10 5. Marker Pen Unit Section (Option) 5-1. Marker Pen Unit (Option) 13 7 21 4 2 12 14 3 25 27 24 1 6 19 16 9 22 26 8 20 23 24 17 18 24 20 10 5 21 15 24 23 20 13 1 1 13 7 21 4 2 12 14 3 25 27 24 1 6 19 16 9 22 26 8 20 20…
9
4.
Controller
Section
4-1. Power Control
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M4251-02 PLATE,POWER CTRL 1
2 LE1-M4252-01 BRACKET 1
3 LE1-M4253-04 COVER 1
4 LE1-M4255-02 PLATE,CTRL 1
5 LE1-M4256-02 STAY(1) 1
6 LE1-M4258-04 PLATE,CTRL 1
7 LE1-M4259-02 BRKT,HDD 1
8 LE1-M425C-02 BRACKET,FAN 1
9 LE1-M425E-03 PLATE 1
10 LE1-M425F-03 DUCT 1
11 LE1-M425K-01 COVER 1
12 LE1-M425L-01 STAY 1
13 LE1-M425M-00 STAY 2
14 LE1-M425P-02 BRACKET 1
15 LE1-M425R-00 BRACKET 1
16 LE1-M425U-00 COVER 1
17 LE1-M425W-00 COVER 1
18 LE1-M4261-01 BRACKET,USB 1
19 LE1-M4262-01 PLATE,CTRL 1
20 LE1-M4263-00 COVER 1
21 90563-13J060 SPACER 16
22 LC1-M40A2-00 SPACER,HED 4
23 LC1-M40A3-00 H.E.D. 4
24 90990-28J126 WASHER,PLAIN 4
25 97602-03314 SCREW,PAN HEAD W/W 4
26 LE1-M5254-00 BRACKET 1
27
91314-03006 BOLT HEX.SOCKET
HEAD
11
M3X6
28
91314-04005 BOLT HEX.SOCKET
HEAD
10
M4X5
29
91314-04008 BOLT HEX.SOCKET
HEAD
44
M4X8
30 98904-03006 SCREW BINDING HEAD 19
31 92907-03200 WASHER PLAIN 5
32
92990-04400 WASHER EXTL.
TOOTHED
6
10
5. Marker Pen Unit Section (Option)
5-1. Marker Pen Unit (Option)
13
7
21
4
2
12
14
3
25
27
24
1
6
19
16
9
22
26
8
20
23
24
17
18
24
20
10
5
21
15
24
23
20
13
11
13
7
21
4
2
12
14
3
25
27
24
1
6
19
16
9
22
26
8
20
20
23
24
17
18
24
20
10
5
21
15
24
23
20
13
11
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M510A-00 BASE,GUIDE 1
2 LE1-M510B-01 HOLDER,PEN 1
3 LE1-M510C-00 STOPPER,PEN 1
4 LE1-M510D-00 HOOK 1
5 LE1-M510E-00 HOOK 1
6 LE1-M510F-01 PLATE,SENSOR 1
7 LE1-M5107-00 ADAPTER 1
8 LE1-M511A-01 PLATE 1
9 LE1-M511B-03 PLATE 1
10 LE1-M51AA-00 GUIDE 1
11 LE1-M51AB-00 GUIDE 1
12 90990-47J001 KNOB 1
13 90990-50J002 PIN HINGE 1
14 LE1-M51A4-00 SPRING 1
15 90990-33J005 BOLT STOPPER 1
16 LE1-M66M0-02 MOTOR ASSY 1
17 LE1-M66M1-02 MKUP ASSY 1
18 LE1-M66M6-02 MKDN ASSY 1
19 90115-02J004 BOLT HEX.SOCKET HEAD 2
20 91314-03004 BOLT HEX.SOCKET HEAD 3 M3X4
21 91314-03006 BOLT HEX.SOCKET HEAD 4 M3X6
22 91314-04010 BOLT HEX.SOCKET HEAD 3 M4X10
23 91317-03006 BOLT HEX.SOCKET HEAD 12 M3X6
24 91317-03008 BOLT HEX.SOCKET HEAD 8 M3X8
25 91317-03010 BOLT HEX.SOCKET HEAD 2 M3X10
26 91317-04020 BOLT HEX.SOCKET HEAD 3 M4X20
27 90990-01J040 BOLT HEX.SO.LO HEAD 4
11
6. Laser Head Section (Option)
6-1. Laser Head (Option)
7
9
6
2
3
8
1
OLD
5 4
7
9
6
2
3
8
1
OLD
5
4
1-2
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1
LE1-M5252-04 PLATE,LASER
1
1-2 LE1-M5252-03 PLATE,LASER (old) 1 OK
2 LE1-M5253-00 ADJUSTER 1
3 LE1-M50HR-00 HEAD UNIT1 1
4 LE1-M50H8-00 CONTROL UNIT 1
5 LE1-M50HA-01 RB CABLE 5 1
6 90115-02J004 BOLT HEX.SOCKET HEAD 2
7 91314-04012 BOLT HEX.SOCKET HEAD 3 M4X12
8 91314-05020 BOLT HEX.SOCKET HEAD 2 M5X20
9 92903-04200 WASHER PLAIN 3
