30 SM E 12 mm SME Tape Feeder - Total NO. LEVEL P ART N O. P ART NAM E Q'TY TYP E OLD NO. Refere nce 2 J70 65 0978 C INS T A L L GU ID E 1 3 FC1 8-00 0205A BT M LOC ' PI N 1 S70 000 001 A 4 J70 65 0948 B LOCA T…
29
SME
12
mm SME Tape Feeder - Sub (6)
30
SME
12
mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
2 J70650978C INSTALL GUIDE 1
3 FC18-000205A BTM LOC' PIN 1 S70000001A
4 J70650948B LOCATION FLANGE 1
5 FC18-000204A FRONT GUIDE PIN 1 S70000002A
14 S66010003A BEARING 1 S66010003A
31
SME
12
mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
D EP08-000035A MOTOR ASSY 1 S90000011A
F AM03-001462A VINYL DISCHARGE ASSY 1 S90000013A
1 FC39-000730A DISCHARGE FRAME 1 S72000010A
2 MC19-000342A VINYL FIX ROLLER PULLEY 1 S72000011A
