63 SM E 24 mm SME Tape Feeder - Sub NO. LEVEL P AR T NO. P ART NAME Q'TY T YPE OLD NO. Reference D EP 08- 00 0035 A MOTO R AS SY 1 S90 00 00 1 1A F AM 03 -001 5 00 AA VINY L DISC HAR GE AS SY 1 S900 000 14 1 FC39- 0…
62
SME
24
mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
2 J70650978C INSTALL GUIDE 1
3 FC18-000205A BTM LOC' PIN 1
4 J70650948B LOCATION FLANGE 1
5 FC18-000204A FRONT GUIDE PIN 1
14 J66011014A BALL_BEARING_F605ZZ-STF100N F605ZZ 1 S66010003A
63
SME
24
mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
D EP08-000035A MOTOR ASSY 1 S90000011A
F AM03-001500AA VINYL DISCHARGE ASSY 1 S90000014
1 FC39-000730A DISCHARGE FRAME 1 S72000010A
2 MC19-000342A VINYL FIX ROLLER PULLEY 1 S72000011A PULLEY FLANGE included
64
SME
24
mm SME Tape Feeder - Sub
NO. LEVEL PART NO. PART NAME Q'TY TYPE OLD NO. Reference
9 AM03-005005A VINYL SEPARATOR 1 1 S72000014A
10 J66011086A BALL_BEARING MF106ZZS 2 S66010005A
G FC35-000078A VINYL EXIT ROLLER ASSY 1 S90000019A
H AM03-005014A VINYL EXIT MOVING ASSY 1 S90000024A
