4 5 Clamp Board Conveyor Unit KKH-1008 R>L 9 10 11 12 12 14 14 13 13 15 15 16 16 15 15 17 18 19 20 21 22 23 24 25 26,27 28,29 30 31 32 32 33 34 34 35 35 36 36 36 37 38 39 39 26,27 28,29 1,3 2,4 5,7 6,8 L>R No. Part…
3
5
Main Stopper (YSi-V Type)
Conveyor Unit
KKH-1504
MAIN STOPPER ASSY.1
MAIN STOPPER ASSY.2
LR
5
1
4
6
9
2
3
18
14
17
15
16
13
MAIN STOPPER ASSY.1
MAIN STOPPER ASSY.1
MAIN STOPPER ASSY.2
MAIN STOPPER ASSY.2
RL
KKH-9160-01 (RL)
KKH-9160-11 (LR)
KKH-9170-01 (RL)
KKH-9170-11(LR)
7
8
19
20
23
22
21
21
5
1
4
9
2
3
18
14
17
15
16
13
8
19
20
23
22
21
21
5
1
4
6
11
2
3
18
14
17
15
16
12
7
10
19
20
23
22
21
21
5
1
4
11
2
3
18
14
17
15
16
12
10
19
20
23
22
21
21
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHW-M916C-000 SPACER 4
2 KHW-M916G-000 COLLAR, JOINT 2
3 KHY-M926H-001 JOINT, CYL. 2
4 KKE-M9169-010 SHAFT,STOPPER 2
5 KKE-M916B-000 GUIDE 2
6 KKH-M653A-000 SEN.MAIN ST UP ASSY 1
7 KKH-M653A-100 SEN.MAIN ST DN ASSY 1
8 KKH-M9161-020 BRKT.,CYLINDER 1 1
9 KKH-M9163-010 BRKT.,STOPPER 1 1
10 KKH-M9166-020 BRKT.,CYLINDER 2 1
11 KKH-M916A-000 BRKT.,STOPPER 2 1
12 KLT-M9163-000 PLATE,STOPPER 2 1
13 KLT-M9165-000 PLATE,STOPPER 1 1
14 KLT-M9168-000 PLATE,STOPPER 2
15 KLT-M9169-100 CYLINDER 2
16 $UEF4BU-M3 JOINT 4
17 90112-2AJ005 BOLT, HEX.SOCKET HEAD 4
18 90990-08J027 SCREW, PAN HEAD 4
19 91312-03030 BOLT HEX,SOCKET HEAD 4
20 91312-04006 BOLT HEX,SOCKET HEAD 4
21 91312-04010 BOLT HEX,SOCKET HEAD 8
22 91312-04012 BOLT HEX,SOCKET HEAD 2
23 92902-04200 WASHER,PLAIN 4
4
5
Clamp Board
Conveyor Unit
KKH-1008
R>L
9
10
11
12
12
14
14
13
13
15
15
16
16
15
15
17
18
19
20
21
22
23
24
25
26,27
28,29
30
31
32
32
33
34
34
35
35
36
36
36
37
38
39
39
26,27
28,29
1,3
2,4
5,7
6,8
L>R
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKH-M9260-10 CLAMP BOARD SUB ASSY 1 R>L 600
2 KKH-M9260-20 CLAMP BOARD SUB ASSY 1 R>L 600
3 KKH-M9260-30 CLAMP BOARD SUB ASSY 1 R>L 650
4 KKH-M9260-40 CLAMP BOARD SUB ASSY 1 R>L 650
5 KKH-M9260-50 CLAMP BOARD SUB ASSY 1 L>R 600
6 KKH-M9260-60 CLAMP BOARD SUB ASSY 1 L>R 600
7 KKH-M9260-70 CLAMP BOARD SUB ASSY 1 L>R 650
8 KKH-M9260-80 CLAMP BOARD SUB ASSY 1 L>R 650
9 KHW-M9167-00 BRKT.,CYL. 1
10 KHW-M916E-00 BUSH 1
11 KHW-M916F-00 SHAFT 1
12 KHW-M9261-00 PLATE1, LINK 2
13 KHW-M9264-A0 LINK A ASSY. 2
14 KHW-M9264-B0 LINK B ASSY. 2
