Parts to retrofit the WPC on X-Serie S

Part number to configure the option WPC on X-series S:

03111747- Config upgrade kit WPC X4S,X3S,X2S (for SCM)

Content:

03110607- xx Fixed Table with WPC

03060460- xx Tape reel container compl./WPC

03048906- xx Waste container /WPC

03117193- xx Spacer block WPC-XS tape container

03113144- xx Basic body,NC second Row_WPC

- 1x PPW for CP short

- 3x NC magazine Type 20xx

- 1x NC magazine Type 28xx

00519845-xx Nozzle changer TH SX-Serie

(magazine holder, 3 magazine with 2 garage,

1 magazine with 1 garage)

03115109- xx Basic body,NC second Row_WPC, Base

03113720- xx Bridge cover WPC on X-Series S

03117888- xx Bridge cover WPC on X-Serie S short

03115118- xx Protective plate WPC cpl. X-Series S

03105017-xx Add-on kit WPC M2 CAN switch X series S

00519975-xx Service window X-series S

09.09.2014 Page 3

Table fiducials

WPC-fiducial s

SIPLACE WPC @ X-Series S

09.09.2014 Page 4

00119743-xx Component table SIPLACE X-series S with WPC

03110607- xx Fixed Table with WPC

SIPLACE WPC @ X-Series S

03060460- xx Tape reel container compl./WPC

03113720- xx Bridge cover WPC on X-Series S

03117888- xx Bridge cover WPC on X-Serie S short

03115118- xx Protective plate WPC cpl. X-Series S

03048906- xx Waste container/WPC

09.09.2014 Page 5

Additional Parts for the option WPC on X-Serie S

SPS magazine Q10 SPS Magazine Q10 – 03087508-xx (without holder)

Magazine holder Q10cpl. – 03088072-xx

IC camera adapter assembly – 03099054-xx

03113144-xx Basic assembly NC 2.Row WPC

(complete part for option WPC on X-Series S

with CPP)

03115109-xx Basic assembly NC 2 array WPC

basic (for TH) + 00519845-xx NC TH for SX

Series

SIPLACE WPC @ X-Series S
