VERSION: .1.01 E
43 / 52
Q11,15 （Q: Label length，gap between 2 labels）
JF （JF：Enable label return）
D13 （D: Print definition）
S2 （S: Print speed）
O （O:Option）
A186,0,0,1,1,1,N,"SKID:@S0"
A185,15,0,1,1,1,N,"Quantity:@C"
B185,30,0,1,1,1,16,N,"@C"
A185,50,0,1,1,1,N,"Operator:@S1"
A160,68,0,1,1,1,N,"Time:@Y-@M-@D @H:@m"
P1,1 （P:Label number，number of copies）
Please see below for more information about the long sentence：
A：Print text
B：Print 1D barcode
N：Do not print barcode text (change the 8th digit 'N' to 'B' to print barcode
with text)
The six digit numbers represent: horizontal coordinate, vertical coordinate,
text rotation direction, barcode width, barcode height, and font style
(default is Style 1)
“”:The content to be printed is enclosed in double quotation marks.
@S0 : The content when scan at the first time.
@S1 : The content when scan at the second time.
@C ：Quantity after counting.
@Y-@M-@D @H:@m ：Date&Time.
The printing effect of the above code content is as below：
SKID:C0805ZKY5V6BB
Quantity:347
Operator:ZHANG SAN
Time:2024-01-01 12:00
VERSION: .1.01 E
44 / 52
When the print code is set, click "PRINTER SET" and the device gives a "beep"sound, the
print format setting is successful and the settings are permanently saved unless it is
changed next time.
5.4.3 Set the rotating speed of counting motor
VERSION: .1.01 E
45 / 52
Our factory default set speeds are: low-speed S1=15, medium speed S2=30,
high-speed S3=45. If you have specific requirements for the set speeds, you
can directly change the corresponding speed values.
5.4.4 Change password
The factory-set password is：root，if you want to change the password,
just fill new password in the input column and click
to save the new password
If you forget your password, you can click 10 times and the left page
will appear.