15 KHW-M9265-00 SPACER 4
16 KHW-M926A-00 COLLAR 2
17 KHW-M926B-00 COLLAR, JOINT 1
18 KHW-M926E-00 NUT 1
19 KHW-M9285-00 SPEED CONTROLLER 2
20 KHY-M9263-00 CYLINDER 1
21 KHY-M926F-00 JOINT,CYL.BRKT 1
22 KHY-M926H-00 JOINT, CYL. 1
23 KHY-M926M-00 STOPPER,CYLNDER 1
24 KKH-M9262-00 PLATE,BASE S 1
25 KKH-M9269-00 BRKT.,CYL. 1
26 KKH-M926C-00 PLATE,BOARD CLAMP 2 R>L 600
27
KKH-M926C-12 PLATE,BOARD CLAMP 2
Long hole potition 565.5mm NG MF70137-2009/8/4
KKH-M926C-11 PLATE,BOARD CLAMP 2 R>L 650 Long hole potition 540.4mm
28 KKH-M926C-21
PLATE,BOARD CLAMP 2 L>R 600
29
KKH-M926C-32 PLATE,BOARD CLAMP 2
Long hole potition 582mm NG MF70137-2009/8/4
KKH-M926C-31 PLATE,BOARD CLAMP 2 L>R 650 Long hole potition 557mm
30 KKH-M926G-00 PLATE 2,LINK 1
31 KV7-M9266-01 GUIDE 3
32 90169-02JB04 SCREW, BINDING HEAD 12
33 90440-10J050 CIRCLIP(E) 1
34 91312-04010 BOLT HEX.SOCKET HEAD 2 M4X10
35 91312-04012 BOLT HEX.SOCKET HEAD 5 M4X12
36 91312-04014 BOLT HEX.SOCKET HEAD 4 M4X14
37 92012-04012 BOLT,BUTTON HEAD 1
38 95302-06600 NUT HEXAGON 1
39 98902-03005 SCREW BINDING HEAD 4
5
5
Main Conveyor (width)
Conveyor Unit
KKH-1008
R>L
27
28
40,41,65
2
1
2
3
3
4
5
5
7
8
9
10
10
11
12
13
13
13
13
14
17
18
19
19
18
21
22
22
22
22
24
25
23
16
20
15
6
6
31
32
33
34
34
35
36
37
37
38,39
38,39
40,41,65
42,43,66
42,43,66
42,43,66
42,43,66
44,45
L>R
44,45
44,45
L>R
27
28
29
30
51
50
50
51
52
52
52
52
52
52
52
52
52
52
52
53
52
52
53
53
55
54
55
55
55
55
55
56
56
57
57
57
57
58
58
58
59
60
48
49
49
49
49
49
49
49
49
60
60
60
60
60
60
46
46
46
46
46
46
46
46
47
47
60
62
49
62
64
64
63
69
26
63
44,45
26
60
63
54
60
63
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KG7-M9113-01 PULLEY 3 1 Board length
2 KGT-M912D-00 PULLEY 2
3 KH2-M9121-00 BEARING 2 Commonization
4 KHW-M9137-00 COLLAR,BRG. 1
5 KHW-M9139-00 PLATE,BRG. 2
6 KHY-M9A00-00 BALL SCREW W(460) 2
7 KHY-M1124-00 PLATE 24 1
8 KHY-M9101-01 STAY 1 1
9 KHY-M9102-01 STAY 2 1
10 KHY-M9103-01 STAY 3 2
11 KHY-M9104-00 PLATE 1A 1
12 KHY-M9105-00 PLATE 1B 1
13 KHY-M9107-01 STAY 1 4
14 KHY-M9109-01 BRKT.,MOTOR W 1
15 KHY-M9154-00 SPACER 1
16 KHY-M9152-00 SPACER 1
17 KHY-M9112-00 BRKT.,TENSION 1
18 KHY-M9115-01 PLATE 1,LINEAR 2
19 KHY-M9116-00 LM RALE&BLOCK 15,480 2
20 KHY-M9153-00 DAMPER B 1
21 KHY-M9120-00 BELT, W AXIS 1
