30
SME
12
mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
2 J70650978C INSTALL GUIDE 1
3 FC18-000205A BTM LOC' PIN 1 S70000001A
4 J70650948B LOCATION FLANGE 1
5 FC18-000204A FRONT GUIDE PIN 1 S70000002A
14 S66010003A BEARING 1 S66010003A
31
SME
12
mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
D EP08-000035A MOTOR ASSY 1 S90000011A
F AM03-001462A VINYL DISCHARGE ASSY 1 S90000013A
1 FC39-000730A DISCHARGE FRAME 1 S72000010A
2 MC19-000342A VINYL FIX ROLLER PULLEY 1 S72000011A
32
SME
12
mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
9 AM03-005003A VINYL SEPARATOR 1 1 S72000013A
10 J66011086A BALL_BEARING MF106ZZS 2 S66010005A
G FC35-000077A VINYL EXIT ROLLER ASSY 1 S90000018A
H AM03-005013A VINYL EXIT MOVING ASSY 1 S90000023A
