77.2.MTU-71E TZ軸(BHTC) 77.2.MTU-71E TZ axis(BHTC) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 No. Drg. No. & Code No. QTY Description Rating Remarks 60 BHTA0660 1 PULLEY ﾌﾟｰﾘ 62 BHTA0651 2 PULLEY ﾌﾟｰﾘ 63 IGK1040 1 COLLAR, SPACER …
77.2.MTU-71E TZ軸(BHTC)
77.2.MTU-71E TZ axis(BHTC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
6 BHTC0061 1 PLATE ﾌﾟﾚｰﾄ
7 BHTC0070 1 PLATE ﾌﾟﾚｰﾄ
8 BHTC0082 1 PLATE ﾌﾟﾚｰﾄ
9 BHTC0092 1 PLATE ﾌﾟﾚｰﾄ
10 BHTC0100 10 STOPPER ｽﾄｯﾊﾟ
12 BHTC0120 1 SHAFT ｼｬﾌﾄ
13 BHTC0130 1 BLOCK ﾌﾞﾛｯｸ
16 BHTC0160 20 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ
17 BHTC0170 20 STOPPER ｽﾄｯﾊﾟ
18 BHTC0180 2 BALL SCREW ﾎﾞｰﾙﾈｼﾞ
19 BHTC0620 10 PLATE ﾌﾟﾚｰﾄ
20 BHTC0201 10 PLATE ﾌﾟﾚｰﾄ
28 BHTC0280 20 SHAFT ｼｬﾌﾄ
29 BHTC0290 20 COLLAR ｶﾗｰ
30 BHTC0300 30 NUT ﾅｯﾄ
31 BHTC0311 10 BKT BKT
32 BHTC0321 11 TRAY ﾄﾚｲ
33 BHTC0331 10 PLATE, STOPPER ﾌﾟﾚｰﾄ ｽﾄｯﾊﾟ
34 BHTC0340 30 NUT ﾅｯﾄ
37 BHTC0380 1 STOPPER ｽﾄｯﾊﾟ
38 BHTC0391 10 PLATE ﾌﾟﾚｰﾄ
39 BHTC0400 18 PLATE ﾌﾟﾚｰﾄ
40 BHTC0420 1 NAMEPLATE 銘板
41 BHTC0430 1 BKT BKT
42 BHTC0440 1 BKT BKT
43 BHTC0451 1 DOG ﾄﾞｯｸﾞ
47 BHTC0490 1 DOG ﾄﾞｯｸﾞ
48 BHTC0500 1 DOG ﾄﾞｯｸﾞ
49 BHTC0510 1 DOG ﾄﾞｯｸﾞ
51 BHTC0530 2 NUT ﾅｯﾄ
52 BHTC0540 6 NUT ﾅｯﾄ
53 BHTC0550 10 PLATE, STOPPER ﾌﾟﾚｰﾄ ｽﾄｯﾊﾟ
54 BHTC0560 10 PIN, PIVOT ﾋﾟﾝ 支点
55 BHTC0570 10 BKT BKT
56 BHTC0580 20 SPRING ｽﾌﾟﾘﾝｸﾞ
58 BHTC0600 1 NAMEPLATE 銘板 Option
59 BHTA0150 2 STOPPER ｽﾄｯﾊﾟ
QP-242E PARTS LIST ver11
77 - 5
77.2.MTU-71E TZ軸(BHTC)
77.2.MTU-71E TZ axis (BHTC)
77.2.MTU-71E TZ軸(BHTC)
77.2.MTU-71E TZ axis(BHTC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
60 BHTA0660 1 PULLEY ﾌﾟｰﾘ
62 BHTA0651 2 PULLEY ﾌﾟｰﾘ
63 IGK1040 1 COLLAR, SPACER ｶﾗｰ ｽﾍﾟｰｻ
65 IPB0420 1 COLLAR ｶﾗｰ
66 ABHTA2080 60 GUIDE, SIDE ｶﾞｲﾄﾞ ｻｲﾄﾞ
67 ABHTB1030 20 GUIDE, SIDE ｶﾞｲﾄﾞ ｻｲﾄﾞ
69 H4567A 2
BEARING UNIT
ﾍﾞｱﾘﾝｸﾞﾕﾆｯﾄ WBK08-11-DB
70 H30712 2 BUSHING ﾌﾞｯｼｭ PL006X017KE
71 H4242A 2
BEARING
ﾍﾞｱﾘﾝｸﾞ RF-2280ZZ
72 S1024A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-6
75 SAM3060 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ RB29GIGT4B1
77 H4452D 20 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ W683ZZ
78 H4476G 1 BELT ﾍﾞﾙﾄ 1374-3GT-15
79 A10105 1 ADJUSTER ｱｼﾞｬｽﾀ AJST6-30
82 S1040A 20
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW3
88 H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L
89 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
91 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L
92 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
93 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
94 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
95 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L
96 H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X18L
99 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
100 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
104 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
105 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
106 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
107 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
109 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
110 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
111 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
112 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
113 W1040A WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7
114 W1041A
WASHER, FLAT
ﾜｯｼｬ 平
4M/MX0.8X9(1W-4)
116 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L
118 N4029A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X8L
QP-242E PARTS LIST ver11
77 - 6
77.2.MTU-71E TZ軸(BHTC)
77.2.MTU-71E TZ axis (BHTC)
77.2.MTU-71E TZ軸(BHTC)
77.2.MTU-71E TZ axis(BHTC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No.
Drg. No. & Code No.
QTY Description Rating Remarks
120 N1085A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0
123 .
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋
M2.6X5L
124 BHTC0660 10 GUIDE ｶﾞｲﾄﾞ
125 BHTC0670 10 GUIDE ｶﾞｲﾄﾞ
126 H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X12L
127 BHTA1221 1 PULLEY, MOTOR ﾌﾟｰﾘ ﾓｰﾀ
128 BHTA1230 1 CAP ｷｬｯﾌﾟ ･
QP-242E PARTS LIST ver11
77 - 7
