09.09.2014 Page 5
Additional Parts for the option WPC on X-Serie S
SPS magazine Q10 SPS Magazine Q10 – 03087508-xx (without holder)
Magazine holder Q10cpl. – 03088072-xx
1
2
IC camera adapter assembly – 03099054-xx
03113144-xx Basic assembly NC 2.Row WPC
(complete part for option WPC on X-Series S
with CPP)
03115109-xx Basic assembly NC 2 array WPC
basic (for TH) + 00519845-xx NC TH for SX
Series
SIPLACE WPC @ X-Series S
09.09.2014 Page 6
General configuration
The following configurations for the X-Series S machine focus on location 2 only.
The images show the different configurations of the X-Series S machine with WPC and
all other options which are possible.
Option: - WPC 5 or 6 only on location 2
Additional Options: - CPP or Twin Head
- IC camera with TH and CPP_H
- FC camera with TH
- 3D coplan with TH
- Smart pin support
Option on the fixed table: - all Feeder types
- Linear dipping unit (LDU)
- Glue feeder
SIPLACE WPC @ X-Series S
09.09.2014 Page 7
Configuration 1 - X4 S with WPC5/6 and CPP head
Note:
Option SPS:3 tracks on
location 1/3 are not reachable
Dummy Feeder with Fiducial
- Table position 3
- Gantry 1/3 Pin Picker left
- Gantry 2/4 Pin Picker right
- Q10 on Location 2
- SPS Pin Picker (Left/Right)
- SPS magazine W5
WPC 5/6
Location 2
Siplace X4 S
Location 3
Location 1
Gantry 1
Location 4
SST33
Gantry 2
SST33
Gantry 3
SST 33
SST 33
Reject
Bin
Gantry 4
Reject
Bin
Reject
Bin
Reject
Bin
Note: FC camera and/or 3D-Sensor with CPP head is not possible.
