Immediate stop after one pick action
Chapter
Immediate stop after one pick action.............................................................................................1
1.
Target model and Target version............................................................................................2
2.
Outline of Function .................................................................................................................3
3.
Detail of Function ...................................................................................................................3
3.1 Behavior ............................................................................................................................... 3
3.2 Restrictions ..........................................................................................................................3
3.3 Error Message .....................................................................................................................4
3.4 Operation after error occurs.................................................................................................5
3.5 Log .......................................................................................................................................6
4.
Setting ..................................................................................................................................10
Revision
Version Chapter Contents
00 V3.28STD R1.000
All New
01 V3.31STD R1.000
All “Dump after 1pickup error” is added
marked with (Rev.01)
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50136
2/11
1. Target model and Target version
The target model and the target version of this specification are as follows.
Table1 Target Machine and Software
Machine, Software Version Remarks
YS Series Mounter, YG300
YG12 Series Mounter, YSP, YSC1
V3.28STD R1.000 or later
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50136
3/11
2. Outline of Function
This function makes a vacuum check of every single pick action. If the vacuum is not correct,
the machine is stopped immediately.
Without this function, when a head failed to pick one of the same parts group, machine was
stopped after the other heads finished picking rest of the group.
With this function, machine is stopped just after a pickup failure is detected by vacuum
check, without feeding or moving heads.
(Rev.01 add) When [Dump after 1pickup error] is set to “Use”, error heads are dumped
before pickup other heads just after restart auto-running. In this case, the tape is fed in the
next pick action.
3. Detail of Function
3.1 Operation
This function checks a pick up vacuum by each pick action. If vacuum level dose not reach
the specified value, the machine is stopped immediately. If vacuum level reaches the specified
value, the machine works normally.
3.2 Restrictions
There are some restrictions on this function as described below.
1. This function is NOT enabled for board data with [Standard] - [Vacuum Check] set to
“no use”.
2. This function is NOT enabled with [Pick&Mount Vacuum Check] set to “Ignore”.
3. This function is enabled with [Package] set to [Tape]
4. Please note that when picking the target parts, each single head performs a
vacuum check, so that tact time becomes a little long.
5.
The “Splicing point check” function of Parts Remain Counter cannot be used with this
function. It’s can be used only when [Dump after 1pickup error] is set to “Use”, but
“Ea7995: Part pick up error” doesn’t occur in “Splicing point check area”. (Rev.01 add)
