E2E 15 Accessories (Sold Separately) Mounting Brackets Material: Iron 9 6 2.4 23 1.5 12 5.5 Two hexagon nuts M3×P0.5 Two washers Two hexagon socket head cap screws M3 × 20 0.5 14.5 12.5 25 3 dia. 5.5 dia. 8 dia. Y92E-SC0…

100%1 / 20
E2E
14
M8 Pre-wired Connector Models (0.3 mm) (Unshielded)
M8 Connector Models (Unshielded)
6
M8 × P1
23.9
33
3
0
-0.1
dia.
Operation indicators (yellow) 4 × 90°
2.4-dia. vinyl-insulated round cable,
Standard length: 300 mm
E2E-C03N02-CJ-@@
6
M8 × P1
24.4
31
4
0
-0.1
dia.
2.9-dia. vinyl-insulated round cable,
Standard length: 300 mm
Operation indicators (yellow) 4 × 90°
E2E-C04N03-CJ-@@
6
M8 × P1
24.2
35.9
4-dia. vinyl-insulated round cable,
Standard length: 300 mm
Operation indicators (yellow) 4 × 90°
6.5
0
-0.1
dia.
E2E-C06N04-CJ-@@
6
6.5
M8 × P1
21
23.9
33
5
1
7
8.5 dia.
3
2.4-dia. vinyl-insulated round cable,
Standard length: 300 mm
3 dia.
0
-0.1
Two clamping nuts Toothed washer
Operation indicators (yellow) 4 × 90°
M4 × P0.5
*
* Mounting with clamping nuts and a
toothed washer is not possible on
this threaded section.
E2E-S04N02-CJ-@@
* Mounting with clamping nuts and a
toothed washer is not possible on
this threaded section.
6.5
6
M8 × P1
24.4
31
21
4
1
8
10 dia.
3
2.9-dia. vinyl-insulated round cable,
Standard length: 300 mm
Operation indicators (yellow) 4 × 90°
4 dia.
0
-0.1
Two clamping nuts Toothed washer
M5 × P0.5
*
E2E-S05N03-CJ-@@
6
M8 × P1
6.75 dia.
30.1
4
46
24.4
4 dia.
Operation indicators (yellow) 4 × 90°
0
-0.1
E2E-C04N03-MC-@@
6
43.4
28.4
24.2
6.75 dia.
M8 × P1
4
6.5 dia.
0
-0.1
Operation indicators (yellow) 4 × 90°
E2E-C06N04-MC-@@
6
6.5
24.4
30.1
46
21
M8 × P1
4
8
10 dia.
Operation indicators (yellow) 4 × 90°
Two clamping nuts Toothed washer
3
4 dia.
0
-0.1
M5 × P0.5
E2E-S05N03-MC-@@
E2E
15
Accessories (Sold Separately)
Mounting Brackets
Material: Iron
9
6
2.4
23
1.5
12
5.5
Two hexagon
nuts M3×P0.5
Two washers
Two hexagon
socket head
cap screws
M3
×
20
0.5
14.5
12.5
25
3 dia.
5.5 dia.
8 dia.
Y92E-SC03 (3-dia. block)
Material: Iron
0.5
9.5
6
2.4
23
1.5
12
5.5
14.5
12.5
25
4 dia.
5.5 dia.
Two hexagon
nuts M3×P0.5
Two washers
Two hexagon
socket head
cap screws
M3
×
20
8 dia.
Y92E-SC04 (4-dia. block)
Material: Iron
0.5
10.2
6
2.4
23
1.5
12
5.5
14.5
12.5
25
5.4 dia.
Two hexagon
nuts M3×P0.5
Two washers
Two hexagon
socket head
cap screws
M3
×
20
8 dia.
5.5 dia.
Y92E-SC05 (5.4-dia. block)
Material: Iron
0.5
10.8
6
2.4
23
1.5
12
5.5
14.5
12.5
25
6.5 dia.
Two hexagon
nuts M3×P0.5
Two washers
Two hexagon
socket head
cap screws
M3
×
20
8 dia.
5.5 dia.
Y92E-SC06 (6.5-dia. block)
A
2.5
± 0.05
dia.
Half punch
1
Cross sectional diagram A-A
20
14
±0.1
22
10
± 0.1
8
± 0.1
4 dia.
3.5
dia.
17
5
2
A
(R2)
R 0.3 max.
Material: Iron
+0.1
0
Y92E-SS04 (for M4 screw)
A
2.5
± 0.05
dia.
1
20
14
± 0.1
10
± 0.1
8
± 0.1
5.1 dia.
17
5
A
R2
R 0.3 max.
2-R1
2-R1
3.5
dia.
22
2
Material: Iron
Half punch
Cross sectional diagram A-A
+0.1
0
Y92E-SS05 (for M5 screw)
E2E
16
Protective Stainless-steel Spiral Tubes against Wire Breakage
Sensor I/O Connectors
Y92E-STS04-@
A
A
M4 × P0.5
Brass/nickel platingBrass/nickel plating Stainless steel (SUS304)
L
12
16 12
2
L = 0.5 m (Y92E-STS04-05), 1 m (Y92E-STS04-10)
8 dia.
4 dia.
7 dia.
5.6 dia.
Y92E-STS05-@
A
A
L
12
16 12
2
8 dia.
4 dia.
7 dia.
5.6 dia.
Brass/nickel platingBrass/nickel plating Stainless steel (SUS304)
M5 × P0.5
L = 0.5 m (Y92E-STS05-05), 1 m (Y92E-STS05-10)
XS3F-M32@-3@@-R
Straight
L
21.5
9 dia.
30
5
31.4
50
4
31
4 dia.
M8×P1
Soft PBT (UL94V-0)
Brass/nickel plating
L = 2 m (XS3F-M321-302-R),
5 m (XS3F-M321-305-R)
9 dia.
L
4 dia.
30
5
20.5
23.1
50
M8×P1
4
3
1
Brass/nickel plating
Soft PBT (UL94V-0)
Right-angle
L = 2 m (XS3F-M322-302-R),
5 m (XS3F-M322-305-R)