22 KHY-M9123-00 GUIDE 1 4
23 KHY-M9151-00 DAMPER A 1
24 KHY-M9134-00 COVER,PULLEY 1
25 KHY-M9150-00 DOG,ORIGIN 1
26 92A08-04303 SET SCREW 6
27 90990-41J006 COLLAR 2
28 90933-01J200 BEARING 2
29 90933-03J608 BEARING 2
30 90K55-4W476W AC SERVO MOTOR 1
31 KKH-M652H-00 SENSOR,WORG ASSY 1
32
KKH-M9106-01 BRKT.,GUIDE 1
33 KKH-M9106-10 BRKT.,GUIDE 2 1
34 KKH-M911G-01 BRACKET,SENSOR 1 2
35 KKH-M911J-01 BRACKET,WIRE 1
36 KKH-M911K-01 BRACKET,CONNECTOR 1
37
KKH-M9121-01 FRAME,CONVEYOR 2 NG MF70137-2009/8/4
KKH-M9121-00 FRAME,CONVEYOR 2
38
KKH-M9124-01 PLATE 1,GUIDE 2 A notch position change NG MF70137-2009/8/4
KKH-M9124-00 PLATE 1,GUIDE 2 Board length 600 L=714
39
KKH-M9124-01 PLATE 1,GUIDE 2 A notch position change NG MF70137-2009/8/4
KKH-M9124-10 PLATE 1,GUIDE 2 Board length 650 L=714
40
KKH-M9125-01 PLATE 2,GUIDE 2 A notch position change NG MF70137-2009/8/4
KKH-M9125-00 PLATE 2,GUIDE 2 Board length 600 L=598
41
KKH-M9125-11 PLATE 2,GUIDE 2 A notch position change NG MF70137-2009/8/4
KKH-M9125-10 PLATE 2,GUIDE 2 Board length 650 L=648
42
KKH-M9126-02 GUIDE 1-1 4 Long hole potition 264>275.5mm NG MF70137-2009/8/4
KKH-M9126-01 GUIDE 1-1 4 Board length 600 L=291
43 KKH-M9126-11 GUIDE 1-1 4 Board length 650 L=266
44 KKH-M9164-00 SUPPORT,STOPPER 2 Board length 600 L=70
45 KKH-M9164-10 SUPPORT,STOPPER 2 Board length 650 L=50
46 92902-03200 WASHER PLAIN 20
47 92902-04200 WASHER PLAIN 2
48 91312-05020 BOLT HEX.SOCKET HEAD 1 M5X20
49 91312-06016 BOLT HEX.SOCKET HEAD 18 M6X16
50 91312-03005 BOLT HEX.SOCKET HEAD 4 M3X5
51 91312-03006 BOLT HEX.SOCKET HEAD 12 M3X6
52 91312-03008 BOLT HEX.SOCKET HEAD 44 M3X8
53 91312-03010 BOLT HEX.SOCKET HEAD
12 M3X10
54 91312-04006 BOLT HEX.SOCKET HEAD 2 M4X6
55 91312-04008 BOLT HEX.SOCKET HEAD 15 M4X8
56 91312-04010 BOLT HEX.SOCKET HEAD 8 M4X10
57 91312-04014 BOLT HEX.SOCKET HEAD 24 M4X14
58 91312-04020 BOLT HEX.SOCKET HEAD 7 M4X20
59 91312-04040 BOLT HEX.SOCKET HEAD 1 M4X40
60 91312-05010 BOLT HEX.SOCKET HEAD 2 M5X10
60 91312-06025 BOLT HEX.SOCKET HEAD 28 M6X25
62 92902-05200 WASHER PLAIN 2
63 92902-06200 WASHER PLAIN 8
64 90990-28J076 WASHER PLAIN(N) 2
65 KKH-M9100-E0 CONV. ASSY 500FR 1 Board length 500 L=398 MF70219-2009/7/28
66 KKH-M9100-F0 CONV. ASSY 500FL 1 Board length 500 L=391 MF70219-2009/7/28
