SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
6/8
3. Both of the front and rear side operators are switched into the scanned operator.
* When "Operator Level Time Limit" is effective, both of the front and rear side operators
return to "Returning operator name" at the same time.
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
7/8
4. Setting
Set this function with “SystemConfig” of PC in which YAMAHA IT-System is installed.
Specify "Use" or "Not Use" of “Simultaneous switching operator setting both of the front and
rear" with System Config.
1. Start [SystemConfig] window from [Start] - [Program] - [YAMAHA IT-System] -
[SystemConfig], and select [Inline Setup] from the [Setting Item] drop down list box.
2. Select [Alllines common] – [OP002] – [Use Setting] – [Simultaneous switching operator
setting both of the front and rear] of the tree view.
Press the "Change" button and set “Use” or “Not Use”.
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
8/8
[ Item of setting ]
Item of setting Default
Value
Set value
Simultaneous switching operator
setting
both of the front and rear
Not Use When "Use" is selected
This Function becomes effective.
When "Not Use" is selected
This Function becomes invalid.
3. Press the "Save" button after changing the setting.
* The setting of "SystemConfig" is completed.
Reload the board data on the machine after above setting is changed.
