Spare Parts
PVA offers standard spare parts kits for all dispensing valves. These kits are
stocked for immediate shipment and allow replacement of all wearable parts of the valve.
The spare parts kit for this valve, product number RC2-SP, includes the following
components:
RC2-SP Includes:
Qty
Part Number
Description
1
V302
Seat
1
114-5247
Needle
1
V305
Packing, Teflon
2
VLV-014B
O-ring, Buna
2
VLV-008B
O-ring, Buna
1
VLV-006K
O-ring, Kalrez
1
VLV-004B
O-ring, Buna
3
VLV-010K
O-Ring, Kalrez
BILL OF MATERIALS FOR: FC100-MODULE (112-2998):
Item
Part Number
Description
Quantity
1A
114-5247
Needle
1
2A
SH5-40 x 2.0
Socket Head Cap Screw
2
3A
SH5-40 x 2.25
Socket Head Cap Screw
2
4A
V001
Set Screw
1
5A
V050
Spring
1
6A
V075
Standoff
2
7A
V200
End Cap
1
8A
V201
Lower Air Body
1
9A
V202
Piston
1
10A
V228
Upper Air Body
1
11A
V229
Lock Nut
1
12A
V230
Stroke Adjust
1
13A
V302
Seat
1
14A
V304PC
Fluid Section
1
15A
V305
Packing
1
16A
V306
Packing Nut
1
17A
VLV-004B
Buna O-Ring
1
18A
VLV-006K
Kalrez O-Ring
1
19A
VLV-008B
Buna O-Ring
2
20A
VLV-014B
Buna O-Ring
2
