1 7 Laser Head Laser Head (OP) KKH-1008 42 19 42 18 37 28 41 16 17 43 49 46 46 38 30 13 34 34 14 15 32 9 10 8 33 44 42 1 1 12 7 31 48 48 27 37 40 22 21 32 20 41 29 45 39 39 36 25 26 35 6 23 46 47 1 50 39 24 47 47 2 50 50…
1
6
Marker Pen Unit
Marker (OP)
KKH-1008
29
45
6
38
29
29
45
45
44
48
37
23
11
38
25
26
13
47
46
47
46
40
8
33
42
9
21
30
22
31
36
15
16
39
34
19
51
36
27
20
32
24
28
38
14
17
38
41
43
43
5
35
24
28
27
21
30
22
31
12
7
18
39
10
50
1, 3
2, 4
34
20
32
25
38
29
45
29
45
29
45
37
38
38
10
R>L
L>R
49
FRONT
FRONT
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKH-M5100-00 MARKER PEN UNIT(LR) 1 (LR)
2 KKH-M5100-10 MARKER PEN UNIT(LL) 1 (LL)
3
Delete MF90169-2009/9/30
KKH-M5100-20 MARKER PEN UNIT(SR) 1 (SR)
4
Delete MF90169-2009/9/30
KKH-M5100-30 MARKER PEN UNIT(SL) 1 (SL)
5 KKH-M5132-00 GUIDE 1
6 KKH-M5159-01 STAY,HNS. 1 2 (LR,SR)
7 KKH-M5159-11 STAY,HNS. 1 2 (LL,SL)
8 KKH-M5165-00 CYLINDER 1
9
KKH-M5171-02 BASE,CAP 1 OK MF90171-2009/10/9
KKH-M5171-01 BASE,CAP 1
10
KKH-M5173-01 BASE,MARKER 1 OK MF90171-2009/10/9
KKH-M5173-00 BASE,MARKER 1
11 KKH-M5176-01 STAY,HNS. 2 2 (LR,SR)
12 KKH-M5176-11 STAY,HNS. 2 2 (LL,SL)
13 KKH-M5179-01 PEN,CYLINDER 1
14 KKH-M5182-00 BRKT.,CYLINDER 1 1
15 KKH-M5184-00 STAY,CHUCK 1
16 KKH-M5185-00 STOPPER,GUIDE 1
17 KKH-M5188-01 BRKT.,CYLINDER 2 2 (LR,SR)
18 KKH-M5188-11 BRKT.,CYLINDER 2 2 (LL,SL)
19 KKH-M5189-01 HOLDER,PEN 1
20 KKH-M5190-01 STOPPER,PEN 1
21 KKH-M5191-00 CAP(L) 2 (LR,LL)
22 KKH-M5191-10 CAP(S) 2 (SR,SL)
23 KH2-M7101-00 VALVE 1 1
24 LE1-M5107-00 ADAPTER 2 (SR,SL)
25 LE2-M74A2-00 SHOCK ABSORBER 1
26 LE3-M5105-51 ROD.CYLINDER 1
27
LE3-M51D1-20 PEN,MARKER(LR) 2 (LR,LL) Red
LE3-M51D1-30 PEN,MARKER(LB) 2 (LR,LL) Blue
28
LE3-M51D2-20 PEN,MARKER(SR) 2 (SR,SL) Red
LE3-M51D2-30 PEN,MARKER(SB) 2 (SR,SL) Blue
29 90990-11J003 SCREW,PAN HEAD W/W 3
30 90990-22J025 PACKING 2 (LR,LL)
31 90990-22J022 PACKING 2 (SR,SL)
32 90990-47J018 KNOB 1
33 90990-48J001 BALL PLUNGER 1
34 90990-50J002 PIN HINGE 1
35 91312-03010 BOLT HEX.SOCKET HEAD 5 M3X10
36 91312-03014 BOLT,HEX.SOCKET HEAD 6 M3X14
37 91312-03025 BOLT,HEX.SOCKET HEAD 4 M3X25
38 91312-04008 BOLT HEX.SOCKET HEAD 12 M4X8
39 91312-04010 BOLT HEX.SOCKET HEAD 6 M4X10
40 91312-04025 BOLT HEX.SOCKET HEAD 2 M4X25
41 91312-05014 BOLT HEX.SOCKET HEAD 3 M5X14
42 95302-04600 NUT HEXAGON 1
43 99480-04012 PIN,PARALLEL 4
44 $KM-10 MUFFLER 1
45 $NK-3N NYLON CLIP 3
46 $SC4-M3MA SPEED CONTROLLER 2
47 $SS4-M5A SPEED CONTROLLER 2
48 $TL6-01 JOINT 1
49 KHW-M8582-40 VALVE 1 Spare
50 KKH-M518A-00 OIL PAN1 1
51 KKH-M518B-00 OIL PAN2 1
1
7
Laser Head
Laser Head (OP)
KKH-1008
42
19
42
18
37
28
41
16
17
43
49
46
46
38
30
13
34
34
14
15
32
9
10
8
33
44
42
11
12
7
31
48
48
27
37
40
22
21
32
20
41
29
45
39
39
36
25
26
35
6
23
46
47
1
50
39
24
47
47
2
50
50
50
50
47
4
4
47
50
50
50
3
5
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKH-M5401-00 BLOCK,BEARING 1
2 KKH-M5402-00 PLATE,MAIN 1
3 KKH-M5403-00 PLATE,TOP 1
4 KKH-M5404-00 PLATE,SIDE 2
5 KKH-M5405-00 BRACKET,LASER 1
6 KKH-M5406-00 SHAFT 1
