QP-242E P ARTS LIST ver1 1 8 - 1 8 . ノズルチェンジ A ( * S - 6 * * ) ( * S - 7 * * ) ( B H P M ) 8 . N o z z l e c h a n g e A ( * S - 6 * * ) ( * S - 7 * * ) ( B H P M ) 8 . ノズルチェンジ A ( * S - 6 * * ) ( * S - 7 * * ) ( B H P M…
7.ヘッド,マークカメラ(BHPH)
7.Head,Mark camera(BHPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
183 BHPH0210 1 NAMEPLATE 銘板 Japanese/English
184 BHPH0220 1 NAMEPLATE 銘板 Japanese/English
注1. No.146ｷﾞﾔとNo.147ｷﾞﾔは組み合わせ部品ですので同時に交換して下さい｡ ･
注2. No.14ｶﾗｰとNo.15ｶﾗｰは組み合わせ部品ですので同時に交換して下さい｡
Note.1:Gears No.146 and No.147 are used as set.If the replacement of one of the gears is necessary both must be replaced.
Note.2:Collars No.14 and No.15 are used as set.If the replacement of one of the collars is necessary both must be replaced.
QP-242E PARTS LIST ver11
7 - 6
7.ヘッド,マークカメラ(BHPH)
7.Head,Mark camera(BHPH)
QP-242E PARTS LIST ver11
8 - 1
8.ノズルチェンジ A(*S-6**)(*S-7**)(BHPM)
8.Nozzle change A(*S-6**)(*S-7**)(BHPM)
8.ノズルチェンジ A(*S-6**)(*S-7**)(BHPM)
8.Nozzle change A(*S-6**)(*S-7**)(BHPM)
1
2
4
20
20
23
5
8
8
12
18
18
18
18
18
18
18
18
18
18
3
9
38
33
33
38
42
31
31
42
66
39
34
26
39
34
26
26
34
39
39
34
26
39
34
26
39
34
26
39
34
26
43
43
66
39
34
26
39
34
26
39
34
26
A
A
39
34
70
45
37
32
14
17
11
28
35
27
35
21
21
52
54
53
54
50
54
51
49
54
47
54
35
55
16
48
35
55
54
47
49
51
35
66
16
15
56
30
36
13
31
37
7
22
28
35
57
58
38
62
60
61
63
17
63
64
65
59
59
54
54
67
68
68
71
71
6
8.ノルズチェンジA(*S-6**)(*S-7**)(BHPM)
8.Nozzle change A(*S-6**)(*S-7**)(BHPM)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 BHPM1350 1 BKT CYLINDER BKT ｼﾘﾝﾀﾞ
2 BHPM1281 1 PLATE ﾌﾟﾚｰﾄ
3 BHPM1271 1 HOLDER ﾎﾙﾀﾞ
4 BHPM0241 1 SHUTTER ｼｬｯﾀ
5 BHPM0250 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ
6 ABHPM0450 5 PISTON ﾋﾟｽﾄﾝ
7 BHPM1430 1 BKT CYLINDER BKT ｼﾘﾝﾀﾞ
8 BHPM1241 2 BKT, SENSOR BKT ｾﾝｻ
9 BHPM1340 1 PLATE ﾌﾟﾚｰﾄ
11 BHPM0281 1 BKT, SENSOR BKT ｾﾝｻ
12 BHPM0191 5 SPRING ｽﾌﾟﾘﾝｸﾞ
13 S2100Z 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQ2A12-15DM-A73L
14 BHPH1311 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
15 BHPM1560 1
KNUCKLE
ﾅｯｸﾙ
16 Y3079N 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5
17 Y3078A 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-01S-X15
18 S4028T 5 SENSOR ｾﾝｻ EX-11EA-R-C2
20 R5005A 5 ROLLER, NEEDLE ﾛｰﾗ ﾆｰﾄﾞﾙ ﾟ1.5X6.8
21 S3135A 1 SW, PHOTOELECTRIC SW 光電 PS-52
22 A1040H 1
AMPLIFIER
ｱﾝﾌﾟ PS2-61
23 BHPM0080 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ
26 K5175X
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋
M2X8L
27 H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L
28 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
30 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
31 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
32 H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
33 H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L
34 W1020A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M
35 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
36 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
37 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
38 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
39 W1039A
WASHER, FLAT
ﾜｯｼｬ 平
2M/M
42 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L
43 K5186W
SCREW, COUNTERSUNK
小ﾈｼﾞ 皿
M3X8L
45 BHPM0170 1 BKT BKT
QP-242E PARTS LIST ver11
8 - 2
8.ノルズチェンジﾞA(*S-6**)(*S-7**)(BHPM)
8.Nozzle change A(*S-6**)(*S-7**)(BHPM)
