78.MTU-71E カバー(BHTC) 78.MTU-71E Cover(BHTC) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg. No. & Code No. QTY Description Rating Remarks 1 BHTC2010 1 PLATE ﾌﾟﾚｰﾄ 2 BHTC2021 8 RETAINER, ACRYLIC 押え ｱｸﾘﾙ 3 BHTC2030 1 BOX BOX 4…
QP-242E PARTS LIST ver11
78.MTU-71E カバー(BHTC)
78.MTU-71E Cover(BHTC)
78 - 1
78.MTU-71E カバー(BHTC)
78.MTU-71E Cover(BHTC)
Ref.33-7
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
B
B
F
F
G
G
15
15
15
46
18
60
46
60
46
60
57
63
6
63
57
73
57
58
39
5
8
57
63
60
67
62
55
44
62
55
3
70
10
7
58
63
56
12
12
58
58
56
63
38
4
70
55
62
44
63
50
52
48
71
53
57
1
D
C
C
D
61
64
67
13
16
26
19
75
65
47
45
23
30
64
59
28
22
58
65
75
21
31
17
25
75
64
14
67
59
21
68
75
27
31
58
28
69
75
22
19
24
67
64
61
54
33
64
60
49
51
34
51
35
37
36
32
63
58
43
67
59
42
75
20
9
76
2
75
75
75
75
2
2
2
75
2
75
75
2
75
2
2
76
59
64
29
77
77
78
78
x11
49
71
63
51
33
54
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
78.MTU-71E カバー(BHTC)
78.MTU-71E Cover(BHTC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
1 BHTC2010 1 PLATE ﾌﾟﾚｰﾄ
2 BHTC2021 8 RETAINER, ACRYLIC 押え ｱｸﾘﾙ
3 BHTC2030 1 BOX BOX
4 BHTC2040 1 COVER ｶﾊﾞｰ
5 BHTC2075 1 COVER, OVERALL ｶﾊﾞｰ 全体
6 BHTC2090 1 BKT, COVER BKT ｶﾊﾞｰ
7 BHTC2104 1 COVER, CONVEYOR ｶﾊﾞｰ ｺﾝﾍﾞｱ
8 BHTC2110 1 BKT, COVER BKT ｶﾊﾞｰ
9 BHTC2121 1 DOOR 扉
10 BHTC2130 1 COVER, SAFETY ｶﾊﾞｰ 安全
12 BHTC2150 2 BKT, COVER BKT ｶﾊﾞｰ
13 BHTC2160 1 PLATE, STOPPER ﾌﾟﾚｰﾄ ｽﾄｯﾊﾟ
15 BHTC2180 3 COLLAR, SPACER ｶﾗｰ ｽﾍﾟｰｻ
16 BHTC2190 1 ARM ｱｰﾑ
17 BHTC2200 1 COLLAR ｶﾗｰ
18 BHTC2211 1 CAM, PLATE ｶﾑ 板
19 BHTC2220 2 SPRING ｽﾌﾟﾘﾝｸﾞ
20 BHTC2230 1 BKT BKT
21 BHTC2240 2 BKT BKT
22 BHTC2250 2 PIN, PIVOT ﾋﾟﾝ 支点
23 BHTC2260 1 PIN, PIVOT ﾋﾟﾝ 支点
24 BHTC2270 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
25 BHTC2280 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
26 BHTC2290 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
27 BHTC2300 1 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ
28 BHTC2310 2 BUSHING ﾌﾞｯｼｭ
29 BHTC2320 1 ARM ｱｰﾑ
30 BHTC2331 1 BKT BKT
31 BHTC2340 2 STOPPER ｽﾄｯﾊﾟ
33 BHTC2530 1 BKT BKT
38 BHTC2410 1 PANEL, CONNECTOR ﾊﾟﾈﾙ ｺﾈｸﾀ
39 BHTC2420 1 BKT BKT
42 H1018C 1 HANDLE ﾊﾝﾄﾞﾙ THA-171-2(NO.3875)
43 K1046T 1 FIXTURE 金具 THA-266-2(NO.2)
44 . 2 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-77S(NO.1197)
45 H4254T 1
BEARING
ﾍﾞｱﾘﾝｸﾞ 626ZZ
46 K1138T 3
COLLAR
ｶﾗｰ R8
QP-242E PARTS LIST ver11
78 - 2
78.MTU-71E カバー(BHTC)
78.MTU-71E Cover(BHTC)
78.MTU-71E カバー(BHTC)
78.MTU-71E Cover(BHTC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
47 W1004K 1 WASHER ﾜｯｼｬ LRB6-1.0
48 S31991 1
SW, LIMIT
SW ﾘﾐｯﾄ XCS-PA591
49 S31975 1
SW, LIMIT
SW ﾘﾐｯﾄ XCS-Z13
50 H5295A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X35L
51 H5296A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X40L
52 N2029X 1 NIPPLE ﾆｯﾌﾟﾙ ST11 5301 5020
54 BHTA2520 1 NUT ﾅｯﾄ
55 H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L
56 H5285A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5L
57 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L
58 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
59 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
60 H5301A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X18L
61 H5305A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X30L
62 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
63 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
64 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
65 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
67 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
68 W1050A
WASHER, FLAT
ﾜｯｼｬ 平
5M/MX1.0X10(1W-5)
69 W1051A
WASHER, FLAT
ﾜｯｼｬ 平
6M/MX1.6X125(1W-6)
70 K5206A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M4X4L
71 W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
73 K5210A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M4X10L
75 N1082A
NUT, HEX
ﾅｯﾄ 六角
M5 P=0.8
76 ABHTC2451 2 COVER, ACRYLIC ｶﾊﾞｰ ｱｸﾘﾙ Brown Smoke
77 ABHTC2431 2 COVER, ACRYLIC ｶﾊﾞｰ ｱｸﾘﾙ Smoke(Option)
78 ABHTC2491 2 COVER, ACRYLIC ｶﾊﾞｰ ｱｸﾘﾙ Clear(Option)
