POWER UP SEQUENCE
MACHINE POWER UP SEQUENCE
5.4 Installation Manual Chapter Issue 8, Jan 16
7. Select Change time zone....
8. Using the drop down box, select the appropriate time zone.
9. Select OK.
10. Select OK.
11. Select Start on the taskbar.
12. Select DEK Printer Software.
13. Press the System button.
POWER UP SEQUENCE
MACHINE POWER UP SEQUENCE
Chapter Issue 8, Jan 16 Installation Manual 5.5
Time and Date
(Windows XP)
In order for the machine PC to log events correctly, the system time, date and
correct time zone must be set.
1. Using the mouse, double click on the time, displayed at the right hand side
of the Windows taskbar. The Date/Time Properties window is displayed.
2. Click on the Time Zone tab.
3. Select the appropriate time zone from the drop down menu box.
4. Click on Apply.
5. Click on the Date & Time tab.
6. Adjust to local time and date and select OK.
7. Select Start on the taskbar.
8. Select DEK Printer Software.
9. Press the System button.
POWER UP SEQUENCE
MACHINE POWER UP SEQUENCE
5.6 Installation Manual Chapter Issue 8, Jan 16
E Stop Loop
Operation
Carry out the following procedure for E Stop loop operation check:
1. Press the E Stop button. The Restore Power window is displayed.
2. Reset the E Stop by turning the E Stop button clockwise until it unlatches.
3. Press the System button when prompted.
4. Open the front printhead cover. The Machine Operation Suspended -
Cover Open window is displayed.
5. Close the front printhead cover.
6. Press the System button when prompted.
Cover Open
Operation
1. After initialisation, open the front printhead cover. The open cover page is
displayed.
2. Close the front printhead cover.
3. Press the System button to check that system power is restored.
Screen Cleaner Function Check
CAUTION
RECOMMENDED SOLVENTS. ANY SOLVENTS USED MUST COMPLY WITH
LOCAL ENVIRONMENTAL GUIDELINES. ASM RECOMMEND USING SOLVENTS
THAT ARE ENVIRONMENTALLY FRIENDLY, IE CFC FREE AND WATER BASED.
SOLVENTS USED MUST HAVE FAST EVAPORATION RATES AND FLASHPOINT
SPECIFICATIONS GREATER THAN 39ºC.
WARNING
SOLVENT SPRAY. THE UNDER STENCIL CLEANER SPRAYS A FINE JET OF
SOLVENT SOLUTION ON TO THE CLEANER. APPROVED PROTECTIVE
CLOTHING SHOULD BE WORN.
CAUTION
PRINT MEDIUM AND SOLVENTS. WHEN USING OR HANDLING ANY PRINT
MEDIUM OR SOLVENT FORMULATION THE MANUFACTURERS’ SAFETY DATA
SHEETS MUST BE STRICTLY ADHERED TO.
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. SAFETY GLOVES MUST BE WORN.
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. EYE PROTECTION MUST BE WORN.
NOTE
If the Under Stencil Cleaner has not been used for lengthy periods, refer to
Technical Bulletin TB 329 to complete the cleaning regime for the spray bar.
