SM321-part list .pdf - 第30页

NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK 1 J3212022A PHOTO󰚟SENSOR 3 EE-SX674 2 J7054139A SENSOR󰚟PLATE󰚟2 1 J7054139A 3 J7054137A SENSOR󰚟PLATE󰚟4 1 J7054137A 4 J6607076A LM󰚟GUIDE 2 SSR15XW2UUC1+940LHY-II 5 J7054…

100%1 / 140
16
10
9
8
7
8
9
8
9
4
4
2
1
3
1
5
6
17
12
11
14
13
15
18
21
19
8
9
20
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
1 J3212022A PHOTO󰚟SENSOR
3
EE-SX674
2 J7054139A SENSOR󰚟PLATE󰚟2
1
J7054139A
3 J7054137A SENSOR󰚟PLATE󰚟4
1
J7054137A
4 J6607076A LM󰚟GUIDE
2
SSR15XW2UUC1+940LHY-II
5 J7054251A Y󰚟SENSOR󰚟DOG
1
J7054251A
6 J7154256A END󰚟BRACKET-X
1
J7154256A
7 J7154261B GUIDE󰚟CABLE󰚟CHAIN-X
1
J7154261B
8 J7354023A CABLE󰚟CUSHION󰚟X
4
J7354023A
9 J7054255A CUSHION󰚟BRACKET󰚟X
4
J7054255A
10 J7254016D INNER󰚟GUIDE-MAT
2
J7254016D
11 J7154095A END󰚟PLATE-X
1
J7154095A
12 J7054247A BRACKET󰚟CABLE󰚟CHAIN-Y
1
J7054247A
13 J7054256A CUSHION󰚟BRACKET󰚟Y
1
J7054256A
14 J7354024A CABLE󰚟CUSHION󰚟Y
1
J7354024A
15 J7154259A BRACKET󰚟CUSHION󰚟-X
1
J7154259A
16 J7354021A CUSHION-X
1
J7354021A
17 J7054246B SENSOR󰚟DOG-X
2
J7054246B
18 J7054295A CONNECTOR󰚟PANEL
1
J7054295A
19 J7154266A CABLEVEYOR󰚟BRACKET
1
J7154266A
20 J7054260A CABLE󰚟FIXER
1
J7054260A
21 J7054259A CABLE󰚟SPACER
1
J7054259A
22
23
24
25
26
27
4
1
10
3
2
5
6
7
8
9
