vss, 5 V TTL, and Rexroth MSM and MSK servo
motors
• Energy efcient product - DC bus sharing
• Standard, Servo and Synchronization modes available
• Complete range of scalable drives
• Compatible with the IndraDrive family
• Digital inputs/outputs and analog input on board
• Intelligent operating panel with programming function supports device swap without a PC
• Integrated brake resistor, alternative an external brake resistor can be connected
USC00017/10.2021 | Electric Drives and Controls GoTo Bosch Rexroth Corporation 9
Part Number Description Max. Quantity Shipment (Business Days)
R911333290 FWA-INDRV*-MPB-17VRS-D5-1-ALL-ML 5 5 day(s)
R911333280 FWA-INDRV*-MPB-17VRS-D5-1-ALL-NN 5 5 day(s)
R911333283 FWA-INDRV*-MPB-17VRS-D5-1-NNN-NN 5 5 day(s)
R911333284 FWA-INDRV*-MPB-17VRS-D5-1-SNC-NN 5 5 day(s)
R911339321 FWA-INDRV*-MPB-18VRS-D5-1-NNN-NN 5 5 day(s)
R911339323 FWA-INDRV*-MPB-18VRS-D5-1-SNC-NN 5 5 day(s)
R911339325 FWA-INDRV*-MPB-18VRS-D5-1-SRV-NN 5 5 day(s)
R911347129 FWA-INDRV*-MPB-20VRS-D5-0-MSP-NN 5 5 day(s)
R911347132 FWA-INDRV*-MPB-20VRS-D5-0-NNN-NN 5 5 day(s)
R911347135 FWA-INDRV*-MPB-20VRS-D5-1-ALL-MA 5 5 day(s)
R911347136 FWA-INDRV*-MPB-20VRS-D5-1-ALL-ML 5 5 day(s)
R911347137 FWA-INDRV*-MPB-20VRS-D5-1-ALL-NN 5 5 day(s)
R911347138 FWA-INDRV*-MPB-20VRS-D5-1-MSP-ML 5 5 day(s)
R911347139 FWA-INDRV*-MPB-20VRS-D5-1-MSP-NN 5 5 day(s)
R911347140 FWA-INDRV*-MPB-20VRS-D5-1-NNN-ML 5 5 day(s)
R911347141 FWA-INDRV*-MPB-20VRS-D5-1-NNN-NN 5 5 day(s)
R911347142 FWA-INDRV*-MPB-20VRS-D5-1-SNC-ML 5 5 day(s)
R911347143 FWA-INDRV*-MPB-20VRS-D5-1-SNC-NN 5 5 day(s)
R911347145 FWA-INDRV*-MPB-20VRS-D5-1-SRV-NN 5 5 day(s)
R911339345 FWA-INDRV*-MPC-18VRS-D5-1-ALL-MA 1 5 day(s)
R911339352 FWA-INDRV*-MPC-18VRS-D5-1-NNN-ML 1 5 day(s)
R911339355 FWA-INDRV*-MPC-18VRS-D5-1-SNC-ML 1 5 day(s)
R911339356 FWA-INDRV*-MPC-18VRS-D5-1-SNC-NN 1 5 day(s)
R911347114 FWA-INDRV*-MPC-20VRS-D5-1-ALL-MA 1 5 day(s)
R911347115 FWA-INDRV*-MPC-20VRS-D5-1-ALL-ML 1 5 day(s)
R911347116 FWA-INDRV*-MPC-20VRS-D5-1-ALL-NN 1 5 day(s)
R911347106 FWA-INDRV*-MPC-20VRS-D5-1-MSP-NN 1 5 day(s)
R911347108 FWA-INDRV*-MPC-20VRS-D5-1-NNN-ML 1 5 day(s)
R911347109 FWA-INDRV*-MPC-20VRS-D5-1-NNN-NN 1 5 day(s)
R911347110 FWA-INDRV*-MPC-20VRS-D5-1-SNC-ML 1 5 day(s)
R911347111 FWA-INDRV*-MPC-20VRS-D5-1-SNC-NN 1 5 day(s)
R911347112 FWA-INDRV*-MPC-20VRS-D5-1-SRV-ML 1 5 day(s)
