NO. PARTNO. PARTNAME Q'TY TYPE REMARK 45 J7155516A FIDUCIALCAMERABRACKET 1 J7155516A 46 J7155517A FIDUCIALCAMERACLAMP 1 J7155517A 47 J7155572A CAMERACABLEHOLDER 1 J7155572A 48 J6751014A CCDCAMERA 1…
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
23
J7155512A SENSORDOG 6
J7155512A
24
J70551002A BELT_CLAMP2 6
J70551002A
25
J70551001A
BELT_CLAMP1
6
J70551001A
26
J7055542C BALLSPLINE 6
J7055542C
27 J7155566A SIDETIEMOUNT
1
J7155566A
28
J7155513B SENSORDOG-R 3
J7155513B
29
J90551007A SPLINEHOUSINGASS'Y 6
J90551007A
30
J7055659A BEARINGPLATE 6
J7055659A
31
J7155520A PULLEY(R-AXIS1) 6
J7155520A
32 J9055209A COMMONNOZZLEHOLDERASSY
6
J9055209A
32-A J7055431B
NOZZLEHOLDER
1
J7055431B
32-B
J7055140A STEELBALL 3 DIA2,SUS304
32-C
J7255021B SILICONTUBE(BLACK) 1 SA0705-100B
33
J6602077A TIMINGBELT 3 236-2GT-4
34
J7155521B PULLEY(R-AXIS2)
3
J7155521B
35 J7055655A
THETAMOTORPLATE 1
J7055655A
36
J7255083A THETAMOTORISOLATOR 3
J7255083A
37-A
J9083190A R12_MOTOR_CABLE_ASSY 3 SM21-MD038
37-B
J90831009A R34_MOTOR_CABLE_ASSY 3 SM21-MD039
37-C
J90831010A R56_MOTOR_CABLE_ASSY 3 SM21-MD040
38
J9083184A RHOMESENSORCABLEASSY 1 SM21-HD013
39 J7055663A SENSORBRACKETR-M
1
J7055663A
40 J9080829A
SWINGMOTORCABLEASS'Y 1
SM_MD032
41
J7255081A MIRRORMOTORISOLATOR 1
J7255081A
42
J7155524A MIRRORMOTORBRACKET 1
J7155524A
43
J7155523A PULLEY(S-AXIS2) 1
J7155523A
44
J6602078A TIMINGBELT 1 255-3GT-6
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
45
J7155516A FIDUCIALCAMERABRACKET 1
J7155516A
46
J7155517A FIDUCIALCAMERACLAMP 1
J7155517A
47
J7155572A CAMERACABLEHOLDER 1
J7155572A
48
J6751014A CCDCAMERA 1 XC-ES50
49
J90591004A F-MOVING12058LENSASS'Y 1
J90591004A
50 J9060357B HEADOUTERLEDBOARDASSY
1
REV1.1
51
J9055357A PULLEYASSY(Z-AXIS2) 1 J9055357A
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
33
36
5
9
3
1
4
5
7
6
8
37
37-A
37-A
30
31
13
32
21
25
29
23
24
23
22
12
18
8
7
6
13
20
2
28
14
19
17
6
7
10
9
14
15
16
17
12
11
35
38
39
36
34
25
23
26
23
27
7
6
10