7 KKH-M5407-00 SPACER 1
8 KKH-M5408-00 LOCK NUT 1
9 KKH-M5409-00 PULLEY,SHAFT 1
10 KKH-M5410-00 POWER LOCK 1
11 KKH-M5411-00 COVER,HOUSING BRG. 1
12 KKH-M5412-00 HOUSING,BRG. 1
13 KKH-M5413-00 PLATE,MOTOR 1
14
KKH-M5414-01 PULLEY,MOTOR 1 OK MF70120-2009/7/16
KKH-M5414-00 PULLEY,MOTOR 1
15 KKH-M5415-00 BELT,AXIS 1
16 KKH-M5416-00 STOPPER,PIN 1
17 KKH-M5417-00 WASHER 1
18 KKH-M5418-00 BKT. STOPPER 1
19 KKH-M5419-00 STOPPER 1
20 KKH-M5420-00 SHAFT, BGR. LOWER 1
21 KKH-M5421-00 LOWER BRG.TABLE 1
22
KKH-M5422-01 BRACKET,SUPPORT 1 OK MF90165-2009/9/29
KKH-M5422-00 BRACKET,SUPPORT 1
23 KKH-M5423-00 COILING CABLE ASSY 1
24 KKH-M5424-000 BRACKET 1,CABLE 1
25 KKH-M5425-000 BRACKET 2,CABLE 1
26 KKH-M5426-000 BRACKET 3,CABLE 1
27 KKH-M5427-000 COVER,R AXIS 1
28 KKH-M654H-A0 SENSOR R ORG ASSY 1
29
LE1-M50HR-10 HEAD UNIT1 1 OK MFX0103-2009/11/26
LE1-M50HR-00 HEAD UNIT1 1
30 90K63-201207 AC SERVO MOTOR 1
31 90990-26J003 BEARING 1
32 90933-01J902 BEARING 2
33 90152-04J06 SCREW,SET M4X6 1
34 90152-03J03 SCREW,SET M3X3 2
35 92012-04012 BOLT,BUTTON HEAD 4 M4X12
36 91312-03004 BOLT HEX.SOCKET HEAD 1 M3X4
37 91312-03005 BOLT HEX.SOCKET HEAD 6 M3X5
38 91312-03010 BOLT HEX.SOCKET HEAD 4 M3X10
39 91312-04005 BOLT HEX.SOCKET HEAD 6 M4X5
40 91312-04006 BOLT HEX.SOCKET HEAD 4 M4X6
41 91312-04008 BOLT HEX.SOCKET HEAD 3 M4X8
42 91312-04010 BOLT HEX.SOCKET HEAD 8 M4X10
43 91312-04016 BOLT,HEX.SOCKET HEAD 4 M4X16
44 91312-04020 BOLT HEX.SOCKET HEAD 4 M4X20
45 91312-04030 BOLT HEX.SOCKET HEAD 2 M4X30
46 91312-05016 BOLT HEX.SOCKET HEAD 8 M5X16
47 91312-05020 BOLT HEX.SOCKET HEAD 12 M5X20
48 98902-04005 SCREW BINDING HEAD 4
49 92902-04200 WASHER PLAIN 4
50 99480-04010 PIN PARALLEL: 4X10 10
1
8
Control Box
Controller
KKH-0908
28
22
6
5
17
4
27
29
2
29
11
26
18
21
29
10
29
26
9
20
7
26
26
29
8
19
26
13
3
29
15
14
23
25
30
24
26
12
16
1
31
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKH-M4101-00 PLATE,BOX 1 1
2 KKH-M4102-00 PLATE,BOX 2 1
3 KKH-M4103-00 PLATE,BOX 3 1
4 LC1-M4006-01 PANEL,HDD(2) 1
5 LC1-M40A2-00 SPACER,HED 4
6 LC1-M40A3-00 H.E.D. 4
7
Delete MHX0021-2011/11/14
KKH-M4105-00 BRACKET,BOARD 1
8 LE3-M400A-01 BRKT,BOARD 1 1
9 LE3-M400B-01 BRKT,BOARD 2 1
10 LE3-M400C-00 GOM,BOARD 2
11 LE3-M400E-01 PLATE 1 1
12 LE3-M400H-00 GOM,CTRL BOX 2
13 LE3-M400P-00 BRKT,PORT 1
14 KGA-M4187-00 FAN GUARD 119MM 1
15 KHN-M6185-00 FAN MOTOR ASSY 1
16 LE3-M65E5-00 ATX POWER SUPPLY 1
17
KKH-M53J1-A0 HDD UNIT SET 1 OK MGX0059-2010/11/25
KKH-M53J1-00 HDD UNIT 1
18 KKH-M4209-10 SYSTEM UNIT ASSY 1
19 LE3-M40H0-00 BOARD,MCB 1
20
KKH-M441H-00 VISION BOARD ASSY 1 NG MF40062-2009/4/7
LE3-M40HB-00 BOARD,VM9 1
21 90990-05J025 SPACER BOLT 9
22 90990-28J126 WASHER,PLAIN 4
23 92902-04200 WASHER PLAIN 4
24 91312-04008 BOLT HEX.SOCKET HEAD 4 M4X8
25 91312-04012 BOLT,HEX.SOCKET HEAD 4 M4X12
26 97602-03306 SCREW,PAN HEAD W/W 19
27 97602-03308 SCREW,PAN HEAD W/W 4
28 97602-03314 SCREW,PAN HEAD W/W 4
29 97602-04306 SCREW,BIN.HEAD W/W. 20
30 95302-04600 NUT HEXAGON 4
31 KKH-M441H-A0 VISION BOARD SET 1 OK MHX0021-2011/11/14
