SM321-part list .pdf - 第5页

30 30 36 40 40 37 38 31 31 32 32 29 29 29 29 39 39 39 39 31 31 32 32 33 34 35

100%1 / 140
21
23
22
20
OM
RO
N
D
4
D
S
19
18
17
16
14
13
25
24
26
30
30
36
40
40
37
38
31
31
32
32
29
29
29
29
39
39
39
39
31
31
32
32
33
34
35
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
1
J7070291A COVER-M.M.U󰚟BRACKET 2 J7070291A
2
J7070290C CCOVER-M.M.U 1 J7070290C
3
J9052291A WINDOW-FRONT󰚟ASS'Y(SM320_STD) 2 J9052291A
3-A J7070219B WINDOW󰚟FRAME
1 J7070219B
3-B
J7252110B WINDOW-REAR 1 J7252110B
3-C
J6119051A HANDLE 1 AP-2󰚟BLACK
3-D
J6108007A HINGE 3 HINGE󰚟65*32
4 J7070355A
COVER-U.F.R 1 J7070355A
5
J7070297A MONITOR󰚟CABLE󰚟COVER 2 J7070297A
6
J7070286A COVER-U.M.R 1 J7070286A
7
J7070215C CONVEYOR󰚟COVER-R 1 J7070215C
8 J7070357A
COVER-U.R.R 1 J7070357A
9 J7070354A
COVER-U.F.L 1 J7070354A
10
J7070285B COVER-U.M.L 1 J7070285B
OPTION
OPTION
11
J7070214C CONVEYOR󰚟COVER-L 1 J7070214C
12 J7070358A
COVER-U.R.L-2 1 J7070358A
13 J9099194B
MONITOR󰚟ARM󰚟ASS'Y 1 J9099194B
14 J7070234C
MONITOR󰚟CAP󰚟BRACKET 1 J7070234C
15
J7352001A DOOR󰚟CUSHION 4 J7352001A
16 J6404001A DOOR󰚟KEY
2 D4DS-K3
17
J34091001A SAFETY󰚟DOOR󰚟SWITCH 2 D4NS-2BF
18
J7070218C SENSOR󰚟BRACKET󰚟2 2 J7070218C
19
J7070217C SENSOR󰚟BRACKET󰚟1 2 J7070217C
20
J6719050A GAS󰚟SPRING 4 HS22B-300-25
21
J7452036A HINGE󰚟JOINT 8 J7452036A
22
J7252088A SPACER 8 J7252088A
23
J7052927A GAS󰚟SPRING󰚟BRACKET󰚟1 4 J7052927A
