Immediate stop after one pick action
Chapter
Immediate Stop by One Pick ......................................................................................................... 1
1.
Target model and Target version............................................................................................2
2.
Outline of Function .................................................................................................................3
3.
Detail of Function ...................................................................................................................3
3.1 Behavior ...............................................................................................................................3
3.2 Restrictions ..........................................................................................................................3
3.3 Error Message .....................................................................................................................4
3.4 Log .......................................................................................................................................5
4.
Setting ....................................................................................................................................9
Revision
Content Date
1
New
2011/8/23
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50136
2/10
1. Target model and Target version
The target model and the target version of this specification are as follows.
Table1 Target Machine and Software
Machine, Software Version Remarks
YS Series Mounter, YG300
YG12 Series Mounter, YSP, YSC1
V3.27STD R1.000 or later
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50136
3/10
2. Outline of Function
This function makes a vacuum check of every single pick action. If the vacuum is not correct,
the machine is stopped immediately.
Without this function, when a head failed to pick one of the same parts group, machine was
stopped after the other heads finished picking rest of the group.
With this function, machine is stopped just after a pickup failure is detected by vacuum
check, without feeding or moving heads.
3. Detail of Function
3.1 Behavior
This function checks a pick up vacuum by each pick action. If vacuum level dose not reach
the specified value, the machine is stopped immediately. If vacuum level reaches the specified
value, the machine works normally.
3.2 Restrictions
There are some restrictions on this function as described below.
1. This function is NOT enabled for board data with [Standard] - [Vacuum Check] set to
[no use].
2. This function is enabled with [Pick Vacuum sensor chk] set to [special check] or
[normal check].
3. This function is enabled with [Package] set to [Tape]
4. Please note that when picking the target parts, each single head performs a
vacuum check, so that tact time becomes a little long.