R911347113 FWA-INDRV*-MPC-20VRS-D5-1-SRV-NN 1 5 day(s)
R911339297 FWA-INDRV*-MPE-18VRS-D5-1-NNN-NN 3 5 day(s)
R911347464 FWA-INDRV*-MPE-20VRS-D5-1-NNN-NN 3 5 day(s)
R911330278 FWS-INDRV*-MP*-**VRS-NN-ETHERCAT 5 5 day(s)
R911330279 FWS-INDRV*-MP*-**VRS-NN-ETHERNETIP 5 5 day(s)
R911330280 FWS-INDRV*-MP*-**VRS-NN-PROFINETIO 5 5 day(s)
R911331601 HCS01.1E-W0005-A-03-B-ET-EC-NN-L4-NN-FW 3 5 day(s)
R911326038 HCS01.1E-W0005-A-03-B-ET-EC-NN-NN-NN-FW 3 5 day(s)
R911331617 HCS01.1E-W0006-A-02-B-ET-EC-NN-L4-NN-FW 3 5 day(s)
R911325243 HCS01.1E-W0006-A-02-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
R911335596 HCS01.1E-W0008-A-03-B-ET-EC-NN-L3-NN-FW 3 5 day(s)
R911331605 HCS01.1E-W0008-A-03-B-ET-EC-NN-L4-NN-FW 5 5 day(s)
R911325246 HCS01.1E-W0008-A-03-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
R911340077 HCS01.1E-W0008-A-03-B-ET-EC-NN-S4-NN-FW 3 5 day(s)
R911338054 HCS01.1E-W0008-A-03-E-S3-EC-NN-L3-NN-FW 3 5 day(s)
R911328445 HCS01.1E-W0008-A-03-E-S3-EC-NN-NN-NN-FW 3 5 day(s)
R911331620 HCS01.1E-W0009-A-02-B-ET-EC-NN-L4-NN-FW 3 5 day(s)
R911326040 HCS01.1E-W0009-A-02-B-ET-EC-NN-NN-NN-FW 3 5 day(s)
R911331624 HCS01.1E-W0013-A-02-B-ET-EC-NN-L4-NN-FW 5 5 day(s)
R911325245 HCS01.1E-W0013-A-02-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
10 Bosch Rexroth Corporation Electric Drives and Controls GoTo | USC00017/10.2021
R911327329 HCS01.1E-W0018-A-03-B-ET-EC-EC-NN-NN-FW 3 5 day(s)
R911338289 HCS01.1E-W0018-A-03-B-ET-EC-NN-L3-NN-FW 3 5 day(s)
R911331608 HCS01.1E-W0018-A-03-B-ET-EC-NN-L4-NN-FW 5 5 day(s)
R911325247 HCS01.1E-W0018-A-03-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
R911337330 HCS01.1E-W0018-A-03-E-S3-EC-NN-L3-NN-FW 3 5 day(s)
R911328446 HCS01.1E-W0018-A-03-E-S3-EC-NN-NN-NN-FW 3 5 day(s)
R911335595 HCS01.1E-W0028-A-03-B-ET-EC-NN-L3-NN-FW 3 5 day(s)
R911331611 HCS01.1E-W0028-A-03-B-ET-EC-NN-L4-NN-FW 5 5 day(s)
R911325248 HCS01.1E-W0028-A-03-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
R911340084 HCS01.1E-W0028-A-03-B-ET-EC-NN-S4-NN-FW 3 5 day(s)
R911340386 HCS01.1E-W0028-A-03-E-S3-EC-NN-L3-NN-FW 3 5 day(s)
R911328447 HCS01.1E-W0028-A-03-E-S3-EC-NN-NN-NN-FW 3 5 day(s)
R911336673 HCS01.1E-W0054-A-03-B-ET-EC-NN-L3-NN-FW 3 5 day(s)
R911332723 HCS01.1E-W0054-A-03-B-ET-EC-NN-L4-NN-FW 5 5 day(s)
R911331185 HCS01.1E-W0054-A-03-B-ET-EC-NN-NN-NN-FW 5 5 day(s)
R911336255 PFM04.1-512-NW 5 5 day(s)
