5.2.7 To run in Continous Mode
The controller can be setup to repeat the run continuously.
1. Touch the Setup icon to enter the setup screen
2. Touch the “Run Method” icon
3. Enter the delay time (ex. 5000 ms)
4. Touch the “Countinous Run” icon
5. Touch the Check Mark icon to save and exit
The screen will look similarly to the screen below:
25
9. Type: “set ZONEINFO=C:\iot\timezone.zip” then touch the “Enter” button
10. Type: “ipconfig” then touch the “Enter” button
11. Record the Server IPv4 address show in the “IPv4 Address” line on the above
screen; For this example, the Server IP address is: 172.16.40.91
This address will be entered in the controller screen later.
12. Type: “.\portal” then touch the Enter button
24
7. Type: “cd :\iot” then touch the “Enter” button
8. Type: “set OKI_IOT_PREFIX=MyPrefix” then touch the “Enter” button
13
Note: If the controller is set to activate memory cell 1 and the delay time is
set at 5000 ms, the controller will activate memory 1 contiuously with 5000
ms delay between each activation.
5.3 Setup for Auger Valve with Encoder Motor
Procedure to control encoder motor valve is very similar to non-encoder valve.
The dispense cycle of encoder motor valve is controlled mainly through
encoder counts.
1. Touch the Setup icon to enter the setup screen
2. Touch the Controller type icon to switch to Encoder controller
“E-Pump Controller”
3. Touch the X icon to save and exit
4. Touch the Dispense icon to enter the setup screen
14
5. Touch the Up or Down arrows to set the dispense encoder count
Note: if suck back is needed, touch the “Reverse” icon to setup
motor reverse encoder count
6. Touch the Check Mark icon to save and exit
7. Select desired dispense mode to continue (Timed, Interrupt, Teach or Purge)
8. Touch the Voltage icon to set voltage
9. Touch the Up or Down arrows to set input voltage
10. Touch the Check Mark icon to save and exit
23
6. INTERNET of Thing (IoT)
6.1 Setup webserver on the computer
1. Go to Techcon Website (www.techconsystems.com) and download the
following files to your computer:
a. The “portal.exe” file
b. The “timezone.zip” file
2. Create a new folder and name “IoT” or any desired name
3. Copy the “portal.exe” file and the “timezone.zip” file in the “IoT” folder
4. Click on the “Windows” start icon
5. Type: “cmd” in the box (as show below)
6. Touch the “Enter” button
The screen should appear as shown below
