Nozzle height with variab le Z -A xis Nozzle height with variab le Z -A xis ECOSEL EC T 1 ≤ 90 m m (M) ≤ 85 mm (M) SMART FLO W ≤ 75 mm (M) ----- ECOSEL EC T 2 ≤ 75 mm (K ) ≤ 59 mm (K ) V ER S A F L OW 3 ≤ 85 mm (R) ≤ 59 …
Finger Conveyor = (M)
Roller Conveyor = (R)
Pin Chain Conveyor = (K)
7
Nozzle height with variable Z-Axis Nozzle height with variable Z-Axis
ECOSELECT 1
≤ 90 mm (M) ≤ 85 mm (M)
SMARTFLOW
≤ 75 mm (M) -----
ECOSELECT 2
≤ 75 mm (K) ≤ 59 mm (K)
VERSAFLOW 3
≤ 85 mm (R) ≤ 59 mm (R)
ECOCELL
≤ 85 mm (R), 75 mm (K) ≤ 59 mm (R, K)
VERSAFLOW 4
≤ 85 mm (R) ≤ 59 mm (R)
S NOZZLE 4.0/8.0; H=75; B14,1
206303
1 pcs.
S NOZZLE 6.0/10.0; H=75; B14,1
206294
1 pcs.
S NOZZLE 8.0/12.0; H=75; B14,1
235693
1 pcs.
S NOZZLE 8.0/12.0; H=75; B14,1
251285
1 pcs.
S NOZZLE 3.0/6.0; H=80; B14,1
278549
1 pcs.
S NOZZLE 3.5/7.0; H=80; B14,1
213419
1 pcs.
S NOZZLE 4.0/8.0; H=80; B14,1
213417
1 pcs.
S NOZZLE 4.0/8.0; H=80; B14,1
251318
1 pcs.
S NOZZLE 10.0/14.0; H=75; B14,1
251316
1 pcs.
S NOZZLE 6.0/10.0; H=80; B14,1
211313
1 pcs.
S NOZZLE 6.0/10.0; H=80; B14,1
213418
1 pcs.
S NOZZLE 6.0/10.0; H=80; B14,1
251319
1 pcs.
Height 75 mm, B14,1
Height 80 mm, B14,1
Height 80 mm, B14,1
Height 75 mm, B14,1
Selective Soldering Nozzles
Nozzle height with variable Z-Axis Nozzle height with variable Z-Axis
ECOSELECT 1
≤ 90 mm (M) ≤ 85 mm (M)
SMARTFLOW
≤ 75 mm (M) -----
ECOSELECT 2
≤ 75 mm (K) ≤ 59 mm (K)
VERSAFLOW 3
≤ 85 mm (R) ≤ 59 mm (R)
ECOCELL
≤ 85 mm (R), 75 mm (K) ≤ 59 mm (R, K)
VERSAFLOW 4
≤ 85 mm (R) ≤ 59 mm (R)
Finger Conveyor = (M)
Roller Conveyor = (R)
Pin Chain Conveyor = (K)
8
S NOZZLE 7.0/11.0; H=80; B14,1
211557
1 pcs.
S NOZZLE 8.0/12.0; H=80; B14,1
211314
1 pcs.
S NOZZLE 9.0/13.0; H=80; B14,1
211559
1 pcs.
S NOZZLE 10.0/14.0; H=80; B14,1
211315
1 pcs.
S NOZZLE 2.6/5.6; H=85; B14,1
285199
1 pcs.
S NOZZLE 2.8/5.6; H=85; B14,1
282773
1 pcs.
S NOZZLE 3.0/5.6; H=85; B14,1
282775
1 pcs.
S NOZZLE 3.0/6.0; H=85; B14,1
278550
1 pcs.
S NOZZLE 3.5/5.6; H=85; B14,1
229921
1 pcs.
S NOZZLE 3.5/7.0; H=85; B14,1
229923
1 pcs.
Height 80 mm, B14,1
Height 85 mm, B14,1
Selective Soldering Nozzles
Finger Conveyor = (M)
Roller Conveyor = (R)
Pin Chain Conveyor = (K)
9
Nozzle height with variable Z-Axis Nozzle height with variable Z-Axis
ECOSELECT 1
≤ 90 mm (M) ≤ 85 mm (M)
SMARTFLOW
≤ 75 mm (M) -----
ECOSELECT 2
≤ 75 mm (K) ≤ 59 mm (K)
VERSAFLOW 3
≤ 85 mm (R) ≤ 59 mm (R)
ECOCELL
≤ 85 mm (R), 75 mm (K) ≤ 59 mm (R, K)
VERSAFLOW 4
≤ 85 mm (R) ≤ 59 mm (R)
S NOZZLE 4.0/8.0; H=90; B14,1
197665
1 pcs.
S NOZZLE 3.0/6.0; H=20; SPECIAL
289546
1 pcs.
S NOZZLE 5.0/24.0; H=46; SPECIAL
223539
1 pcs.
S NOZZLE 8.0/24.0; H=46; SPECIAL
223544
1 pcs.
S NOZZLE 14.0/28.0; H=46; SPECIAL
272476
1 pcs.
S NOZZLE 15.0/31.0; H=46; SPECIAL
272385
1 pcs.
S NOZZLE 4.0/30.0; H=47; SPECIAL
248276
1 pcs.
S NOZZLE 5.0/20.0; H=47; SPECIAL
266283
1 pcs.
S NOZZLE 5.0/20.0; H=47; SPECIAL
273501
1 pcs.
S NOZZLE 10.0/25.0; H=47; SPECIAL
289533
1 pcs.
S NOZZLE 35.0/8.0; H=83; SPECIAL
273362
1 pcs.
Height 90 mm, B14,1 Special Nozzles, B14,1
Special Nozzles, B14,1
Selective Soldering Nozzles
